Showing 25 of 101 matching Pulverizers.
UPZ 315 highly polished 316L stainless steel fine impact mill with pin disc grinding system consisting of:
(1) UPZ 315 highly polished 316L stainless steel pin disc mill, manufactured by Hosokawa, serial #P1 125 630/1, asset #12302, 4500 rpm,(max 9200 rpm), permissible overpressure 0.09 bar @ 50 degrees C, inside 34 liter, pin size 7mm diameter x 35mm long, (236) pins on door side, (231) pins on drive side, plate beater diameter 298mm, (10) plate beaters, mill driven by approx 18kw motor
(1) 13.5 square meter 316L stainless steel vertical heat exchanger (gas cooler), manufactured by Transitherm GmbH, type WTGDP 273/2400 1-PASS, fabrik #10830, design pressure tube side -1/10 bar @ -29/100 degrees C (82 liter), shell side -1/10 bar @ -29/100 degrees C (76 liter), TUV, (132) 14mm diameter x 1 x 2.4m long 316L stainless steel tubes, single pass tube side, 273mm diameter 316L stainless steel shell
(2) 316L stainless steel heads with 90 degree bend, openings tube side each head with a 150mm, shell: 2-75mm, mounted on lugs
(1) stainless steel screw feeder
(1) 22 square meter polished 316L stainless steel reverse jet dust filter, manufactured by Hosokawa Alpine, type AR 34 M, serial #P1 140 710/1, pressure -0.1/+0.49 bar @ -29/80 degrees C, stainless steel polished to Ra max 0.5um, 1.3m diameter x 2m straight side x 1250mm bottom cone section, clamp bonnet head, (34) 130mm diameter x 1820mm long internal filter cages, 6-sets of valves
(1) highly polished 316L stainless steel cantilever rotary sifter, ATEX zone 22, manufactured by Kemutec Powder Technologies Ltd, type K650C sifter, serial #K650C A10942/1, asset #12230, working pressure -0.1/0.49 barg, design temperature 40 degrees C max, driven by 2.2kw, 3/50/415 volt 1500 rpm EExde IIB T4 zone 1 & 22, motor, mounted on a stainless steel frame with wheels
(1) 25m3/hr @ 7.06m head 316L stainless steel centrifugal pump, manufactured by HMD Sealless Pumps, serial #824545, type GSI 80-50-200 D-4A, NPSHa 19.68m, driven by 1.1kw, 3/50/415 volt 1450 rpm EExd IIB T4 motor, mounted on a baseplate
(1) 15 m3/minute 316L stainless steel Radial blower/fan, manufactured by Reitz, type single stage KXE080-001430-00, serial #175747, total pressure increase 746 daPa, impellor speed 3000 rpm, inlet size 140mm, discharge 100mm, driven by 7.5kw, 3/50/415 volt 3000 rpm EExdeIIBT4 motor
(1) 160mm diameter polished 316L stainless steel motorised rotary valve, manufactured by Engelsmann, type ZSA 200, driven by 0.55kw, 3/50/415 volt 10 rpm EExdIICT4 motor
(1x) stainless steel Lowbotech discharge unit with metal detector
(1x) 316L stainless steel Matcon Hopper discharge unit,
stainless steel (polished) Frewitt Delumper with crushing and grinding system, type Delumpwitt, upto 9000kg/hr flow rate, system includes: (1) stainless steel Frewitt Conwitt 250 conical sieve mill, serial #12014519069, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) stainless steel infeed hopper, (1) stainless steel Frewitt crushing unit, serial #12014532028, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) Frewitt Conwitt 250 vibrating unit, serial #1201459069, internal CE 1258 Ex II 1Dckb T157 degrees C X, external CE Ex II 3D c Ex tD T125 degrees C X, (1) servolift elevating/lifting machine, serial #12885, all mounted on a stainless steel frame
100 kg typical batch weight (Polished to a 0.1 Ra Min finish) Standard capacity range is 120-240 liters. This granulator features a through the wall design where the utilities are located outside the clean room. It has a jacket for the base and bowl with temperature sensor. The main impeller is capable of being raised and lowered. The side chopping system has a variable speed control. Discharge is into a through the wall mill model U-20. Features sanitary design and Clean in place. This multipurpose machine can process dry powders, aqueous and solvent granulations, effervescent products, and melt palletization applications. This machinery is electronically controlled. Can be used with Fluid bed dryer IPP stock # 233968.
1000 kg/h 120x160 mm drum screen, scraper drum 120x160 mm
Alexanderwerk Pharma pressure internal -1/3 bar @ 145 deg C (91ltr), jacket -1/3.3 bar @ 145 deg C (13ltr) underdriven by a DIETZ 400-690 Volt
Single Rotor Crusher fixed hammers. Crusher walls are 1/4" thick, shaft is 1 15/16" diameter. Unit has a SS feed chute, screen discharge with 1/2" holes230/460 volt motor.
10 HP Fixed knives blunt one side, w/reversible rotor. Unit driven by approx 10 HP, US varidrive. Screw feed driven by 1/4 HP, 3/60/230/460 volt US varidrive 3/60/230/460 volt US varidrive.
w/(3) feed screws. Discharge hopper w/out valve Stirrup type hammers. Rotor belt driven by 30 HP, 3/60/230/460 volt, 1770 rpm TEFC motor. Feeder belt driven by 1/2 HP, 3/60/220/440 volt, 1140 rpm TEFC motor.
Mikro Atomizer Rated for 6,000 rpm. Capable of handling capacities from 100 to 1000 lbs/hr, dependent on the material, this machine handles 3 functions in one machine. Pulverizes, air classifies and conveys the material.
fluidised opposed jet milling (grinding air pressure 6 barg, nozzle 0 16mm), 1250 dm3 grinding bin volume, 80 mbar permissible operating pressure in grinding bin, max operating pressure in grinding bin, 5- nozzles, nozzle diameters 14mm, 16mm, 18mm, classifier has 3-wheels, each wheel with 60 vanes wide pitch, narrow pitch 120 vanes, max wheel speed 4000 rpm each whees driven by 5.12 - 16 kw,3/50/415 volt, 940/2940 rpm motor, (1) 1100 liter carbon steel feed hopper weld dished top, weld coned bottom, bottom outlet with 150mm diameter carbon steel screw conveyor, 15.1 rpm speed,
fluidised opposed jet milling (grinding air pressure 6 barg, nozzle 0 16mm) 1250 dm3 grinding bin volume, 80 mbar permissible operating pressure in grinding bin, max operating pressure in grinding bin, 5- nozzles, nozzle diameters 14mm, 16mm, 18mm, classifier has 3-wheels, each wheel with 60 vanes wide pitch, narrow pitch 120 vanes, max wheel speed 4000 rpm, each whees driven by 5.12 - 16 kw, 3/50/415 volt, 940/2940 rpm motor, (1) 1100 liter carbon steel feed hopper weld dished top, weld coned bottom, bottom outlet with 150mm diameter carbon steel screw conveyor, 15.1 rpm speed,
Hammer mill pulverizer with product heater with left hand drive Rated for 1200 rpm with 12 hammers Machine has auto oiler for bearings. With Spinner and blower to move sized product to plant. with spinner 22,565 lbs. Product heater is rated 6 mm BTU, CS, North American air dryer powered by natural gas With Blower, Gas train and heater installed on skid Skid dimensions are 193" long x 61" wide x 74" high Air inlet is rectangular flange 15" x 11". Air Outlet is round 19" diameter Complete automated fuel train by, with series 2300 turbo blower. Product air heater is also listed under IPP # 221294.
Ni-Resist, Micro Atomizer Atomizer set up in its own building complete with the following accessories: Feed hopper is 33" wide x 39" long, Super sack unloader with dust collector & bagger, 50 Sq.Ft., 304 SS baghouse with fan. Takes 30 socks 4" diameter x 6' long, Takes 30 socks 4" diameter x 6' long, 51" w x 52" d x 68" h chamber.
Atomizer air swept classifying pulverizer/mill, all parts which are in contact with the product are stainless steel, capacity is 100 kgs to 2000 kg/hour, down to D90 = 20 microns, the mill grinds, classifies and conveys the product the Mikro-Atomizer uses air flow to convey materials to the grinding zone, size reduction occurs when hammers fitted to the rotor impact particles @ 4000 to 8000 rpm, a deflecting liner returns oversized particles to the hammer impact zone for further reduction, the ground materials are then conveyed to the classifier wheels which are mounted to the grinding rotor, larger particles are rejected for regrinding as the desired particles are air conveyed by internal fan blades and exit the mill for collection
Hammer mill pulverizer with product heater with left hand drive Rated for 1200 rpm with 12 hammers Machine has auto oiler for bearings. With Spinner and blower to move sized product to plant. Weight on hammer mill 14,660 lbs with spinner 22,565 lbs. Product heater is rated 6 mm BTU, CS, North American air dryer powered by natural gas With Blower, Gas train and heater installed on skid. Skid dimensions are 193" long x 61" wide x 74" high. Air inlet is rectangular flange 15" x 11". Air Outlet is round 19" diameter Complete automated fuel train by, with series 2300 turbo blower. Product air heater is also listed under IPP # 221295.
Fine grind air swept mill Approx 1000 CFM. Unit fine grinds and classifies. Features of this unit are Dust free operation, ease of mainteneance, and an exceptional ratio of product yeils to energy consumption. Simple adjustments to the machine allow for a narrow distibution range of output particles on wet, dry, fiberous, or heat sensitive materials. Capable of grinding down to the 5 micro range with maximum plates and speed. Mill speed of 1800 rpm, includes self contained lube system and volumetric feeder. Mian mill rotates counter clockwise 3/60/230/460V through a lubricated shaft. All seals purged with air/nitrogen. On board oil system features 12 gallon lube oil storage tank with self contained pump & regulator including sight glass. On board Volumetric feeder, 304SS, features a 4" screw with a 12" x 16" hopper, is chain driven by a 1 hp electric motor through a gear box.
Atomizer air swept classifying pulverizer/mill parts which are in contact with the product are stainless steel capacity is 100 kgs to 2000 kg/hour, down to D90 = 20 microns, the mill grinds, classifies and conveys the product the Mikro-Atomizer uses air flow to convey materials to the grinding zone, size reduction occurs when hammers fitted to the rotor impact particles @ 4000 to 8000 rpm, a deflecting liner returns oversized particles to the hammer impact zone for further reduction, the ground materials are then conveyed to the classifier wheels which are mounted to the grinding rotor, larger particles are rejected for regrinding as the desired particles are air conveyed by internal fan blades and exit the mill for collection
Pressure shock resistant design
Rated for 1500 kg./Hr,
pressure 11 bar at 70 degrees C,
side bottom inlet 390mm diameter and 125mm diameter,
top discharge 340mm,
36 pin disk underdriven by 45kW, 3/60/460 volt, 1775 rpm IP65 motor,
24 blade classifier under driven by 11kW, 3/60/460 volt, 1760 rpm motor,
Classifier is rated max. 3100 rpm.
speed 720 to 1775 rpm.
400mm air intake nozzle,
hinged top cover with manually operated opening mechanism
Coffee grinder
Atomizer air swept classifying pulverizer/mill all parts which are in contact with the product are stainless steel, capacity is 100 kgs to 2000 kg/hour, down to D90 = 20 microns, the mill grinds, classifies and conveys the product the Mikro-Atomizer uses air flow to convey materials to the grinding zone, size reduction occurs when hammers fitted to the rotor impact particles @ 4000 to 8000 rpm, a deflecting liner returns oversized particles to the hammer impact zone for further reduction, the ground materials are then conveyed to the classifier wheels which are mounted to the grinding rotor, larger particles are rejected for regrinding as the desired particles are air conveyed by internal fan blades and exit the mill for collection
rated: 11 DCuM, 0.05 bar, 60°C., 10 bar overpressure stud disc diameter: 315 mm, plate beater: 298 mm, swing beater: 298mm, air inlet: DN 100 mm
oscillating granulator. milling chamber 370 mm wide x 550 mm long 3~ 380V/220V 2,7A/4,7A 1,1 kW; 50Hz completely enclosed in stand
construction with 360 degree SS screen.
Designed for industrial duty, for mixing and depluming of slurries, pastes, liquids, and resins and shredding
Unit has vertical shaft with horizontal rotating knives, 360 degrees screen discharge.
Used pulverizer equipment from IPP encompasses a wide range of machinery essential for material size reduction and processing. Whether you require hammer mills, jet mills, or fluid energy mills, IPP offers equipment that meets your specific needs. With over 47 years of industry experience, IPP supplies used, surplus, and secondhand pulverizer equipment from 20 global plant sites and maintains a ready-to-ship inventory of 15,000+ process systems.
IPP stocks equipment from leading manufacturers such as Mikro Pulverizer, Fitzpatrick, and Hosokawa, ensuring quality and reliability.
To ensure durability and compliance, pulverizer equipment is typically constructed from:
