agit jkt reactor. 1000mm dia x 1180mm from clamp top to btm discharge, Cont #417902. Driven by 1.5 KW, 3/50/220/380 volt motor w/Indur varispeed drive, 2000-1000 rpm. Light. Designed to APAVE standards. Glass #3008
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: DeDietrich
Model: STA
Condition: Used
Material: Glasslined
Capacity (Design): 875 L (231.2 gallons)
Internal Pressure: 2 bar (29 psi)
Cont #414834 W/glass #2222N 800mm dia Driven by 2.2 KW, 3/50/220/380 volt w/fluid gear drive. varispeed pulley Light. Designed to APAVE standards
Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,000 mm (39.4 in). Straight Side Length: 1,200 mm (46.5 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: DeDietrich
Model: STA
Condition: Used
Material: Glasslined
Capacity (Design): 875 L (231.2 gallons)
Internal Pressure: 2 bar (29 psi)
Glass type: #2222N Lighting: Yes Contract number: 414834 Standards: Designed to APAVE standards 800mm dia. Driven by 2.2 KW, 3/50/220/380 volt Designed to APAVE standards. w/fluid gear and varispeed pulley
Internal Full Vacuum: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,000 mm (39.4 in). Straight Side Length: 1,200 mm (46.5 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: DeDietrich
Model: STA
Condition: Used
Material: Glasslined
Capacity (Design): 980 L (258.9 gallons)
Internal Pressure: 6 bar (87 psi)
Internal pressure -1/6bar@ 200 Degrees C, 980 liter, jacket 6 bar@ 200 Degrees C, 200 liter,
Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Diameter: 1,000 mm (39.4 in). Straight Side Length: 1,200 mm (46.5 in).
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: DeDietrich
Model: STA
Condition: Used
Material: Glasslined
Capacity (Design): 3,800 L (1,000 gallons)
Internal Pressure: 6 bar (87 psi)
Ekato drive HWL 2060, Lining: Glass 3008
Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Agitation: Yes. Diameter: 1,600 mm (63 in). Straight Side Length: 1,400 mm (55.1 in). Support Type: Lugs.
