Results 5 items found

Available equipment

Showing 5 of 5 matching equipment.

Stock Number: #213312
316 Stainless Steel Packed Column with 220 Sq.Ft. Overhead Condenser
Diameter (1): 36 in
Length (overall): 20 in
Pressure: 15 psi
Vacuum: Yes
Temperature: 365 °F
Packing Type: Structured
Packing Material: Structured
Additional Information: • 240 Sq. Ft • 316 stainless steel packed column with reboiler . • top mounted horizontal U-Tube reboiler, 316 SS tubes, 316 SS tube sheets, CS heads, 316 SS shell, Shell side rated for FV/15 @ 365 degrees F., tube side rated for 75 psi at 365 degrees F. 210 straight tubes, 0.75" diameter x 16 Ga wall x 72" long. 4 pass. • Shell = 0.25" thick, heads =0.3125" thick
More Details ⟶
Stock Number: #230369
Stainless Steel 304 Tolan Machinery Co, Inc. Tank
Capacity (Design): 1,500 gallons
Orientation: Vertical
Diameter: 72 in
Straight-side Length: 82 in
Internal Pressure: 14.7 psi
Does it have Agitation ?: Yes
Baffle Type: Sidewall Mounted Straight Baffle
Support: Legs
Additional Information: With 3HP top angle entering clamp mounted Lightning Agitator. (1) 2' center bottom discharge.
More Details ⟶
Stock Number: #241136
Stainless Steel 316L Tolan Machinery Co, Inc. Tank
Capacity (Design): 100 gallons
Orientation: Vertical
Diameter: 30 in
Straight-side Length: 31 in
Internal Pressure: 50 psi
Internal Temperature: 400 °F
Jacket Type: Half Pipe/Limpet
Jacket Material: Inconel
Jacket Pressure: 180 psi
Jacket Temperature: 400 °F
Vacuum: Yes
Support: Legs
Additional Information: • With SB168 Inconel 600 jacket on tank straight side and bottom dish, 0.105" thick.
More Details ⟶
Stock Number: #42074
Stainless Steel 304 Tolan Machinery Co, Inc. Tank
Capacity (Design): 250 gallons
Orientation: Vertical
Diameter: 42 in
Straight-side Length: 42 in
Internal Pressure: 15 psi
Internal Temperature: -30 °F
Does it have Agitation ?: Yes
Support: Sockets for pipe legs
More Details ⟶
no image found
Stock Number: #241260
Stainless Steel 316L Batch-Type Agitated Reactor
Capacity (Design): 100 gallons
Internal Pressure: 50 psi
Internal Full Vacuum: Yes
Internal Temperature: 400 °F
Jacket Pressure: 180 psi
Jacket Temperature: 400 °F
Jacket Material of Construction: Inconel
Body Only: Yes
Orientation: Vertical
Diameter: 30 in
Straight Side Length: 31 in
Support Type: Legs
More Details ⟶
