Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: SGL
Model: RS77-1-3760.6
Condition: Used
Material: Graphite
Heat Transfer Surface Area: 21.9 m² (235.7 ft²)
Orientation: Horizontal
design pressure tubeside -1/5.3 bar @ 175 degrees C, heads with carbon steel flat plate
Shell Pressure: 7 bar (101.5 psi). Shell Temperature: 175 °C (347 °F). Shell Material: Carbon Steel. Tube Pressure: 5.3 bar (76.9 psi). Tube Temperature: 175 °C (347 °F). Tube Material: Graphite. Vacuum: Yes. Shell Diameter: 332 mm (13.1 in). Head Material: Carbon Steel. Length: 6,700 mm (263.9 in). Shell-side Passes: 1. Tube-side Passes: 6. Tube Number: 37. Tube Diameter: 32 mm (1.26 in). Tube Length: 6,000 mm (236.2 in). Tube Thickness: 22 mm (0.87 in). Nozzle Schedule: openings tubeside: (1) head with 2-1 1/2", (1) head with none, shell side: 2-4", 2-1".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: VICARB
Model: HP2/20
Condition: Used
Material: Graphite
Heat Transfer Surface Area: 21 m² (226 ft²)
Orientation: Vertical
design pressure process side 7 bar @ 50/61 degrees C, service 3.6 bar @ 23/34 degrees C, exchanger made up of 8- blocks of HP2/20 elements
Shell Pressure: 2.5 bar (36.3 psi). Shell Temperature: 34 °C (93.2 °F). Shell Material: Carbon Steel. Tube Pressure: 6 bar (87 psi). Tube Temperature: 61 °C (141.8 °F). Tube Material: Graphite. Shell-side Passes: 2. Tube-side Passes: 3. Nozzle Schedule: openings: process 2-100mm, 2-25mm, service 2-100mm,.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Ralph Coidan LTD.
Model: 85-04.5A
Condition: Used
Material: Graphite
Heat Transfer Surface Area: 11.6 m² (125.1 ft²)
Orientation: Horizontal
inclined Hykarb tube in shell graphite heat exchangerJob number: 3420B Design pressure shell side: 5.2 bar @ 90 degrees C Design pressure tubeside: 3.5 bar @ 170 degrees C Tube dimensions: (85) 32mm O/D x 22mm I/D X 1391mm longNumber of internal baffle plates: 10
Shell Pressure: 3.5 bar (50.8 psi). Shell Temperature: 90 °C (194 °F). Tube Pressure: 1.01 bar (14.7 psi). Tube Temperature: 170 °C (338 °F). Shell Diameter: 438 mm (17.2 in). Length: 2,500 mm (98.4 in). Tube Number: 85. Tube Diameter: 32 mm (1.26 in). Tube Length: 1,400 mm (54.8 in). Tube Thickness: 10 mm (0.39 in). Nozzle Schedule: openings tubeside: 1-200mm, 1-150mm, 1- 100mm, 1-80mm, shell: 2-80mm,.
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Ralph Coidan LTD.
Model: 85-04.5A
Condition: Used
Material: Graphite
Heat Transfer Surface Area: 11.6 m² (125.1 ft²)
Orientation: Inclined
inclined Hykarb tube in shell graphite heat exchanger Job number: 3420A Design pressure (shell side): 5.2 bar @ 90 degrees C Design pressure (tubeside): 3.5 bar @ 170 degrees C Tube dimensions: (85) 32mm O/D x 22mm I/D X 1391mm long Number of internal baffle plates: 10
Shell Pressure: 3.5 bar (50.8 psi). Shell Temperature: 90 °C (194 °F). Tube Pressure: 1.01 bar (14.7 psi). Tube Temperature: 170 °C (338 °F). Tube Material: Graphite. Shell Diameter: 438 mm (17.2 in). Length: 2,500 mm (98.4 in). Tube Number: 85. Tube Diameter: 32 mm (1.26 in). Tube Length: 1,400 mm (54.8 in). Tube Thickness: 10 mm (0.39 in). Nozzle Schedule: openings tubeside: 1-200mm, 1-150mm, 1-100mm, 1-80mm, shell: 2-80mm,.
