weld flat top weld coned bottom approx 200mm diameter central screw,148-1400 rpm150mm bottom outlet

15 ton/hr stainless steel horizontal conical continuous mixer with integrated nozzles for adding up to 3 components into the powder, for mixing and agglomerations pocket wheel / chain (2) trunnions, additional small mixing screw on the powder outlet to add another powder for finishing

twin shaft wad mill (pug mill) with a removable 304SS cover 1/8" thick lining Twin chrome plated mixing shafts, 5" diameter with chrome plated blades, with a CS compacting tapered screw discharge on the end of each shaft . Tapered screw sections are 14" diameter x 36" long, feeding a single 9 3/4" wide x 6" high 304SS lined discharge chute. With an air operated automatic wire cutter on discharge end of machine to cut extruded clay. Screw shafts driven through a 25.38 ratio shaft mounted reducer Motor rated for 230/460 Volts

turbolizer Size 661-K min 382 rpm 14" dia x 42" long chamber Drop door style. Packing gland on shaft.

stainless steel/rubber vertical continuous mixer and agglomerator 3~/330-440V/2946rpm.

25 Liter Double Shaft Kneader Mixer with 1.4306 s/steel Double wall jacket internal -1/+0,5 bar hydraulic drive

15 ton/hr stainless steel horizontal conical continious mixer with integrated nozzles for adding up to 3 components into the powder, for mixing and agglomeration spocket wheel / chain driven (2) trunions, additional small mixing screw on the powder outlet to add another powder for finishing

Twin barrel mixer/processor Two 8" barrels input rpm 778, output rpm, 105

direct driven by BBC Brown Boveri Motor: 335-440 V included a motorized fan

ko-kneader. 8" dia x 10' long kneading chamber. Cored shaft.

ko-kneader kneading chamber. Cored shaft, jkt chamber

Cored shaft, jacket chamber. No motor available.

Type: Twin screw jacketed mixer 316 stainless steel shafts with scraper type removable blades. motor with cooling fan Unit with removable top, bottom and ends. Spare blades. Openings: feed 1-95mm; discharge 140mm x 75mm; 34-25mm on jacket.

turbolizer. Unit driven by Reeves varidrive 50 HP, max 1222 rpm, min 132 rpm. 14" dia x 42" low chamber. Drop door style. Packing gland on shaft.

****Buss kneader Oil pressure 6 bar @ 250 deg C water pressure 20 bar @ 200 deg C SS screw cored for steam heating, screw 140mm dia screw casing w/hinge (2) heating zones, (1) cooling zones. Screw driven by Miller Type KLA841-4, 14.8-65 KW, 500-2200 rpm, 3/50/380 volt varispeed motor via Type H6/R150, 14:1 ratio, Unit w/SS screw conveyor Chain driven by 3 HP varispeed motor. Mixer openings: feed 1-5 1/2"; discharge 1-5 1/2"; jkt connections 7-1/2", 4-1/4".

continuous Solidaire non-jkt paddle mixer. Agitator is lined w/small flat adjustable pitched paddles. Outboard bearings on shaft. Openings: top 2-13 1/2", hd 1-4". No drive w/unit.

Zig Zag blender, continous spray nozzle blender. Rated 60 LBS/CuFt. 19.81 rpm drum rotating speed. With feed and discharge hoods designed for nitrogen purge.

Unit driven by Reeves varidrive 50 HP, max 1222 rpm, min 132 rpm. 14" dia x 42" low chamber. Drop door style. Packing gland on shaft.

continuous plastic foam mixer. Double mech seal on shaft. Mixer enclosed in sound proof housing.
