Results 5 items found

Available equipment

Showing 5 of 5 matching equipment.

Stock Number: #212801
Ammonia Converter for 1250STPD Ammonia Plant
Capacity (Design): 19,150 gallons
Orientation: Horizontal
Diameter: 84 in
Straight-side Length: 900 in
Internal Pressure: 2,600 psi
Internal Temperature: 475 °F
Support: Lugs
Additional Information: • Function: Ammonia converter • Head thickness: 3.125 inches • Additional feature: Haldor Topsoe Basket • Built to ASME code, but not stamped. State Special.
More Details ⟶
Stock Number: #235922
Stainless Steel 321 Clad Struthers Wells Batch-Type Agitated Reactor
Capacity (Design): 500 gallons
Internal Pressure: 1,250 psi
Internal Temperature: 650 °F
Jacket Pressure: 300 psi
Jacket Temperature: 750 °F
Orientation: Vertical
Agitation: Yes
Diameter: 44 in
Straight Side Length: 65 in
Support Type: Legs
Additional Information: • Internal coil, of 321 SS seamless pipe, is 2 & 3/8" diameter x 0.218 wall thickness. It has 13 turns with a 36" mean diameter on a 4" pitch. • Mixing is by a 16" diameter radial type impeller rotating at 258 rpm. The mixer drive system has a belt driven MagneDrive II series seal less magnetic drive, manufactured by Parker/Autoclave Engineers. This drive arrangement features Contamination free mixing, and zero atmospheric leakage.
More Details ⟶
Stock Number: #220768
Stainless Steel 321 Struthers Wells Inc. Tank
Capacity (Design): 3,000 gallons
Orientation: Vertical
Diameter: 72 in
Straight-side Length: 156 in
Internal Temperature: 300 °F
Vacuum: Yes
Support: Lugs
Additional Information: crystallizer
More Details ⟶
Stock Number: #220770
Stainless Steel 321 Struthers Wells Inc. Tank
Capacity (Design): 3,500 gallons
Orientation: Vertical
Diameter: 80 in
Straight-side Length: 144 in
Internal Temperature: 300 °F
Vacuum: Yes
Cone Length: 48 in
Support: Lugs
Additional Information: • Type: Crystallizer • Additional features: SS vacuum venturi and elbow pump
More Details ⟶
Stock Number: #246893
Stainless Steel 304 Struthers Wells Inc. Crystalizer/Evaporator Evaporator
Evaporation Rate: 2,400 lb/h
Total Heat Transfer Surface Area: 475 ft²
Orientation: Vertical
Pressure: 50 psi
Temperature: 293 °F
Vacuum: Yes
Vapor Body #1: Main body and vapor section , 304 SS with overall height of 49', overall width of 15' and overall diameter of 9 '.
More Details ⟶
