Results 4 items found

Available equipment

Showing 4 of 4 matching equipment.

Featured
Stock Number: #222356
Stainless Steel Austenitic Theodore Winkels Gmbh Tray Column
Diameter (1): 1,200 mm
Length (overall): 15,000 mm
Pressure: 3.2 bar
Vacuum: Yes
Number Of Trays: 23
Additional Information:

tray/distillation column design pressure 3.2 bar + vacuum (15500 liter) (23) 316Ti stainless steel (1.4571) internal single flow sieve trays with weirs, 400(1000)mm tray spacing,
More Details ⟶
Stock Number: #225672
Stainless Steel Austenitic Theodore Winkels Gmbh Tank
Capacity (Design): 13,200 gallons
Orientation: Vertical
Diameter: 3,200 mm
Straight-side Length: 6,150 mm
Internal Pressure: 0.05 bar
Internal Temperature: 200 °C
Jacket Type: External Pipe Coil
Jacket Material: Stainless Steel 316L
Jacket Pressure: 6 bar
Jacket Temperature: 200 °C
Vacuum: Yes
Cone Length: 24.8 in
Additional Information:
  • Tank with external coil on straight side.
  • 6.4 m^2^ coil designed for 6 bar & vacuum at 200 degrees C.
  • Coil 25mm thick, 8 turns with 300mm pitch. Support: Base Mounted.
More Details ⟶
no image found
Stock Number: #222345
Stainless Steel Austenitic Theodore Winkels Gmbh Tank
Capacity (Design): 50,000 L
Orientation: Vertical
Diameter: 3,000 mm
Straight-side Length: 7,450 mm
Internal Pressure: 0.05 bar
Internal Temperature: 200 °C
Does it have an Internal Coil?: Yes
Jacket Pressure: 6 bar
Jacket Temperature: 200 °C
Vacuum: Yes
Additional Information:

  • Coil 6 bar + vacuum @ 200 degrees C (70 liter) 25mm diameter 316Ti stainless steel (1.4571) removable pipe coil on straight side, coil surface area approximately

    8.9 square meter (96 square feet), (12) turns @ 500mm pitch (spacing).
More Details ⟶
no image found
Stock Number: #225671
Stainless Steel Austenitic Theodore Winkels Gmbh Tank
Capacity (Design): 70,000 L
Orientation: Vertical
Diameter: 2,600 mm
Straight-side Length: 13,400 mm
Internal Pressure: 0.05 bar
Internal Temperature: 200 °C
Jacket Type: External Pipe Coil
Jacket Material: Stainless Steel 316L
Jacket Pressure: 6 bar
Jacket Temperature: 200 °C
Vacuum: Yes
Cone Length: 11.4 in
Additional Information:
  • Tank with 115 liter external coil on straight side.
  • 13 m^2^ coil designed for 6 bar & vacuum at 200 degrees C.
  • Coil 25mm thick, 20 turns with 500mm pitch.
  • Built to TUV design code. Support: Base Mounted.
More Details ⟶
