Showing 15 of 15 matching Nauta Mixers.
(1) Labotech discharge system with magnetic participle separator
(1) Labotech discharge system,
(1) magnetic particle separator
connected to gear reducer rated 20 PS Screw driven from btm by 11 KW, 3/50/290/500 volt, 1400 rpm motor W/pneumatic operated discharge valve. Top has 600mm manway w/cover, 1-150mm light, 1-200mm feed
Vrieco Nauta orbital screw mixer 15 PSIG @ 275 degrees F internal ASME Code stamped Internals have a 180 grit polished finish. All Welds ground smooth, and screw is also polished with a 180 grit finish With 30HP 3/60/230/460V screw drive 3HP 3/60/230/460V arm motor Dust collector: 10' 6" long, 4'10" wide, 3'4" high, weight 800lbs.
jacketed helical screw mixer/dryer internal design pressure -1/6 bar @ 220 degrees C (6300 liter) coil jacket 20 bar @ 220 degrees C (385 liter) top head jacket -1/3 bar @ 220 degrees C (180 liter) coil jacket and top head jacket are 321 stainless steel (1.4541) bolt dished top and bolt coned bottom 2m diameter kato agitator drive 750/2975 rpm mechanical seal, 321 stainless steel half pipe coil jacket on straight side and bottom cone, 321 stainless steel straight jacket on top head,mounting ring
single screw Nauta mixer Mixing chamber 120" dia x 173" Rotating arm driven by 2 HP, 3/60/230/460 volt, 1725 rpm motor Openings: 2-24", 2-8" Screw has bottom steady bearing rotation 1.437 rpm
single screw Nauta mixer Mixing chamber 120" dia x 173" cone Rotating arm driven by 2 HP, 3/60/230/460 volt, 1725 rpm motor. Openings: 2-24", 2-8". Screw has bottom steady bearing. Shaft speed 59.87 rpm, rotation 1.437 rpm.
truncated cone mixer 3080mm top diameter x 2440mm high cone section with 1800mm diameter truncated cone bottom Max speed 20 rpm 316 stainless steel twin helical agitator on single shaft. serial #21084086/1 20-710 rpm Belt driven with fluid clutch and thermistor (overheat protection). Unit designed for slow rotating batch mixing. Product is subject to minimal mechanical and thermal stress. Can be used on: soup mixtures, baking mixtures, spice mixtures, feedstuff, pesticides, dry materials with liquid and dry mortar mixes. Batch size 3800-6000 Kg. Openings: top 1-500mm with inspection cover, 3-50mm (1 with magnehelics gauge); cone side 1-480mm hinged inspection door; bottom discharge 310mm x 260mm. Unit with a reverse air jet filter.
single screw Nauta mixer. Mixing chamber 120" dia x 173" cone. Rotating arm driven by 2 HP, 3/60/230/460 volt, 1725 rpm motor. Openings: 2-24", 2-8". Screw has bottom steady bearing. Shaft speed 59.87 rpm, rotation 1.437 rpm.
Type 3530. Mixing chamber 11' diameter x 17' cone. 13" diameter screw, output speed 99 rpm. Orbital arm output speed 33 rpm. Orbital arm driven by 2 HP, 3/60/230/460 volt, 1750 rpm X-proof motor.
sanitary jacketed mixer, Jacket pressure 40 psi. carbon steel jacket on cone section. Belt driven.
order #16667 high conical section bolt flat top, screw and rotating orbital arm both driven from the top orbital arm driven by 1.5kw, 3/50/220/380 volt, 1420 rpm motor via 50 rpm reduction gearbox screw 350mm diameter x 3624mm long, 270mm screw pitch. screw is attached via a bottom pintle bearing openings top: 2-350mm (1 is the manway), 2-250mm, 3-100mm (2 are sightglasses), side bottom discharge with chute and pneumatic valve, chute has a 200mm discharge opening with pneuamtic butterfly valve,
order #M-16668, bolt flat top, screw and orbital arm both driven from the top, orbital arm driven by 2.2 kw, 3/50/220/380 volt, 1450 rpm motor 316 s/steel (1.4401) screw 350mm diameter x 4526mm long, 270mm screw pitch. screw is attached via a bottom pintle bearing, openings top: 2-350mm (1 is a manway), 2-250mm, 3-100mm ( 2 are sightglasses), side bottom discharge with chute and pneumatic valve, chute has a 200mm discharge opening with pneumatic butterfly valve
Series D, Int has polished finish. 52" x 61", overall 90" long. Hinged half cover. 10" btm discharge. 64 rpm screw speed, 2.2 rpm arm speed.
1440 rpm motor, Type SP70-LM70, 36 rpm Screw driven from btm by 11 KW, 3/50/290/500 volt, 1400 rpm motor, W/pneumatic operated discharge valve Top has 600mm manway w/cover 1-150mm light, 1-200mm feed.
Used Nauta mixers are vertical, conical screw mixers designed to gently mix powders, pastes, and slurries while preserving particle integrity and preventing segregation. The combination of axial and radial flow creates a low-shear blending action that is ideal for fragile, segregative, or heat-sensitive materials. With more than 47 years of process expertise, IPP supplies used, secondhand and surplus Nauta mixers from 20 global process plant sites and maintains a world-class inventory of 15,000+ ready-to-ship systems.
IPP sources Nauta-type mixers from trusted manufacturers including Hosokawa Micron, Bolz-Summix, and De Dietrich Process Systems.
Nauta mixers are built for precision and clean operation:
Explore how conical screw mixers optimize gentle powder mixing from Powder and Bulk Engineering.
Search the IPP inventory or contact IPP’s mixing equipment specialists to find the right used, surplus or secondhand Nauta mixer. Let us help you reduce downtime, improve blend uniformity, and save on capital costs.
