Nash SC2SS Vacuum pump, with vapor recovery system
Test # 90Y002
The system includes the following equipment; a vacuum pump, two heat exchangers, a separating tank, and seal pots. The direct drive vacuum pump, is manufactured by Nash, size SC2SS, Pos. 4 ,Vac, rated 200 cfm @ 5-20" Hg.
The vapor exchanger is a 30 sq. ft., all 316 SS, horizontal heat exchanger manufactured by Industrial Process Equipment corp., Model # 2ST8-60, Serial # 105-641A
National Board # 988
It’s shell and tubes are rated for 150/FV
The condensate chiller is a 10 sq.ft., 316SS tube bundle, 316SS heads, with CS shell, horizontal heat exchanger and is also manufactured by Industrial Process Equipment Corporation. Serial # 1056413, and National Board # 989, Rated for 150/FV psi in the shell and tubes.
The dual seal pot arrangement, with Nitrogen purge is provided by Duramettalic, Canada/Condex Heat Transfer Corp. Serial # 91-3-4146 & 4179, and rated for 400 psi at 400 degrees F. Both have level sight glasses and N2 purge line with regulator and Liquid make up valves. The units 316 SS separator, is manufactured by Jenco, Serial # 91-1327, National Board # 525, and rated for 30/FV at 350 psi. The separator tank also has a liquid level sight glass. The vapor inlet line is 4" flanged, and separator outlet is 1”. Automatic valves for liquid flow control are provided by Fisher and El-O-Matic, and the vapor contact piping is 316 SS. System includes all DP cells, RTD temperature probes, and pressure gauges. Designed to be used in a hazardous atmosphere, skid has a 60 amp Square D breaker, and explosion proof switches and controls.

NFPA
class A drum warming oven.
designed for BOC Anhydride and acetic acid
Purge time 10 minutes
input 124,000BTUH at 75 psi
Complete with fire protection and controls.

SIHI vacuum skid
consisting of (1) 140m3/hour carbon steel liquid ring vacuum pump
3 bar
(1) 4 liter carbon steel separator vessel, pressure -1/3 barg @ 120 degrees C
273mm diameter x 1020mm total height, (1) 9.9 square meter carbon steel condenser, pressure tube side 6 barg @ 250 degrees C, shell -1/3 barg @ 250 degrees C,

• Side discharge with automatic valve Agitator Cored for Heating/Cooling: Yes. Vessel Liquid Capacity: 400 gallons.

• Product contact polished and sanitary.
• 3 pc valve and plunger.
• Free standing with its own cabinet

This Aquadyne 3300DST is a robust, mobile, Detroit Diesel-powered reciprocating pump built to deliver very high pressure (up to 10,000 psi) at 45 GPM. Its design makes it well-suited for clean-in-place (CIP) operations—such as high-pressure tank washing—where reliability and performance are critical. This system includes a tank pressure washing module for installation on manways to perform CIP operations.

20 Ton , 3000 SCFM Roof top heat and ac system--12 SEER

Podbielniak counter current extracting centrifuge
job number 106-102
Bowl is 38" OD x 39" Long
Hinged 304SS cover
CS coated bottom housing
Unit has a 2" feed pipe,
3" outlet on bottom housing
230/460 volt motor
with VFD controller
Drive dimensions are 48" x 40" x 30" high

twin shell blender system maximum density of 50 lbs./cu.ft Shell diameter is 54" (est.), manway diameter is 17 3/4"with air operated butterfly valve Brake supplied with motor Electrical requirements are 230/460, 3 ph, 60 hz

pressure both sides -1/10 bar @ -50/150 degrees C (18 liter/17 liter)
fully insulated, CE-0036,

• Rated for lethal service.
• Nozzles with Inconel 625 inlay.
• Glasslined beavertail baffle with WIKA TR-10 & PT100 temperature probes.
• Mechanically sealed agitator: FlowServe MD-200 DN140.
• See sales comments for additional options.

Rated FV/300 psi @ -20 to 425 degrees tube side; FV/50 psi @ -20 to 425 degrees F shell side.
with glass lined clamped heads Tube Number: 18. Tube Diameter: 0.75 in. Tube Length: 216 in.

13 KW Rhenania drive1000 U/min reduction 63:15 motor 13,2 kW 3/50/500V/ 21,5A/ 965 rpm Flender gear type: SVRF 140

Double Drum Dryer

With vacuum housing and vacuum skid

Chrome plated carbon steel drums with 304 stainless steel, jacketed vacuum housing

Sanitary and polished construction suitable for food and pharmaceuticals but can be used for any batch processes, or converted to a continuous process.

Drum rolls have a 16 micro-inch finish, all internals have a 32 micro-inch finish

External finish is 2B or bead blast

Vacuum housing is rated to operate at full vacuum

Drums are rated for 160psi/FV @ 375 degrees F (NB# 9918 and NB# 9919)

Designed for use in class 1 division 2 atmospheres

1287 lbs./hr. of H2O and Ethanol

utilizing a 3.8 to 4.6 lbs./hr./ft2 evaporation rate

Spring loaded screw type manual adjustment assemblies with digital drum gap display

Pneumatic cylinder adjustable 304 stainless steel knife bars with clamp and acme thumb fasteners and pneumatically operated stainless steel end scrapers

8 zone steam jackets rated for 160 psi at 375 degrees F

(4) 6” tri-clamp top chamber inlets, (4) 4” tri-clamp product feed inlets, (2) 14” 150lb ANSI flange vapor outlets

(14) 1/2” NPT hot water jacket nozzles, (2) 1.5” NPT hot water jacket nozzles, (6) 4” tri-clamp internal drains, (10) 4” tri-clamp light ports

The Vacuum system is rated for 140 CFM, and is 304 SS contact, capable of handling 1,340 lbs./Hr. of vapor rate

Manufactured by Wintek Corp

Model # C380R50-WSS-=140/2-1FRss, serial # 140321

The skid mount system contains the following equipment: One-(1) 380 square foot, 304 SS contact, shell and tube pre condenser

TEMA C AEL, requires 180 GPM of cooling water at 50 degrees F

One-(1) Non code 304 SS 50-gallon receiver, with condensate pump

One-(1) Vacuum pump, SS wetted side, manufactured by Dekker, rated for 140 CFM, direct driven by a WEG 10 HP motor at 1750 rpm

One -(1) separator tank, non-code 304 SS, approximately 10 gallons

One- (1) Sealant heat exchanger, non-code, plate and frame, SS process side, requires 10 GPM cooling water at 50 degrees F

All equipment mounted in a CS frame work with ss interconnecting piping

The control system is a free standing Panel View Plus 1000 in a nitrogen purged enclosure good for Class 1,Division 2, Group D

It is located local to the machine, but will also send a signal to a remote control room

Located outside the classified area are the motor VFD, and electrical controls

Positive Displacement Rotary Lobe blower
Series RBS, size 65/F
includes Inlet and Exhaust filters.
With patented special three lobe profile rotors with LOW-pulse system to reduce the pressure pulsations.
Flow rate up to 1072 m3/h , solute inlet pressure starting from 450 mbar, maximum outlet temperature 150°C
Material: rotor, shaft and housing (steel casting)
Material: tooth wheels (18NiCrMo 5)

UNUSED

Internal finish 240 grit buff polished-Bright polished, external buff polish to a matte finish. ASME NB rated, and "U" stamped.

welded dish heads (2:1) 12 mm thick

Coil: 114 mm OD x 4 mm thick,

Limpet covers bottom dish and 2615 mm of straight side (pitch 150mm). Coil heating surface area.

With Insulation rings and upper drip ring. Two top lifting lugs and one tailing lug.

20" Manhole with Cover and davit arm assist, one 6" sight glass, Support Type: Lugs.

• Can be equipped with Agitation System
• Reglassed KC series reactor body
• Manufacturers number 4364421
• With (4) side support lugs or (8) leg couplings for mounting/installation.

top load, bottom discharge,
12mm thick basket,
3.15 square meter filter area,
1100 rpm permissible speed
single motion plow driven by a hydraulic powerpack, powerpack driven by approx 0.75kw EX motor, mounted on a steel baseplate,

• Jacket conical screw mixer/dryer with top mounted filter,
• screw 7 bar @ 150 degrees C . (18.5 liter), single internal 316L (1.4404) stainless steel screw which is cored for steam heating, screw bottom driven by 11kw 3/50/380 volt 1500 rpm Eex motor, carriage motor 1.1 kw, 3/50/380 volt 1500 rpm Ex motor.
• Bottom discharge valve driven by 0.75kw, 3/50/380 volt 1400 rpm Ex motor, dished top with a 5.5 square meter 316L (1.4404) stainless steel jacketed reverse jet filter.
• Manufactured by Kilsch Apparatebau Gmbh, fabrik #2184/2, pressure -1/2 bar @ 170 degrees C (750 liter),bolt dished top, (4) jets, TUV certified

• Alloy C276 Vacuum Conical Screw Dryer.
• Coil jacket, Shell rated 88FV.
• 103" diameter x 117" length.
• Welded dished top head.
• Orbital acting screw agitation. Johnson Joint attached to top.

223 liter
Sterilizer
Internal pressure -1/2.5 bar @ 138 degrees C
cover with hinge
With a side mounted control panel, and electric steam heating skid

80mm inside diameter
blue glass

12 stages agitated extraction column
R25/4 (75-375 infinitely variable)
Double mechanical seal, type Crane 109/109,
Driven by a 0.25kW electrical motor
manufactured by BBC
type eQUx71MA4, 3~/50Hz/220-380V/1400rpm
EX proof (ExeG3)
(2) bolt dished heads

belt flaker, with Accu-Drop Pastillator and Variable Speed Drive
Belt system is 60" wide x 75 feet long. With six (138" x 59" x 5'5") water collectors
190 Gallons rated for 55 degrees F.
Six water spray systems, 116" x 2" OD.
Hot melt is feed through a rotoform, with steam to keep hot melt in a liquid state.
Shell side (Product side) rated for 400 degrees F, tube side, (steam) rated for 300-350 degrees F.
Rotoform is 59" long x 3.25" diameter
Main Belt is driven by a Euro drive variable-speed, with a helical reducer 3 HP gear ratio 34.26:1
Overall belt speed is from 25 FPM up to 125 FPM.
(This can also be adjusted with different sprockets.)
1750 rpm. 2.77 HP, service factor 1 with output torque 892. The rated temperature range is 51-110 degrees F.
Driven by a 1 hp AC motor, continuous duty TEFC.
Model # DF26DT1001.54, serial # 88075 1570.07.

• Class 1 Group C & D, Class 2 Group F & G Div2
