Rotary Vacuum Paddle Dryer with heated shaft. Vessel rated for Full vacuum internal 316SS internals SS 1/2 pipe coil jacket one head bolted dished, one head welded dished. Unit has approx. 12" diameter heated shaft with paddle agitator blades. Shaft is direct coupled to a gear reducer 3/60/230/460 volt Openings include: (1) 18" Top, (1) 12" x 16" end port with hinged cover, Bottom center discharge.

• Pharmaceutical design. This centrifuge has a clear distinction between the process area/clean room and the drive area. The processing area is free of dead space and allows for complete inspection and sterilization.
• The filter medium is installed inside the cantilever mounted screen basket.
• This centrifuge is Gas tight (over -pressure) to 0.04 bar. With feed and wash pipes, hydraulic plow with pneumatic heel cake removal system and solids discharge chute, with door lock switch.
• Internal accessories are Hastelloy C-22, Gasketing is PTFE.

inlet Carbon Steel skid mounted High Efficiency Fine classifier 3600 RPM rotor max speed.15kW. 460 vac 35 amps Inlet size is 9", outlet is 21" x 19 " square flange. Rejects line is 5" Particle wheel has hinged door for clean out and wheel access This classifier is rated for 2000-2600 m3h, and 200/2400 kG/h Finess is rated for 3.0-4.0 (c/37um).

• Rated for lethal service.
• Nozzles with Inconel 625 inlay.
• Glasslined beavertail baffle with WIKA TR-10 & PT100 temperature probes.
• Mechanically sealed agitator: FlowServe MD-200 DN140.
• See sales comments for additional options.

Fire pump Direct Driven by John Deere Diesel engine, with controller and fuel tank.

sanitary Two types of atomizers: (1x) Belt driven centrifugal atomizing disk & (1x) Down spraying, two fluid, external mixing, air atomizing nozzle APV Anhydro Compact Spray Dryer Air Inlet temperature 200 -300 degrees C (390-670 degrees F), Exhaust air temperature 90 degrees C (195 degrees F) Food grade construction Heat for hot air is natural gas fired by an Eclipse burner rated for 240,000 BTU This system has two forms of atomization, #1)Belt driven centrifugal atomizing disk, driven by a 1 HP motor. #2) Down spraying, two fluid, external mixing, air atomizing nozzle type. Dry product is separated in a SS cyclone, 12" top diameter x 48" high with a 4" cone bottom . Dust is collected in a CS bag house, 36" wide x 86" long x 14' high. 16 Bags with 4" diameter x 48" long socks, approximately 64 Sq. Ft. of filtration area TEFC Hi efficiency. Feed pump is driven by a 0.5 HP motor. Straight wall internal is 60".

• REBUILT 2.1 cu. ft. operating capacity Jacketed Porcupine Processor designed for batch operation manufactured by Bethlehem Foundry and Machine Company
• Shell is rated for MAWP 50 PSI
• Porcupine surface area is 15 sq. ft. jacket is 9.4 sq. ft. Head flats are 3/4" and 3 & 7/8"shell is 1/4" and jacket is 5/16"
• 230/460 volt motor with a Reynolds reduction gear
• with a 207:1 ratio Steam or hot oil inlets and outlets are all 1" NPT Process inlets an are two 3" and outlets are 3.5"
• Rebuilding included the following: Unit is stripped, cleaned, and shaft and jacket pressure tested Gearbox drained, cleaned, checked and refilled. Motor replaced, unit test run. Stuffing box gaskets replaced and new rotary joint installed. New top head cover gasket replaced, Test run and painted, new coupling guard installed.
• Manufactured by Gale Process Solutions (legacy Bethlehem Corporation/Advanced Thermal Solutions) Total Heat Transfer Surface Area: 24.4 ft². Size: 1203.

Alloy C22

Internal finish is a sanitary polish. 304SS sheathing. 304 stainless steel

18.35" Side discharge with discharge valve, 132 gallon Hastelloy C 22 side discharge valve. National Board # 287. rated FV/88 @392 degrees F.

Dryer Dimensions: 90" diameter x 76" length

hydraulic skid. Includes: integral Stock # 241013- Hastelloy C22 pulse jet Dust collector. 8.6" handhole, 4.33" site glass.

UNUSED

Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated, and "U" stamped.

welded dish heads (2:1) 12 mm thick

Coil: 114 mm OD x 4 mm thick,

Limpet covers bottom dish and 2615 mm of straight side (pitch 150mm). Coil heating surface area.

With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug.

20" Manhole with Cover and davit arm assist, one 6" sight glass, Support Type: Lugs.

• Single agitator design. Trough is not jacketed Agitator is hardfaced and rated 150 psig @ 650 degree F vessel rated atmospheric @ 650 degree F Trough contains approximately 62 cu. ft. of processing space Completely fabricated and assembled except for the following: Johnson rotary joint, panel coils, drive motor, gear reduction, chain and sprocket
• Manufactured by Gale Process Solutions (legacy Bethlehem Corporation/Advanced Thermal Solutions)

240 gal (900/1400 liter) sigma blade jkt mixer. Btm discharge. 1160mm wide x 810mm deep x 1160mm long. Geared both ends. W/Flander right angle gear reducer. Mixing arms speed 168/84 rpm. Btm valve pneumatically operated.

peeler centrifuge with a 0.12kw, 3/50/230/400 volt, 1360 rpm fan motor, discharge screw/plow driven by 2.2kw, 3/50/400 volt Ex motor, hydraulic door locking mechanism and cake thickness device driven by a hydraulic pump with a 0.75kw, 3/50/400 volt Ex motor, hinged front door, 1-200mm discharge, 1-250mm filtrate with s/steel tank, centrifuge with (1) Siemens OP37 controller, (1) s/steel GAF filter, (1) diaphragm pump, (1) 600ltr plastic tank, 900mm diameter x 1m high, (1) s/steel centrifugal pump, manufactured by SERO, type SEMA-3111-75-2.32, (1) 35ltr Schott glass reciever, (2) flow meter, (2) pneumatic valves, (1) main control panel

Zirconium/Alloy 59 packed column design pressure 5 bar + FV @ -20/205 deg C, 14580mm straight side, top section is 1350mm diameter x 7089mm straight side thickness is 6mm to 7.9mm, 4549mm high packing section, bottom section is 1.7m diameter x 7.9m straight side thickness 6mm, 4.4m high packing section, packing is glass filled polypropylene, also includes c/steel top platform and ladders

Niro (Bowen Design) Spray Dryer With BB-3 Type Spray machine Conical Bottom drying chamber is 12' diameter x 6' 7" straight side, and utilize a co current air flow design. Elevation to top of dryer is 25' 7". This is a complete system with the spray dryer and bag house mounted out doors. Feed related equipment is mounted indoors on a skid. Dryer details are as follows: Supply air; 1385 acfm. Natural gas; 27.9 acfm. Feed; 1725 lbs/hr. Product 525 lbs/hr. Evaporation rate 1200 lbs./hr. Process gas inlet temp. = 1100 degrees F. BB-3 spray machine with complete controls including a Penthouse control panel, feed valve, automatic force oil lube system by Sloan Brothers, and Magnetek GPD 505 VSC variable motor speed system. Bag house is manufactured from 321 SS, rated for 400 degrees F, with an air volume of 1850 scfm, and air to cloth ratio of 3.9:1. Blower is CS, by New York blower, series 45, size 224 and rated for 3000 cfm at 3127 rpm. Other support equipment includes a 400 gallon, fiberglass mixing feed tank, and related pumps. Auto valves are by Fischer, instrumentation is by Rosemount.

electronic intermittent pilot ignition Surface heating area, 83.4 Sq. Ft. Gas connection is 1.25", water inlet and outlet are 2", and pressure relief line is 1" Flue size is 12".

Single Use Fermenter

• 5:1 Turndown Ratio, 3:1 Height to Diameter ratio.
• Jacket area 7.77 Sq. Ft., Jacket volume 10.85 liters
• 4 Tank Baffles, Internal impeller 2 HP drive motor with 5:1 Gear reduction
• Max rotation speed 375 RPMs. Internal Finish: Buff Polish. External Finish: Buff Polish .

About Equipment #99990

Some basic information here.

This is a heading 2

Features:

Check out these features.

• Feature 1

• Feature 2

  • Feature 2-a
  • Feature 2-b
  • Feature 2-c

• Feature 3

That about wraps it up. Here's an edit link.

Wet Grinding Media Mill water cooled grinding chamber Batch size 200 to 1000 liter capacity closed design grinding chamber,axial flow. Mechanical Seal on shaft, with Teflon grinding discs for agitating the grinding media 50 HP motor, 3/60/230/460 volt Class1 Groupd D

Mikro Atomizer Rated for 6,000 rpm. Capable of handling capacities from 100 to 1000 lbs/hr, dependent on the material, this machine handles 3 functions in one machine. Pulverizes, air classifies and conveys the material.

• sanitary reactor body,
• Wall thickness: 0.25" thick side wall, 0.220" thick top head, 0.218" thick bottom head
• Sanitary construction, vessel and jacket are insulated and covered with a SS shroud.
• Previously used for creams and lotions processing.

jacketed rotary vacuum paddle dryer safe operating pressure of vessel atmospheric/vacuum 3000 liter with rotary union joint top mounted dust filter, bottom discharge with valve,

Octagonal blender/mixer, with a Mirror Polish internal finish. Designed with GMP and sanitary construction, 625" shell diameter 615" shell length 2.5" shell thickness 250" Cone length, 2.5" cone thickness 6" bottom butterfly valve.

• This is a bare reactor

• 12" diameter-ASME stamp for Jacket Only Link Belt HP rated 10’
• Vessel rated for 3psi +/- (vacuum)
• Manufactured by Gale Process Solutions (legacy Bethlehem Corporation/Advanced Thermal Solutions) Size: 1208.
