Capacity (Design):
7,600 L
Internal Pressure:
6 bar
Internal Full Vacuum:
Yes
Internal Temperature:
200 °C
Jacket Pressure:
6 bar
Jacket Temperature:
200 °C
Agitation:
Yes
Diameter:
2,000 mm
Straight Side Length:
1,950 mm
Additional Information:
• Reactor with condensing system
• CE-6300 series
• internal design pressure -1/6 bar @ -25/+ 200 deg C (7590ltr),
• jacket -1/6 bar @ -25/+200 deg C (700ltr)
• Motor: 3 phase
-mechanical seal type RF100-VOS-H with lubricator
• Straight side openings: 2-25mm (jacket), bottom: 1-150mm with Pneumatic valve, 4-50mm (jacket)
• Condensing system:
• 1 x 100 liter Schott QVF glass vertical receiver, type VZG-100/g, pressure -1/0.3 bar @ 150 deg C
• 2 x 100 liter Schott QVF glass round receivers, type VSV-100, pressure -1/0.3 bar @ 150 deg C
• 1 x 1 sqm vertical Schott QVF glass shell and spiral tube heat exchanger, type HE6/10, pressure -1/0.3 bar @ 150 deg C
• 1 x 1.5 sqm Schott QVF glass shell & spiral tube heat exchanger, type HE6/15, pressure -1/0.3 bar @ 150 deg C
• 1 x 26 sqm Schott QVF glass horizontal shell and tube heat exchanger, type RGM12/21, pressure -1/0.3 bar @ 150 deg C
• 1 x 100 m3/hr @ 33 mbar Traveini 2-stage c/steel water seal vacuum pump with a 40 liter c/steel separator tank, type TRHC-40-190/C/RX, serial #BX432, driven by 6.6 kW, 3/50/380/420/655/725 volt, 1430 rpm Ex motor, mounted on a baseplate.
