Ingersoll Rand C12M2 Centrifugal Compressor - IPP# 208890

Type: Compressor

Subtype: Centrifugal

Manufacturer: Ingersoll Rand

Model: IGH5-21M1

Condition: Used

Compressor Type: Centrifugal

Discharge Pressure: 1.24 bar (18 psi)

Centac Air Compressor

Flow Rate: 3,653 m3/h (2,150 CFM). Speed (RPM): 3,600.

Type: Compressor

Subtype: Centrifugal

Manufacturer: Ingersoll Rand

Model: ICII 21M1

Condition: Used

Compressor Type: Centrifugal

Inlet Pressure: 1 bar (14.5 psi)

Centac Air Compressor
at 60% relative humidity
rated speed 1800 rpm
barometer 14.4 psia

Discharge Pressure: 1.24 bar (18 psi). Flow Rate: 3,653 m3/h (2,150 CFM). Speed (RPM): 3,600.

Type: Compressor

Subtype: Centrifugal

Manufacturer: Ingersoll Rand

Model: ICII 21M1

Condition: Used

Compressor Type: Centrifugal

Inlet Pressure: 1 bar (14.5 psi)

Centac Air Compressor
Direct coupled to motor
Intake pressure;14.5
Intake temp. 95 degrees F
at 60% relative humidity
rated speed 1800 rpm,
barometer 14.4 psia.

Discharge Pressure: 1.24 bar (18 psi). Flow Rate: 3,653 m3/h (2,150 CFM). Speed (RPM): 3,600.

Type: Compressor

Subtype: Centrifugal

Manufacturer: Ingersoll Rand

Model: 1ACII26A/E2

Condition: Used

Material: Carbon Steel

Compressor Type: Centrifugal

Inlet Pressure: 0.972 bar (14.1 psi)

Centac II air compressor
Water cooled with both Intercooler & after cooler
Compressor inlet 6" discharge 3"
cooling water inlets and outlests are 2" Skid mounted with control panel and oil pump
2 pole 3 phase constant speed AC drive motor rated for 129 full load amps
With carbon steel air reciever
600 gallon vertical mount
6" inlets and outlets,
1.5" presure releif valve, and 15" eliptical hand way.

Discharge Pressure: 7.58 bar (110 psi). Flow Rate: 4,586 m3/h (2,699 CFM). Inlet Diameter: 152 mm (6 in). Speed (RPM): 3,575.
