Evaporation Rate:
160 lb/h
Total Heat Transfer Surface Area:
3 m²
Orientation:
Vertical
Diameter:
600 mm
Height:
1,750 mm
Pressure:
5 bar
Temperature:
250 °C
Internal Condenser:
Yes
Internal Condenser size:
48.4 ft²
Vacuum:
Yes
Mechanical Seal on Shaft:
Yes
Drive Type:
Eberhard Bauer DF 1A41AH/283
Additional Information:
Short Path wiped film evaporator system with internal condensor
650 liter internal
45 liter in the jacket
top mounted rotor drive with a 2.2 kW/50 Hz gear motor with mechanical seal on rotor, (72) Graphit wipers on rotor
wipers dimensions: 30mmx16mmx150mm;
shell thickness: 8.0 mm; evaporator has a side bottom discharge for product
4.5 m² internal condensor: with (40)pipes, 25 mm outside diameter x 2270 mm long x 1.5 mm thickness
motor data: 380 V/2.2 kW/50 HZ/1420 rpm, exproof (G3), mfd by EBERHARD BAUER - Germany;
(1) separately 1.3 m² s/steel cold trap, mfd by Chematec AG - Switzerland, rated tube side 2 bar, rated shell side 5 bar, 368 mm diameter x 1420 length total. Mounted on (2) lugs.
