Showing 14 of 14 matching Compressor.
system includes,
(1) compressor, manufactured by Frick, type RWBII, size IV222,
(1) 158.8 square meter carbon steel tube, head and shell horizontal evaporator, design pressure tube side 10 barg @ -28.9/93 degrees C, shell side 20.6 barg @ -28.9/93 degrees C, (298) 31.75mm diameter x 5486mm long carbon steel tubes,
(1) 53 square meter carbon steel tube, head and shell horizontal condenser, design pressure tube side 10.3 barg @ -28/90 degrees C, shell 20.7 barg @ -28/90 degrees C, (120) 31.75mm diameter x 4572mm long carbon steel tubes,
(1) oil system with oil circulation pump, oil separator, oil cooler, oil storage tank,
(1) purge drum,
(1) suction separator,
(1) economiser,
all mounted on a carbon steel skid
duty available 700,000 BTU/hr (205 kw) contract # 40391 16 bar (low), rated 180KW, 3/50/400 volt, system includes
20 Ton , 3000 SCFM Roof top heat and ac system--12 SEER
rotary chiller Optimus helical rotary, Hermetically sealed motor, Water cooled.
system includes,
(1) compressor, manufactured by Frick, type RWBII, size IV222,
(1) 158.8 square meter carbon steel tube, head and shell horizontal evaporator, design pressure tube side 10 barg @ -28.9/93 degrees C, shell side 20.6 barg @ -28.9/93 degrees C, (298) 31.75mm diameter x 5486mm long carbon steel tubes,
(1) 53 square meter carbon steel tube, head and shell horizontal condenser, design pressure tube side 10.3 barg @ -28/90 degrees C, shell 20.7 barg @ -28/90 degrees C, (120) 31.75mm diameter x 4572mm long carbon steel tubes,
(1) oil system with oil circulation pump, oil separator, oil cooler, oil storage tank,
(1) purge drum,
(1) suction separator,
(1) economiser,
all mounted on a carbon steel skid
rotary chiller Optimus helical rotary Hermetically sealed motor Water cooled.
300psig low side. Rated for 289 BHP.
refrigerant screw compressor, 492,000 kcal/hr with associated shell and tube condenser water 40 deg C in, 45 deg C out.
rotary Screw Compressor, max speed 4500 rpm, Design pressure High 350 psig., low 300 psig.-rated 298 BHP.
refrigerant screw compressor 492,000 kcal/hr, associated shell and tube condenser water 15 deg C in, 6 deg C out.
492,000 kcal/hr associated shell and tube condenser water 15 deg C in, 6 deg C out.
492,000 kcal/hr associated shell and tube condenser, water 15 deg C in, 6 deg C out.
When your operation requires reliable, precise temperature control, industrial chillers provide efficient cooling solutions for a wide range of process applications. With over 47 years of process equipment expertise, IPP offers immediate access to high-quality used chillers sourced from 20 complete plant sites and included in our inventory of over 15,000 ready-to-ship pieces of equipment. Choosing used chillers from IPP helps companies save on capital expenses, shorten installation timelines, and maintain consistent process conditions.
Industrial chillers remove heat from liquids or gases through refrigeration cycles or heat exchange systems, ensuring that equipment and processes operate within the required temperature ranges. They are essential for industries where cooling is critical to maintaining product quality, equipment performance, or operational safety.
Industrial chillers are designed for efficiency, chemical resistance, and durability:
Learn more about industrial chiller selection and operation at Plant Engineering.
Search the IPP inventory or contact IPP’s equipment experts to find a used chiller that matches your process cooling needs. With ready-to-ship inventory, IPP helps companies reduce project lead times, control cooling costs, and maintain consistent operational performance.
