Manufactured by Estrella AG in Ettingen, Germany Packed column consisting of (3) Clamped mid sections, each 2.000 mm long x 788 mm inside diameter, openings each section: (1) NW 150, (1) NW 50; (1) clamped dished top, 1.120 mm long x 788 mm inside diameter

600mm inside diameter x 14.200mm overall height glass packed column. Manufactured by Schott Schleiffer Chemie-Technik in Switzerland Number of main parts: 13 Number of glass middle sections: 11 Glass cover top height: 400mm Glass cover top inside diameter: 600mm Glass cover top openings: (1) NW 200, (2) NW 25 Glass cover bottom height: 300mm Glass cover bottom inside diameter: 600mm Glass cover bottom openings: (1) NW 100 First middle section height: 600mm First middle section inside diameter: 600mm First middle section opening: (1) NW 80 Second middle section height: 1.500mm Second middle section inside diameter: 600mm Second middle section openings: (2) NW 50, (2) NW 25 Third middle section height: 1.500mm Third middle section inside diameter: 600mm Third middle section openings: (3) NW 50 Fourth middle section height: 1.500mm Fourth middle section inside diameter: 600mm Fourth middle section openings: (2) NW 25, (1) Fifth middle section height: 1.500mm Fifth middle section inside diameter: 600mm Fifth middle section openings: (2) NW 25 Sixth middle section height: 600mm Sixth middle section inside diameter: 600mm Sixth middle section openings: (1) NW 80 Seventh middle section height: 1.500mm Seventh middle section inside diameter: 600mm Seventh middle section openings: (2) NW 50, (2) NW 25 Eighth middle section height: 600mm Eighth middle section inside diameter: 600mm Eighth middle section openings: (1) NW 150 Ninth middle section height: 1.500mm Ninth middle section inside diameter: 600mm Ninth middle section openings: (2) NW 50, (2) NW 25 Tenth middle section height: 1.500mm Tenth middle section inside diameter: 600mm Tenth middle section openings: (2) NW 25 Eleventh middle section height: 1.200mm Eleventh middle section inside diameter: 600mm Eleventh middle section openings: (1) NW 150, (2) NW 100, (1) NW 50, (2) NW 25 Included items: support pipe construction, flanges, connection pieces, ceramics pall ring packing material, and many glass accessories.

pressure -1/1.5 bar@ -25/+200 deg C

Zirconium/Alloy 59 packed column design pressure 5 bar + FV @ -20/205 deg C, 14580mm straight side, top section is 1350mm diameter x 7089mm straight side thickness is 6mm to 7.9mm, 4549mm high packing section, bottom section is 1.7m diameter x 7.9m straight side thickness 6mm, 4.4m high packing section, packing is glass filled polypropylene, also includes c/steel top platform and ladders

12 stages agitated extraction column R25/4 (75-375 infinitely variable) Double mechanical seal, type Crane 109/109, Driven by a 0.25kW electrical motor manufactured by BBC type eQUx71MA4, 3~/50Hz/220-380V/1400rpm EX proof (ExeG3) (2) bolt dished heads

total height 36530mm, column made up of (7) clamped sections; section 1 = weld dished top head, 1099mm straight side, 1.6m total height, section 2 = 4265mm straight side, section 3 = 4265mm straight side, section 4 = 1070mm straight side, section 5 = 3600mm straight side, section 6 = 3600mm straight side, section 7 = bottom head, with 4000mm straight side, 4475mm total height., TUV certified

(1.4435) tray column with sump tank sump tank 1.1 bar @ 102 degrees C (1270 liter), 600mm diameter x 8700mm total height, (33) internal 316L stainless steel Varioflex valve trays, approx 200mm spacing, column in 3-sections ( 2-sections 2420mm high, 1- section 2260mm high), column with (1) 26.2 square meter 304 stainless steel (1.4301) tube and shell vertical condenser, manufactured by GIG, design pressure tube side 6 bar @ 35 degrees C, shell atmospheric @ 64 degrees C, (194) 17.2mm diameter x 1.2mm thick x 2.5m long 304 stainless steel tubes, 4 pass tubeside, single pass shell side, 419mm diameter 304 stainless steel shell, condenser fits on to the top of the column, (2) 3.5 m3/hr @ 34m head 316 stainless steel centrifugal pumps, type NCL oh 32/165, manufactured by Dickow Pumpen, 2.1 kw, 2900 rpm, EX design, mounted on a baseplate

vertical column system

fully insulated and clad

system includes: (1) 40 square meter 316L (1.4404) stainless steel tube, head and shell vertical heat exchanger, CE0036, manufactured by Sulzer, type NK 40m2, max allowable pressure tube side -1/6 bar @ -10/200 degrees C (265 liter), shell -1/3 bar @ -10/200 degrees C (550 liter), (192) 25.4mm OD x 2.5m long 316L (1.4404) stainless steel tubes, multi-pass tube side, 638mm diameter 316L (1.4404) stainless steel shell, 3062mm overall length, (2) 316L (1.4404) stainless steel flat heads

distillation column with reflux splitter and separator tank Top head is a 3" to 1.5" concentric reducer Includes a reflux splitter and separator tank

tray/distillation column design pressure 3.2 bar + vacuum (15500 liter) (23) 316Ti stainless steel (1.4571) internal single flow sieve trays with weirs, 400(1000)mm tray spacing,

316SSTi / 1.4571 SS

Extraction column

Wth Lightnin agitator drive Model 82S

7,5 V, 5 KW drive, agitator Model R 100, 7 levels with each 6 adjustable agitator blades, diameter 381 mm,

max rotation 137 Rpm,

mechanical seal on shaft Style C, Code / 3.

Total 6 cubic feet (5 cubic meters) clear glass

Schott glass distillation packed column system each 1m high with glass rasching ring packing material 2m total packing height, system includes (3) 2.5 square meter glass condenser, (1) glass receiver and (1) empty column section.

• 240 Sq. Ft
• 316 stainless steel packed column with reboiler .
• top mounted horizontal U-Tube reboiler, 316 SS tubes, 316 SS tube sheets, CS heads, 316 SS shell, Shell side rated for FV/15 @ 365 degrees F., tube side rated for 75 psi at 365 degrees F. 210 straight tubes, 0.75" diameter x 16 Ga wall x 72" long. 4 pass.
• Shell = 0.25" thick, heads =0.3125" thick

• vertical packed stripper column NB # 360
• Designed for structured packing.

600/700mm (~24"/27.5") diameter x 8700mm (~29') high Methanol Recovery column with 600mm diameter x 1850mm length (including carbon steel feet) bottom section, openings bottom: (1) DN50, (1) DN80, openings side wall: (2) DN25, (1) DN50, (1) DN65, (1) DN300, (4) DN80 sight glass, with 600mm diameter x 1850mm length middle section, openings side wall: (4) DN25, (2) DN80 sight glass, with 600/700mm diameter x 440mm length reduction section, openings (1) DN25, (1) DN50, with 700mm diameter x 2000mm length middle section, openings side wall: (4) DN25, (2) DN80 sight glass, with 700mm diameter x 2000mm length top section, openings side wall: (4) DN25, with 700mm diameter x 550mm high top cover, openings (3) DN25, (1) DN32, (1) DN250, including (1) 700mm diameter sieve ring, (1) 600mm diameter sieve ring, (2) 600mm diameter parts

R-H Grid tray (fixed valve) column (19) R-H grid (fixed valve) spaced at 2' 6" apart Vertical orientation

Heads are 0.180" thick

packed column Packed with Koch-Glitsch Fleximax 400 rasching rings in 304 SS 17' 6" total packed area on
gas injection packing support

Heads are 0.180" thick

Shell thickness 0.25" /0.1875. Head thickness 0.1875" minimum. Internal coil rated for 100 psi at 250 degrees F. (306 SS coil) 25 Glitsch Ballast trays type A-1 With OSHA ladders and platforms.

(2) 3.6m high packing sections, type of packing was Raschig rings (not available) 8mm thick carbon steel shell and flat heads with 0.76mm thick Tantalum lining, (2) 2mm thick Tantalum distribution plates, (2) 2mm thick Tantalum support plates

Heads are 0.180" thick

Column has (2) clamped straight sections 2 x 1.500mm long and 2 x 600mm diameter outside, volume of both sections 803 liter, clamped dished top section, 500mm long x 600 outside diameter, volume 97 liter and bottom section, 730mm long x 600 outside diameter, volume 137 liter. Total weight of the column is 930kg

Column has (2) clamped straight sections 2 x 1.500mm long and 2 x 600mm diameter outside volume of both sections 803 liter clamped dished top section 500mm long x 600 outside diameter volume 97 liter and bottom section 730mm long x 600 outside diameter, volume 137 liter. Total weight of the column is 900kg.
