15 Kg bed dryer system Heating capacity 68000 BTU/hour Steam pressure 3 bar air (compressed) 6 bar with removable trolley Drying chamber in (3) sections: (1) 21 1/2" diameter x 12" straight side; (1) 21 1/2" diameter x 27 1/2" straight side; (1) 21 1/2" diameter x 27 1/2" straight side x 15 1/2" diameter (cone shaped). Hydraulic bin closure, (2) trolley for bin removal Unit with air filter, manufactured by HSE, Type 5.5KW-SCF, serial #2620 Motor: 3 phase (3) control panels, (1) built-on unit Top mounted fan driven by 4.5 KW, 3/50/440 volt, 2915 rpm non-flameproof motor.

GMP grade sanitary stainless steel construction order number V4635 vibration bed is belt driven electrical motor : type D160LA-6 , ExII3G, EExIIT4 system included with (1) 7m³ (1.4571) stainless steel silo manufactured by Scholl Switzerland AG order number 502838 serial number 201282 pressure rated -0,1/0,6 bar @ -20/120 degrees C (total volume 7100 liter) openings on top: (3) DN40, (1) DN50, (1) DN80, (1) DN100, (1) DN200, (1) DN500 manway cover; with (1) 4500 m³/h (1.4571) stainless steel radial fan manufactured by Reitz type KXE100-008030 serial number 166417 shaft rating maximum 20.17kW @ 3000rpm with frequency converter fan is coupling driven by a 37kW electrical motor, manufactured by Felten & Guilleaume, type CD200L2-2, serial number 415274001H, 3~/50Hz/400-690V/2955rpm, ExII2G, EEXdeIICT4, mounted on carbon steel baseplate; with (1) 1.2m² (1.4404) stainless steel plate heat exchanger, manufactured by Barriquand, type IJS, serial number 26361E, pressure shell side 2bar @ 200 degrees C (volume 16 liter), pressure plate side -1/6bar @ 200 degrees C (volume 2 liter), openings plate side: (2) DN25, openings shell side: (2) ½” (2) DN80; with (1) 44.3m² (1.4404) stainless s teel plate heat exchanger, manufactured by Barriquand, type IJMASC, serial number 26362E, pressure shell side 2.9bar @ -35/100 degrees C (volume 335 liter), pressure plate side 10bar @ -35/50 degrees C (volume 165 liter), openings plate side: (2) DN80, openings shell side: (1) DN25, (2) DN250; with (1) 12.7m² (1.4404) stainless steel plate heat exchanger, manufactured by Barriquand, type IJS, serial number 26359E, pressure shell side: 2 bar @ -20/200 degrees C (volume 190 liter, pressure plate side: -1/6bar @ -20/200 degrees C (volume 25 liter) openings plate side: (2) DN50, openings shell side: (2) ½” (2) DN250; with (1) 3.6m² (1.4435) stainless steel shell and spiral tube condenser, manufactured by Züricher Apparatebau, order number 105074, serial number 242, pressure tube side: 7.8bar @ -30/200 degrees C, pressure shell side: -1/6bar @ -30/200 degrees C, 500mm diameter x 1039mm length; with (1) 6m² (1.4404) stainless steel shell and tube condenser, manufactured by Züricher Apparatebau AG, order number 502637, serial number 1789, pressure shell side: -1/6bar @ -45/200 degrees C (volume 74 liter), pressure tube side: -1/8bar @ -45/200 degrees C (volume 45 liter), openings tube side: (2) DN50 (1) DN100, openings shell side: (2) DN40; with (1) 4.7m² (1.4404) stainless steel plate heat exchanger, manufactured by Barriquand, type IJS, serial number 26360E, pressure plate side: -1/6bar @ -20/200 degrees C (volume 8 liter), pressure shell side: 2bar @ -20/200 degrees C (volume 102 liter) openings plate side: (2) DN25, openings shell side: (2) ½” (2) DN150; with (1) 4m³ (1.4435) stainless steel vertical agitated tank with half pipe coil jacket, manufactured by WAFAG, order number 89536, serial number 8379, pressure inside: -0.32/4bar @ -30/200 degrees C (volume 4340 liter), pressure jacket side: 7.5bar @ -30/200 degrees C (volume 176 liter), with a (1.4571) stainless steel 3-blade propeller agitator, order number 503049, with mechanical seal, manufactured by Burgmann, type M481K-D20/60, pressure -1/16bar @ -30/200 degrees C, with 3 liter lubricator, manufactured by Aerni, type A-139, pressure 26bar @ 200 degrees C, agitator is driven by a gear, type RXF97D4/P, gear is belt driven by a 7.5kW electrical motor, manufactured by ABB, type 132M-4, 3~/50Hz/400V/1450rpm, EExdeIIBT4, openings top: (1) DN500 including (2) DN100 sight glasses, (1) DN600 including (2) DN50 and (1) DN300, (2) DN100, (3) DN200, openings bottom: (1) DN65, openings half pipe coil: (2) DN40, mounted on (4) lugs; with (1) 316L stainless steel vertical cyclone separator, manufactured by Ventilex, order number 502845, openings top: (3) DN25, (1) DN200, (1) DN300, openings side wall: (1) DN300, with cone bottom, mounted on (4) lugs; with (1) 14m³/h by 20m head (1.4408) stainless steel caned motor pump, manufactured by Ruetschi, type SMN-G5-160SR5E16-2V, order number 502627, driven by a 5.6kW electrical motor, type SR5E16-2V, 3~/50Hz/400V/2930rpm, EExdeIICT4; with (1) 2000mm diameter (1.4404) stainless steel vertical dust filter, manufactured by Ventilex, order number 502846, bolt dished top and weld dished cone bottom, 2000mm diameter x 3000mm straight side (4580mm overall length), (52) 316L stainless steel inlets, 145mm diameter x 2500mm length, openings top: (2) DN25, (3) DN100 sight glass, openings side wall: (2) DN300, (2) DN 200 sight glass, (4) DN50, (8) DN15, (7) 1”, opening cone side wall: (1) 500mm diameter manway cover, opening bottom: (1) DN200, mounted on (2) lugs; with (1) 316L stainless steel discharger valve, manufactured by Matcon

Glatt Fluid Bed Dryer perforated bed 400/690 volt Capacity 200 liter bin

continuous vibrating fluid bed dryer perforated fluid bed openings: feed: 1-600mm, powder discharge: 1-300mm, top: 1-750mm manway, 1-450mm, straight side: 3-450mm manways, bottom: 2-625mm each with a 625mm diameter x 980mm straight side s/steel tank dryer mounted on carbon steel frame with springs

Note: Drawings show Mills, we did not get some of them. Suitable for installation in Hazardous areas.
Typical working volume is 30-225 liters based on the allowable product density of 1500 kg/m This fluid bed dryer was designed for Pharmaceutical service and features sanitary design and clean in place With wet and dry loading ports, internal lighting, and sample ports Air handling is custom manufactured by ZAir, Type SKG-4 Manufactured of 316 SS construction This unit is complete with all filters, and accessories High shear granulator (IPP Stock # 233969) is available at additional cost. 100 kg

100kg system includes a filter housing, control panel, body (3) sections chamber top dish with cover 240mm high (total high with railing 560mm) x 1.180mm inside diameter first section 2.030mm long x 1.180mm inside diameter, second section 2.270mm long x 1.180mm inside diameter, third section 2.030mm long x 1.180mm inside diameter, with one product bowl High performance fan, type RHS1U280MBGXGR360, serial number 34117

Air circulation fan is 12,5 KW, 50/220/380 Volt @ 3000rpm.

120 kg Aeromatic Fluid bed dryer/ coater Com.No. 88 91 42 Bowl volume is 240 liters System utility requirements are: Steam maximum 150 kg/h @ 6 bar g chilled water maximum 5.4 m3/hr 27 degrees C inlet temp compressed air 45 Nm3/hr @ 6 bar Motor: 3 phase Electric System accessories include a heating coil with 10 bar housing pressure for air heating, air inlet filters and cooler, 22 Kw system Fan rated for 10 bar/s, Airflow 0.25-0.83 m3/s at static pressure 10.00 pa; product filter with shaker discharge, and a bin lift system system Fan rated for 10 bar/s Airflow 0.25-0.83 m3/s at static pressure 10.00 pa product filter with shaker discharge, and a bin lift system Electrical controls available with unit

vibrating Fluid bed dryer system All contact parts are 1.4301, with CS frame Fluid bed size 480 mm wide x 6400mm long, overall 640 mm wide x 7356 length Covered drying bed with a vibrator system type SVi450/6n, driven by (2) Vibra-Maschinenfabrik electrical motors second motor: serial number 133138, 1,1kW / 50Hz/220-380V @ 940rpm System includes a GEA heat exchanger, a 5,25kW max. 3.000rpm Polrich blower type AS 56/RU315R/GR90MR driven by an electrical 7,5kW motor type KMER132Sx2ACP, serial number VDE0530, 3~/50Hz/380-660V @ 2.860rpm

300 kg special Vitamin-A-Pulver with cyclones heater and cooler and de-dusting system Filter housing is 1600 mm diamter, 2.5mm thick with (59) bags at the bottom of the filter housing is a tapered section that has a buterfly valve controling flow into the container bottom Hopper bottom is 304 stainless steel (1.4301), 1190 mm diameter x 640 mm straight side with a 660 mm deep cone with a 660 mm deep cone. With separate heating cooling box, rated - heater rated 320,000 Kcal/hr @ 5 atu, air cooler rated 400,000 kcal/hr @ 0/4 degrees c. Main fan is rated 14,000 CuM/Hr, 2900 upm, driven by a 35.8 KW, 3 phase 50 cycle, ExeG3 rated motor.

300 kg Glatt Fluid bed dryer special Vitamin-A-Pulver with cyclones heater and cooler and de-dusting system Filter housing is 1600 mm diamter, 2.5mm thick, with (59) bags, at the bottom of the filter housing is a tapered section that has a buterfly valve controling flow into the hopper bottom with a 660 mm deep cone Hopper bottom is 304 stainless steel (1.4301), 1190 mm diameter x 640 mm straight side with a 660 mm deep cone With seperate heating cooling box,rated - heater rated 320,000 Kcal/hr @ 5 atu, air cooler rated 400,000 kcal/hr @ 0/4 degrees c. Main fan is rated 14,000 CuM/Hr, 2900 upm, driven by a 35.8 KW, 3 phase 50 cycle, ExeG3 rated motor dedusting system rated 15000 CuM/Hr.

load weight 300 kg special Vitamin-A-Pulver, with cyclones heater and cooler and de-dusting system Filter housing is 1.6m diamter, 2.5mm thick, with (59) bags, at the bottom of the filter housing is a tapered section that has a buterfly valve controling flow into the hopper bottom. Hopper bottom is 304 stainless steel (1.4301), 1190 mm diameter x 640 mm straight side with a 660 mm deep cone. Bottom hopper mounted on 4 legs with wheels. With seperate heating cooling box, rated - heater rated 320,000 Kcal/hr @ 5 atu, air cooler rated 400,000 kcal/hr @ 0/4 degrees c. Main fan is rated 14,000 CuM/Hr, 2900 upm, driven by a 35.8 KW, 3 phase 50 cycle, ExeG3 rated motor

static fluid bed dryer system reference number K5/8-88-001A Bed temperature 100 - 120 degrees C Bed with (2) pneumatic operated hinged weir plates weir height range 140mm - 250mm Dryer chamber approx. 920mm wide x 5.8m long, chamber with 690mm wide x 1.3m high hinged inspection door Openings: drying air inlet 900mm, cooling air inlet 300mm, recycle 750mm, exhaust 500mm System consists of (1) air heater, aluminium fins with carbon steel tubes, rated 250 psi, (1) centrifugal cooling air fan, manufactured by Fans & Blowers, Ltd, serial # 6331 Motor: 3 phase (1) carbon steel cyclone, 1000mm top diameter x 1700mm straight side x 2000mm cone. Bottom outlet 350mm, straight side 760mm x 200mm, (1) exhaust/wet air fan, belt driven by 15 kw, 3/50/415V, 2940 rpm motor. (1) main dryer fan belt driven by 75 kw, 3/50/415V, 1470 rpm motor (no motor).

5 Kg Aeromatic spray granulator system Rated 6800 kcal/hr Fan driven by 3.4 PS Drying product bin 700mm dia top, 270mm dia btm x 650mm deep Control panel w/switches Including steam heater, valve, duct

250 Kg Aeromatic Fluid Bed Dryer / Aeromatic fluid bed spray granulator Aeromatic type STRE 0, 86.20 H food grade high performance fluidized bed drying system rated 109,200 Kcal/hr Pressure shock resistance 2,0 bar, vessel volume 610 liter, 0,86m² The system includes dryer, powder filling station, pneumatic system, air and product filters steam air heater (CS) rated 5,5 bar @ 200 degrees C Cooler, and dry product containers Originally used for flour and starch drying in a food processing plant Rated for Flour: inlet moisture 14-16%,outlet moisture 7%,drying temp 70 C. Starch: inlet moisture 15-17%,outlet moisture 5%,drying temp 70 C.

250 Kg Fluid Bed Dryer batch type Steam heater rated 140000 Kcal/hr steam Motor: 3 phase 220/380 volt With (2) product bins 1200mm upper diameter, 800mm lower diameter, sanitary polished Drying chamber 3.5m high (11'6") x 1.2m diameter (48") With a control panel indicating air temperature, timers, intervals, vibration indicator of dust collector

15-30 Kg, 45 liter bowl capacity, 52000 K/hr steam heaters, compressed air @ 6 bar, Air warming range -10 degrees C to +70 degrees C, Electrics motor

Fluid Bed Dryer Spheronizer perforated bed electrical motor Motor: 3 phase type KPER200L4-TWS

60-180 Kg Rated 467200 Kg/hr air flow with a Control panel, steam heater, and (2) sanitary product bins 1100/750mm dia x 500mm deep

200-400 Kg Designed drying 200 to 400 Kg batches Housing type 105.4, made of 304SS Product bin type 202.3, 780 liter volume, 304SS 1630mm top dia, 1230mm btm dia x 880mm conical section. W/(2) 200mm inlet for adding products, 1-500mm manway w/cover, 1-200mm sight glass, 200mm x 60mm oval sight glass. Btm section below bin 1230mm dia x 500mm deep. Includes air inlet 500mm dia. Dryer body and product bin are mtd on steel stand w/legs, 1550mm x 1050mm x 3900mm high. Drying chamber has (2) explosion doors. Product filling nozzles for granulation are Type 2001.1, 304SS. System includes second product spray system Type 701, nozzle rated 4 liter/min. Feed pump rated 0.01 to 11 liter/min @ 2.5 bar Variable speed drive motor. XP rupture disc. W/centrifugal fan Type 5012, made of CS w/epoxy lining, rated 180 cbm/hr @ 500mm WA @ 2900 rpm. Steam coil rated 270,000 kCal/hr @ 6 ATU. Fine dust filter, Type 403.1, 23 sq meter filter area. Product empties from the btm of dryer into Frewitt (Switzerland) granulator, Type MGWI-624, 304SS, SN 0677449, feed 350mm x 500mm. . Driven by 1.1 KW, 3/50/220/380 volt, 1390 rpm motor, couples to variable speed gear reducer, Type R4S-1062-11-4, SN 304531, rated inlet speed 56/280 rpm, outlet speed 89/30 rpm. connecting ducts

150 Kg 110,000 Kcal/hr steam heating with dust collector bags and bag hanger ring

25 Kg fluid bed dryer with steam heated jacket/battery flameproof motor with (1) 24" diameter x 13" deep bin Complete with socks, temperature gauge and bag vinch (manual)

fluid bed dryer system 50-250 Kg With cylindrical chamber the rupture channel 950mm dia x 2345mm high Filter housing rated 2 bar and has volume of 1638 liter. Filter area 13 sq meter. W/(2) 304SS product bins, rated 2 bar, w/volume of 340 liter, base area of bin 0.45 sq meter, 1100mm/750mm dia x 500mm deep, w/60mm x 270mm sight glass. Fine dust filter 19.3 sq meter. Steam air heater rated 467,2000 Kg/hr with air inlet of -10 deg C and outlet of +80 deg C. Steam pressure 4 bar. Fan rated 1.2 cbm/sec, static pressure 5000 N/sq meter, rated 8.5 KW @ 2900 rpm. With hydraulic operated bin loader

vibrating fluid bed dryer vibratory mechanism 304 stainless steel perforated fluid bed openings: feed: 1-800mm, powder discharge: 1-635mm, top: 1-700mm manway, 2-600mm, 1-250mm, straight side: 3-500mm manways, bottom: 2-625mm, 1-500mm manway dryer with springs but no frame

• Max Capacity 1600 kg
• Stainless steel highly polished Glatt fluid bed dryer system, manufactured by Glatt AG (Switzerland), nominal capacity 500 kg, max capacity 500kg, approx. 3m diameter drying chamber, stainless steel bowl, dimensions 3m top diameter x 1.1m high x 1.1m bottom diameter, bowl fixed to a lifting mechanism, internal filters with hoist, (2) inspection doors for filter, suppression system, system include: blower, dust filter, air handling unit, control panels, duct work and other ancillaries
