Stainless Steel 316L Alfa Laval IV Spiral Heat Exchanger - IPP# 242610

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alfa Laval

Model: IV

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 8.2 m² (88.6 ft²)

Shell Pressure: 10 bar (145 psi)

• design pressure side A: -1/7 barg @ 200 degrees C,
• side B: -1/10 barg @ 200 degrees C,
• spacing side A 6 (45 liter), side B 5 ( 40 liter),
• design code: ASME VIII DIV 1 Ed 1992

Shell Temperature: 200 °C (392 °F). Shell Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 515 mm (20.3 in). Head Material: Stainless Steel 316L. Length: 500 mm (19.7 in). Nozzle Schedule: openings side A 1-75mm, 1-50mm, 1-32mm, side B 2-50mm, 1-15mm. Cold-side Pressure: 10 bar (145 psi). Cold-side Temperature: 200 °C (392 °F). Hot-side Pressure: 7 bar (101.5 psi). Hot-side Temperature: 200 °C (392 °F). Spiral Material: Stainless Steel 316L.

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alfa Laval

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 4 m² (43.1 ft²)

Shell Pressure: 4 bar (58 psi)

(2) 300mm high cone sections,

Shell Material: Stainless Steel 316L. Head Material: Stainless Steel 316L. Length: 300 mm (11.8 in). Nozzle Schedule: openings: 2-200mm, 3-50mm, 1-15mm,. Cold-side Pressure: 1 bar (14.5 psi). Spiral Material: Stainless Steel 316L.

Type: Heat Exchanger

Subtype: Spiral

Manufacturer: Alfa Laval

Model: IIIV

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 14 m² (150.7 ft²)

Shell Pressure: 8 bar (116 psi)

• design pressure side A: -1/6 barg @ 185 degrees C,
• side B: 8 barg @ 185 degrees C,
• spacing side A 12 (170 liter),
• side B 5 (105 liter),
• clamped flat top and bottom heads,
• design code: ASME VIII DIV 1 ED 92

Shell Temperature: 185 °C (365 °F). Shell Material: Stainless Steel 316L. Vacuum: Yes. Shell Diameter: 520 mm (20.5 in). Head Material: Stainless Steel 316L. Length: 1,250 mm (49.2 in). Nozzle Schedule: side A: 1-200mm, 1-100mm, 1-50mm, side B: 2-75mm. Cold-side Pressure: 6 bar (87 psi). Cold-side Temperature: 185 °C (365 °F). Hot-side Pressure: 8 bar (116 psi). Hot-side Temperature: 185 °C (365 °F). Spiral Material: Stainless Steel 316L.
