Nash SC2SS Vacuum pump, with vapor recovery system Test # 90Y002 The system includes the following equipment; a vacuum pump, two heat exchangers, a separating tank, and seal pots. The direct drive vacuum pump, is manufactured by Nash, size SC2SS, Pos. 4 ,Vac, rated 200 cfm @ 5-20" Hg. The vapor exchanger is a 30 sq. ft., all 316 SS, horizontal heat exchanger manufactured by Industrial Process Equipment corp., Model # 2ST8-60, Serial # 105-641A National Board # 988 It’s shell and tubes are rated for 150/FV The condensate chiller is a 10 sq.ft., 316SS tube bundle, 316SS heads, with CS shell, horizontal heat exchanger and is also manufactured by Industrial Process Equipment Corporation. Serial # 1056413, and National Board # 989, Rated for 150/FV psi in the shell and tubes. The dual seal pot arrangement, with Nitrogen purge is provided by Duramettalic, Canada/Condex Heat Transfer Corp. Serial # 91-3-4146 & 4179, and rated for 400 psi at 400 degrees F. Both have level sight glasses and N2 purge line with regulator and Liquid make up valves. The units 316 SS separator, is manufactured by Jenco, Serial # 91-1327, National Board # 525, and rated for 30/FV at 350 psi. The separator tank also has a liquid level sight glass. The vapor inlet line is 4" flanged, and separator outlet is 1”. Automatic valves for liquid flow control are provided by Fisher and El-O-Matic, and the vapor contact piping is 316 SS. System includes all DP cells, RTD temperature probes, and pressure gauges. Designed to be used in a hazardous atmosphere, skid has a 60 amp Square D breaker, and explosion proof switches and controls.

SIHI vacuum skid consisting of (1) 140m3/hour carbon steel liquid ring vacuum pump 3 bar (1) 4 liter carbon steel separator vessel, pressure -1/3 barg @ 120 degrees C 273mm diameter x 1020mm total height, (1) 9.9 square meter carbon steel condenser, pressure tube side 6 barg @ 250 degrees C, shell -1/3 barg @ 250 degrees C,

System with Knock out pot and heat exchanger. 25 Gallon 304 SS, receiver by J D. Cousins, rated for FV 75 psi at 350 degrees F. 30 Gallon condensate receiver, by TMT, Carbon steel, vertical, 12.75" x 38". 69 Sq.Ft. Hastelloy tube, tube sheet and head, CS shell, vertical heat exchanger shell rated for 100 psi at 300 degrees F, tubes rated for FV/100 psi at 300 degrees F.

Part number: BN117 4 Additional equipment: vacuum receiver SIHI stock number 900256, mechanical seals on shaft with vacuum receiver

@ 5mm Hg oil seal high vacuum vacuum pump system 12 gallon receiver, and seperator.

water seal vacuum pump, close coupled to a 7.5 HP motor.

high vacuum rotary Pump, with booster.

• Type number: 89509/E260US
• Booster drive: 10HP Flange size of booster unit is 6" in and 6" out. Flange size of vacuum pump is 3" in and 3" out.
• Booster motor: 10 hp, 3510 rpm, mounted on a 215 tc frame (230/460v 24/12a)
• Spare booster and pump included, recently overhauled, on pallets, still in shrink wrap.

@ 5mm Hg oil seal high vacuum vacuum pump system 12 gallon receiver, and seperator.

system included (2) approx 500 m³/h 316 stainless steel single stage liquid ring vacuum pumps, first pump, type SIHI LPHA-50115 / BN 135 42 0, Motor: ex proof (G3), second pump, type SIHI LPH-50115, serial # D-2879337, driven by 10.0 kW, 3/50Hz/500 V/1460 rpm, mfd LOHER electrical motor, ex proof (G3), (1) 4.2 square meter 316 stainless steel (1.4571) shell and tube heat exchanger, serail # 7032/224, manufactured by GESSNER GmbH Germany, rated shell side -1/7 bar @ 250 degrees C, volume 43 liter, rated tube side -1/7 bar @ 250 degrees C, volume 34 liter. (1) 260 liter s/steel reciever, mfd by WERK OFFENBACH, serial # 282 rated -1/6 bar @ 250 degrees C .

SIHI vacuum skid carbon steel liquid ring vacuum pump 33 mbar 380/660 volt (1) 60 liter carbon steel separator vessel, pressure 3 barg @ 120 degrees C (1) carbon steel condenser, 170mm diameter x 2130mm long, no nameplate

vacuum skid with booster pump consisting of (1) 300 m3/hr Hedrich 2-stage vacuum pump (2) Hedrich type R0-5001 booster pump, fabrik #3205 (1) 6.6 square meter 316Ti (1.4571) stainless steel tube and shell horizontal heat exchanger, manufactured by Hedrich, pressure tubeside 10 bar @ 110 degrees C, shell side 10 bar @ 110 degress C, (1) approx 15 liter stainless steel vertical pressure tank, manufactured by Hedrich, weld dished top and bottom,

Equipment included:

• Two liquid ring vacuum pumps (600 CFM each)
• Water seal
• 2 x 2 rated for 4" Hg at 658 mmbar absolute
• Each pump contains a Graham 14" separator
• Rated for FV/30 psi at 500 degrees F
• NB # 1874, 14" diameter x 43" straight side
• Each pump includes a 24" Graham surge tank
• Rated for FV/30 psi at 500 degrees F
• NB # 18069, size 24" diameter x 24" straight side, serial # 76442-4
• Each pump is equipped with a Graham seal water cooler
• 22 Sq. Ft. 316 SS plate and frame heat exchanger with 316 SS plates and 1" inlets and outlets
• Heat exchanger rated for Hot side 125 psi at 150 degrees F, cold side rated for 125 psi at 150 degrees F
• NB # 18065, serial # 76442-2
• Includes piping interconnecting on the skid

vacuum pump system system included (1) 580 m³/h s/steel double stage liquid ring vacuum pumps, type SIHI LPHA-65320 / BN 135 42 0 ex proof (T3), (1) 4.2 sqm s/steel (1.4571) shell and tube heat exchager, serail # 7032/223, mfd by GESSNER GmbH Germany rated shell side -1/7 bar @ 250 degrees C, volume 43 liter, rated tube side -1/7 bar @ 250 degrees C, volume 34 liter. (1) 150 liter s/steel reciever, mfd by WERK OFFENBACH, serial # 293 rated tube side -1/6 bar @ 250 degrees C, volume 150 liter; rated shell side 6 bar @ 250 degrees C, volume 10 liter.

liquid ring design with a total recirculation system type 309-302, SIHI Drawing number SV1677. System includes a 4" diameter x 30" long, and a gas/liquid seperator/service liquid tank, CS 20" diameter x 45" straight side, rated 16psi @ -20 to 200 degrees f.

Pressure: 200 mbar With SIHI two stage water seal vacuum pump Typ: SIHI, LPHE 45316 driven by 3.0kW 3/50/380V, 1440 RPM motor. Mounted on unitized base.

150 cfm @ 76mm, oil seal vac pump. Has oil mist separator.

oil seal vacuum pump (Once through-lubricating/Vapor Purge) Single stage design with high vacuum and volumetric efficiency Cooling water required is 0.66 GPM Motor: AC 230/460 V Class 1 Div1 group D

• Bare pump only, no base or stand.

dual stage vacuum system. System consists of Stokes Eagle series dry pump model CDE-180 dry lobe vacuum pump with cooling jacket, all wetted surfaces electroless Nickel coated, With booster blower Stokes model 607-4Mv, Serial # 38750E0598 with all wetted surfaces electroless Nickel coated, driven by 10 hp 3/60/460V, 1755 rpm TEFC motor. Via "V" belt drive.

1 mbar

• Additional pump: 350 m3/Hr @ 33 to 0 mbar, SIHI 316 Stainless Steel liquid ring vacuum pump
• Additional motor: 15 Kw Loher E-Motor, Type DNGW 160LB-04A, 500 Volt, 3 phase, 50 Cycle, 1450 U/min, ExProof CT4
• Additional booster: SIHI Sterling CS Vacuum booster, rated 4000 m3/Hr, 11KW, type WNMY4000, Pump Number D729520106, driven by a 11 Kw Loher E-motor, type DNGW-160LB-04A, 500 volt, 50 cycle, 2930 U/min
• Separator tank: 1.730mm diameter x 2.940 mm long, 110 liter Stainless steel, rated 0,5 bar @ 100 degrees C
• Package dimensions: 2.940 mm long x 1.730 mm wide with separator x 3.315 height over all
• Package weight: 5.200 Kg (including carbon steel frame)

SIHI vacuum skid consisting of (1) 110m3/hour carbon steel liquid ring vacuum pump 30/1100 mbar (1) 6 liter carbon steel separator vessel, pressure -1/3 barg @ 120 degrees C, 273mm diameter x 1.2m high, (1) 2.85 square meter carbon steel condenser, pressure tube side 6 barg @ 120 degrees C, shell -1/3 barg @ 120 degrees C

vacuum pump system 2 stage liquid ring vacuum pump, 33 mbar@2 bar, type LPHA 55320 serial # BN BFK 42 4, pump#D-005187901, openings: 4 x DN 50 PN16 e-motor type DNGW-160LB-04A, motor#3306781, 500V/50Hz/22,8A/15kW/1450 U/min, ex proof (CT4); (1) 14.000 m³/h SIHI c/steel roots vacuum pump with water cooling, type WNMY 14000, serial#A2 XOA OBO, pump# D-72-945-0106, CE confirm, (1)down openig connecting tube: approx: 300 mm diameter,(1) top opening: DN 400 PN10, no motor (1) 4.000 m³ SIHI c/steel roots vacuum pump with water cooling, type WNMY4000 A2 XOA OBO, pump#62 125 0006, CE confirm,,(1)down opening: DN 250 PN16 (1)top opening: DN 250x273 PN10, driven by LOHER e-motor type DNGW-160MB-02C, motor#3272776, 500V/50Hz/16,4A/11kW/2920 U/min, ex proof (CT4); (1) 110 liter s/steel separator @ 0,5 bar@100° C, s/steel (316), mfd by STERLING SAT,

Torr: 0.5 Type: Oil seal vacuum pump Additional features: Base, control panel, oil accumulator tank.

3-stage vac pump/jet system 1st stage: Stokes CS rotary vac pump, Mdl 310-41, SN 87533. W/4" suction and discharge opening. Powered by 2 HP, 3/50/60/208/230/460 volt, 2870/3480 rpm direct coupled motor. 2nd stage: Hick and Hargreaves CS vac jet, Order #CA13305. Nozzle throat dia 5.2mm. 3rd stage: Hicks water ring vac pump. SN H9126, Type SHR2200. 1470 rpm. 2" suction and discharge openings. W/solenoid operated inlet water piping and Burgess Manning water separator on discharge. Powered by 20 HP, 3/60/230/460 volt, 1760 rpm direct coupled TEFC motor.
