Used fluid bed dryers for sale: uniform drying for granules, powders and crystals
Highest-ranked available inventory for this selection.
No subtypes are available.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Enter a keyword to match this specification.
Select one or more values to narrow the current listings.
Select one or more values to narrow the current listings.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Use this setting to include or exclude equipment with this feature.
Showing 10 of 10 matching Fluid Bed Dryers.
120 kg Aeromatic Fluid bed dryer/ coater Com.No. 88 91 42 Bowl volume is 240 liters System utility requirements are: Steam maximum 150 kg/h @ 6 bar g chilled water maximum 5.4 m3/hr 27 degrees C inlet temp compressed air 45 Nm3/hr @ 6 bar Motor: 3 phase Electric System accessories include a heating coil with 10 bar housing pressure for air heating, air inlet filters and cooler, 22 Kw system Fan rated for 10 bar/s, Airflow 0.25-0.83 m3/s at static pressure 10.00 pa; product filter with shaker discharge, and a bin lift system system Fan rated for 10 bar/s Airflow 0.25-0.83 m3/s at static pressure 10.00 pa product filter with shaker discharge, and a bin lift system Electrical controls available with unit
5 Kg Aeromatic spray granulator system Rated 6800 kcal/hr Fan driven by 3.4 PS Drying product bin 700mm dia top, 270mm dia btm x 650mm deep Control panel w/switches Including steam heater, valve, duct
250 Kg Aeromatic Fluid Bed Dryer / Aeromatic fluid bed spray granulator Aeromatic type STRE 0, 86.20 H food grade high performance fluidized bed drying system rated 109,200 Kcal/hr Pressure shock resistance 2,0 bar, vessel volume 610 liter, 0,86m² The system includes dryer, powder filling station, pneumatic system, air and product filters steam air heater (CS) rated 5,5 bar @ 200 degrees C Cooler, and dry product containers Originally used for flour and starch drying in a food processing plant Rated for Flour: inlet moisture 14-16%,outlet moisture 7%,drying temp 70 C. Starch: inlet moisture 15-17%,outlet moisture 5%,drying temp 70 C.
60-180 Kg Rated 467200 Kg/hr air flow with a Control panel, steam heater, and (2) sanitary product bins 1100/750mm dia x 500mm deep
200-400 Kg Designed drying 200 to 400 Kg batches Housing type 105.4, made of 304SS Product bin type 202.3, 780 liter volume, 304SS 1630mm top dia, 1230mm btm dia x 880mm conical section. W/(2) 200mm inlet for adding products, 1-500mm manway w/cover, 1-200mm sight glass, 200mm x 60mm oval sight glass. Btm section below bin 1230mm dia x 500mm deep. Includes air inlet 500mm dia. Dryer body and product bin are mtd on steel stand w/legs, 1550mm x 1050mm x 3900mm high. Drying chamber has (2) explosion doors. Product filling nozzles for granulation are Type 2001.1, 304SS. System includes second product spray system Type 701, nozzle rated 4 liter/min. Feed pump rated 0.01 to 11 liter/min @ 2.5 bar Variable speed drive motor. XP rupture disc. W/centrifugal fan Type 5012, made of CS w/epoxy lining, rated 180 cbm/hr @ 500mm WA @ 2900 rpm. Steam coil rated 270,000 kCal/hr @ 6 ATU. Fine dust filter, Type 403.1, 23 sq meter filter area. Product empties from the btm of dryer into Frewitt (Switzerland) granulator, Type MGWI-624, 304SS, SN 0677449, feed 350mm x 500mm. . Driven by 1.1 KW, 3/50/220/380 volt, 1390 rpm motor, couples to variable speed gear reducer, Type R4S-1062-11-4, SN 304531, rated inlet speed 56/280 rpm, outlet speed 89/30 rpm. connecting ducts
fluid bed dryer system 50-250 Kg With cylindrical chamber the rupture channel 950mm dia x 2345mm high Filter housing rated 2 bar and has volume of 1638 liter. Filter area 13 sq meter. W/(2) 304SS product bins, rated 2 bar, w/volume of 340 liter, base area of bin 0.45 sq meter, 1100mm/750mm dia x 500mm deep, w/60mm x 270mm sight glass. Fine dust filter 19.3 sq meter. Steam air heater rated 467,2000 Kg/hr with air inlet of -10 deg C and outlet of +80 deg C. Steam pressure 4 bar. Fan rated 1.2 cbm/sec, static pressure 5000 N/sq meter, rated 8.5 KW @ 2900 rpm. With hydraulic operated bin loader
60-90 Kg batch Steam heated 62000 Kcal/hr Air capacity 60 cbm/min With drying cycle of 20-50 minutes static pressure 300mm WS Cabinet 1644mm wide x 1154mm deep x 2880mm overall height. (2) doors with sight glasses
100-150 Kg Steam heated 200000 Kcal/hr Fan driven by 20 KW motor Drying cycle 20-50 min Fan speed 1450 rpm 100 cbm/min air capacity Static pressure 300mm WS (2) sanitary product bins 580 liter volume, 1200mm top diameter x 600mm straight side Dryer chamber including fan motor (2) doors with sight glasses With hydraulic lift for bins drainage
4.5 Kg/hr plastic lab Plastic cylindrical housing 10" dia x 18" long cone com 4686 Manual shaker Approximately 15 liter fluid bed container.
60-180 Kg 510000 Kcal/hr W/(1) sanitary product bin 1100/750mm dia x 500mm deep on casters Control panel, steam heater Filter volume 1.638 cbm filter area 13 sq meter Air inlet temp -10 deg C, air outlet temp +80 deg C Steam pressure 6 bar Max steam consumption 240 Kg/hr Fan rated 1.2 cbm/sec Static pressure 6000 N/sq meter Fan speed 2900 rpm
When your process requires precise drying and efficient heat transfer, fluid bed dryers offer one of the most reliable solutions available. Backed by more than 47 years of experience, 20 complete process plant sites, and a vast inventory of 15,000+ pieces of process equipment, IPP supplies high-quality used fluid bed dryers ready for immediate shipment to your facility.
Fluid bed dryers are widely used for drying powders, granules, and crystalline materials across industries such as pharmaceuticals, food processing, chemicals, and minerals. The technology uses a perforated plate or bed to suspend the product in an upward flow of heated air. This “fluidization” creates intimate contact between the product and the drying air, enabling fast and uniform drying with precise temperature control.
Because fluid bed dryers achieve high drying rates without exposing products to excessive heat, they are particularly useful for heat-sensitive materials and products requiring tight moisture specifications. This versatility makes them ideal for:
To ensure compatibility across diverse processing environments, fluid bed dryers are commonly constructed from:
Explore the IPP inventory or contact IPP’s equipment specialists to secure a fluid bed dryer tailored to your process needs. With used and surplus equipment available for immediate shipment, IPP helps companies accelerate projects while cutting capital costs.
Have questions about Fluid Bed Dryers or our services? Learn more about our products and why customers choose IPP.
