Capacity Design:
2.2 m3
Capacity Working:
56.5 ft3
Diameter:
1,500 mm
Length:
4,000 mm
Height:
116.1 in
Temperature:
165 °C
Rated for Vacuum:
Yes
Heat Transfer Surface Area:
55.2 ft²
Shaft Cored and National Board Stamped:
Yes
Orientation:
Horizontal
Operational Mode:
Batch
Agitation:
Yes
Additional Information:
jacketed vacuum paddle dryer system
design pressure internal vacuum @ 165 degrees C (2223 liter total capacity),
heating capacity internal 3.5 square meter, jackets 1.63 square meter, paddle 3.38 square meter
paddle cored for heating, paddle speed 4 rpm
11 kw, 3/50/380 volt, 1450 rpm motor
front hinged door with half pipe coil jacket,
system includes: (1) 630 liter 316L stainless steel vertical pressure tank, internal pressure 2 bar + vacuum @ 200 degrees C, 1m diameter x 790mm straight side, weld dished top and bottom, (1) 1.6 square meter 316L stainless steel vertical jacketed dust filters, 448mm diameter x 1632mm overall height, weld dished top, weld coned bottom, half pipe coil jacket Dust Collection: Yes. Jacket Material: Stainless Steel Other. Jacket Pressure: 6.5 bar. Jacket Temperature: 165 °C. Jacket Type: Half Pipe/Limpet.
