Results 14 items found

Available equipment

Showing 14 of 14 matching equipment.

Stock Number: #247250
Dryer-Rotary Vacuum Paddle
Capacity Design: 111.2 ft3
Capacity Working: 88.3 ft3
Diameter: 47.2 in
Temperature: 329 °F
Pressure: 29 psi
Rated for Vacuum: Yes
Heat Transfer Surface Area: 143.2 ft²
Shaft Cored and National Board Stamped: Yes
Orientation: Horizontal
Agitation: Yes
Agitation Seal Type: Mechanical
Dust Collection: Yes
Additional Information: design pressure internal -1/2 bar @ 165 degrees C (3150 liter), jacket 6 bar @ 165 degrees C (105 liter), shaft 6 bar @ 165 degrees C (800 liter), motor is Ex CE II 2G Ex de IIC T4 Gb ATEX, 1-bolt dished end and 1-weld dished end, 1.2m diameter x 8195mm overall length, shaft cored for heating with rotary union joint, Jacket Material: Stainless Steel 304. Jacket Pressure: 87 psi. Jacket Temperature: 329 °F. Jacket Type: Half Pipe/Limpet.
More Details ⟶
Stock Number: #247251
Dryer-Rotary Vacuum Paddle
Capacity Design: 111.2 ft3
Capacity Working: 88.3 ft3
Diameter: 47.2 in
Temperature: 329 °F
Pressure: 29 psi
Heat Transfer Surface Area: 143.2 ft²
Shaft Cored and National Board Stamped: Yes
Orientation: Horizontal
Agitation: Yes
Agitation Seal Type: Mechanical
Dust Collection: Yes
Jacket Material: Stainless Steel 304
Additional Information: design pressure internal -1/2 bar @ 165 degrees C (3150 liter), jacket 6 bar @ 165 degrees C (105 liter), shaft 6 bar @ 165 degrees C (800 liter), motor is Ex CE II 2G Ex de IIC T4 Gb ATEX, 1-bolt dished end and 1-weld dished end, 1.2m diameter x 8195mm overall length, shaft cored for heating with rotary union joint, Jacket Pressure: 87 psi. Jacket Temperature: 329 °F. Jacket Type: Half Pipe/Limpet.
More Details ⟶
Stock Number: #217829
Stainless Steel Austenitic Buss-SMS-Canzler GmbH Rovactor NCE-1000-RD Dryer-Porcupine
Operational Mode: Continuous
Diameter: 19.7 in
Length: 118.1 in
Number of Shafts: 1
Has Jacket: Yes
Porcupine Operating Pressure: 174 psi
Porcupine Operating Temperature: 392 °F
Jacket Operating Pressure: 174 psi
Jacket Operating Temperature: 392 °F
Total Heat Transfer Surface Area: 109.8 ft²
Additional Information: rotating segmented disc dryer 316 stainless steel (1.4571) single rotor with segmented discs and rotary coupling via reduction gearbox mechanical seals on shaft bolted ends drive end top inlet with stainless steel filter fabrik TRF005/043 TUV certified
More Details ⟶
Stock Number: #217828
Stainless Steel Austenitic Buss-SMS-Canzler GmbH Rovactor NCE-0350-RD Dryer-Porcupine
Operational Mode: Continuous
Diameter: 13.8 in
Length: 70.9 in
Number of Shafts: 1
Porcupine Operating Pressure: 290.1 psi
Porcupine Operating Temperature: 572 °F
Jacket Operating Pressure: 290.1 psi
Jacket Operating Temperature: 572 °F
Total Heat Transfer Surface Area: 42 ft²
Additional Information: Buss-SMS continuous rotating segmented disc dryer 3.9 square meter rotor -1/20 bar @ 300 degrees C (22 liter) total useable heating surface 10.7 square meter heated by steam single rotor with segmented discs and rotary coupling via reduction gearbox mechanical seals on shaft bolted ends top inlet with s/steel lump breaker
More Details ⟶
Stock Number: #211713
Stainless Steel 316 Wiped/Thin Film Evaporator
Total Heat Transfer Surface Area: 6.5 m²
Diameter: 900 mm
Height: 4,700 mm
Pressure: 5 bar
Temperature: 250 °C
Internal Condenser: Yes
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Drive Type: Brown Boveri eQU 112 MB4
Additional Information: Short Path wiped film evaporator system with internal condensor includes SS seperator tank Rated 2000 liter 95 liter in the jacket. Top mounted rotor drive with a 3.7 kw, 50 Hz gear motor with mechanical seal on rotor, Graphite wipers on rotor. Evaporator has a side bottom discharge for product. Vessel weight empty, 2600 kg; motor and rotor 800 kg.
More Details ⟶
Stock Number: #211714
158.8 kg/h (350 lb/h) Stainless Steel 316 Wiped/Thin Film Evaporator
Evaporation Rate: 350 lb/h
Total Heat Transfer Surface Area: 6.5 m²
Orientation: Vertical
Diameter: 900 mm
Height: 4,700 mm
Pressure: 5 bar
Temperature: 250 °C
Internal Condenser: Yes
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Drive Type: Brown Boveri EQU112 MB4
Additional Information: Short Path wiped film evaporator system with internal condensrr includes SS seperator tank Rated 2000 liter 95 liter in the jacket. Top mounted rotor drive with a 3.7 kw, 50 Hz gear motor with mechanical seal on rotor, graphite wiper on rotor. Evaporator has a side bottom discharge for product. Vessel weight empty, 2600 kg; motor and rotor 800 kg.
More Details ⟶
Stock Number: #236136
Stainless Steel Austenitic Buss-SMS-Canzler GmbH D-015 Dryer-Thin Film
Heat Transfer Surface Area: 37.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 572 °F
Jacket Pressure: 217.6 psi
Jacket Temperature: 572 °F
Orientation: Horizontal
Shell Diameter: 22.4 in
Shell Length: 141.7 in
Additional Information: jacketed thin film dryer, fabrik #0500/187, shell jackets 15 bar @ 300 degrees C (2 x 38 liter) 569mm diameter x 3.6m, rotor driven by 27kw, 3 phase, 50Hz, 400 volt, 1000 rpm Eexe 11 T2, IP55 motor, rotor speed 310 rpm,
More Details ⟶
Stock Number: #219255
47.6 kg/h (105 lb/h) Stainless Steel 316 Wiped/Thin Film Evaporator
Evaporation Rate: 105 lb/h
Total Heat Transfer Surface Area: 2 m²
Orientation: Vertical
Height: 2,100 mm
Pressure: 0.5 bar
Temperature: 185 °C
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Drive Type: MarelliMotori D5X 160 MA8 B3
Additional Information: wiped film evaporator with carbon steel jacket jackets 10 bar @ 185 deg C, carbon steel jackets on straight side rotor speed 210 rpm, wiper blades with teflon lining, double mech seal on shaft heated length 2120mm wiper blades with teflon lining, double mech seal on shaft rotor belt driven by 3.5 KW, 3/50/380 volt, 750 rpm, IP 44, Exe G3 motor
More Details ⟶
Stock Number: #211618
Stainless Steel 316 Wiped/Thin Film Evaporator
Total Heat Transfer Surface Area: 3.5 m²
Orientation: Vertical
Diameter: 450 mm
Height: 4,250 mm
Pressure: 16 bar
Temperature: 200 °C
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Drive Type: Eberhard Bauer DF 2A43HZ/309
Additional Information: wiped thin film evaporator with external condensor and seperator tank rated 440 liter With top mounted 3.7 KW, 50 Hz gear motor, mechanical seal on rotor, (4) blade rotor with wipers With 2 SqM external 1.4435 SS spiral coil condenser, manufactured by Zurcher, Serial number 630, rated -1/2 bar @ -20 to 200 degrees C in vessel; -1/6 bar @ -20 to 200 degrees C in the coil. Vessel is 419mm diameter x 936mm tangent to tangent, with bolted dished top, dished bottom, and (2) bank of internal spiral condensing coil. Coil and tank are 1.4435 SS.
More Details ⟶
Stock Number: #246466
stainless steel other Hydrogenation Reactor
Capacity (Design): 1,350 gallons
Internal Pressure: 45 bar
Internal Temperature: 329 °F
Jacket Pressure: 145 psi
Jacket Temperature: 329 °F
Orientation: Vertical
Diameter: 40.7 in
Straight Side Length: 274.2 in
Support Type: Lugs
Additional Information: Buss Loop hydrogenation reactor,
More Details ⟶
Stock Number: #246468
Stainless Steel Other Shell and Tube Heat Exchanger
Heat Transfer Surface Area: 495.1 ft²
Orientation: Vertical
Shell Pressure: 188.5 psi
Shell Temperature: 329 °F
Shell Material: Stainless Steel Other
Tube Pressure: 45 bar
Tube Temperature: 165 °C
Tube Material: Stainless Steel Other
Tubesheet Material: Stainless Steel Other
Head Material: Stainless Steel Other
Tube-side Passes: 1
Tube Type: Straight Tube
Additional Information: approx 46 square meter, shell with expansion bellows, approx 3.2m long tubes Tube Number: 246. Tube Diameter: 0.75 in. Tube Length: 0.13 in. Capacity: 125.5 gallons. Heat Exchanger Tube Capacity: 77.4 gallons.
More Details ⟶
Stock Number: #246469
Centrifugal Pump
Flow Rate: 350 GPM
Pump Head: 45 ft
Orientation: Horizontal
Powered By: Electric
Motor Power: 60.3 HP
Motor Speed (RPM): 1,465
Additional Information: • EEx de IIC T4 motor.
More Details ⟶
Stock Number: #206245
Stainless Steel 316 Wiped/Thin Film Evaporator
Total Heat Transfer Surface Area: 150 ft²
Temperature: 650 °F
Vacuum: Yes
Additional Information: 4' of shell is 316SS lined and the rest of the shell Hastelloy C lined Hastelloy C shell, CS Jacket. Dual rated jacket 200 PSIG @ 400 degrees F or 100 PSIG @ 650 degrees F. With 20 HP, 900 RPM, 3/60/230/460 Volt motor.
More Details ⟶
Stock Number: #211715
Stainless Steel 316 Wiped/Thin Film Evaporator
Total Heat Transfer Surface Area: 3.5 m²
Orientation: Vertical
Diameter: 450 mm
Height: 4,250 mm
Pressure: 16 bar
Temperature: 200 °C
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Additional Information: wiped thin film evaporator system Rotafilm straight side made up of (2) 1354mm long bolted sections, c/steel jackets on straight side and bottom cone, rotor direct driven by 3.6 kw, 3/50/380 volt, 1450 rpm gear motor, mechanical seal on rotor, (4) blade rotor with wipers evaporator mounted lugs. system includes (1) 2 Sqm 1.4435 s/steel coil condenser, fabrik #645, shell pressure -1/2 bar @ -20/200 deg C, coil -1/6 bar @ -20/200 degs C, 419mm diameter x 936mm tangent to tangent shell, bolted dished top,weld dished bottom, (2) banks of internal spiral condensing coil. mounted on lugs, (1) 88ltr 1.4435 s/steel vertical separator tank with internal coil, fabrik #646, internal pressure -1/6 bar @ -30/300 deg C, coil -1/13 bar @ -30/200 deg C (4ltr), 280mm diameter x1m straight side
More Details ⟶
