Capacity:
42.3 gallons
Air Flow Rate:
394.3 CFM
Pressure:
12 bar
Temperature:
100 °C
Clean in Place:
Yes
Bowl Diameter:
25.6 in
Bowl Height:
39.4 in
Orientation:
Vertical
Product Density:
52,950 ft3
Operational Mode:
Batch
HEPA Filtration:
Yes
Dust Collection:
Yes
Additional Information:
Documentation shows Mills but we did not get some of them. With spare product containers. (read below) 60 kg
Explosion shock resistant fluid bed dryer.
Designed for cGMP production, it is a contained system, and can be used for other process’ such as food agglomeration and drying
Model - MP2/3-K2-F1/2
Rated for Maximum absolute pre pressure of 11 bar
and Maximum explosion over pressure of 12 bar
Total volume 610 liters
typical working volume is 18-160 liters
based on the allowable product density of 1500 kg/m
This fluid bed dryer was designed for Pharmaceutical service and features sanitary design and clean in place
With wet and dry loading ports, internal lighting, and sample ports
Designed for liquid/binder addition, it includes the Peristaltic transfer pump. This dryer is part of a contained system, product never reaches outside the unit. It is also integrated to work with products upstream and downstream. Designed for easy and quick cleaning and changeovers, the clean in place and all the operations are completely automated, and can be controlled at a local operator station
Air handling is achieved with a custom manufactured unit by ZAir, Type SKG-4,2 507-68273-1
Manufactured of 304 SS construction, it’s rated for 130-670 m3/Hr. at 20-80 degrees C
This unit handles all the air heating, cooling, and humification duties
The Main fan is driven by a 12.7 kW AC motor, and it also has a HEPA filter
This unit is complete with all filters, and accessories
High shear granulator available (IPP Stock # 233967. This unit also has spare product containers. Product containers are FBP 07304A.FBP101, # 001, built 2019, with Product container trolly. FBP 07304A.FBP101, # 002, built 2019, with Product container trolly. FBP 07304A.FBP101, # 003, built 2019, with Product container trolly
Unit comes with one product container, all other additional equipment is available at an additional cost Explosion-Shock Resistant: Yes.
