1 sqm rest filtration area Vessel volume: 500 ltr Jacket volume: 46 ltr Internal pressure: vac/6 bar @ -10/200 degrees C Number of filter elements: 13 Number of rest filter elements: 2 Distance between filter elements: 30mm filter cake volume 150 ltr
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Schenk
Model: ZHF-SR 15 KLK
Condition: Used
Material: Stainless Steel Austenitic
Filtration Area: 15 m² (161.9 ft²)
Orientation: Vertical
vessel # 5293GW rated inside -1/6bar volume 1.000 liter rated jacket -1/6bar volume 110 liter, vertical jacketed centrifugal discharge. Cake capacity 0.45 cubic feet.
Pressure: 6 bar (87 psi). Temperature: 200 °C (392 °F). Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F).
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Schenk
Model: ZHF-SR15 KLKB1
Condition: Used
Material: Stainless Steel Austenitic
Filtration Area: 15 m² (161.5 ft²)
Diameter: 805 mm (31.7 in)
Vessel Number 5056GW Capacity: 955 liters Centrifugal wet cake discharge (32) 805mm diameter elements, (2) 805mm diameter scavenger elements mechanical seal
Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 100 °C (212 °F).
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Schenk
Model: ZHF-SR15 KLKB1
Condition: Used
Material: Stainless Steel Austenitic
Filtration Area: 15 m² (161.5 ft²)
Diameter: 805 mm (31.7 in)
Vessel Number: 5055GW Capacity: 955 liters Centrifugal wet cake discharge Elements: (32) 805mm diameter elements, (2) 805mm diameter scavenger elements Seal: Mechanical seal under driven
Orientation: Vertical. Pressure: 6 bar (87 psi). Temperature: 100 °C (212 °F). Number of Filter Elements: 32. Vessel Liquid Capacity: 955 L (252.3 gallons). Scavenging: Yes. Number of Scavenging Elements: 2.
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Schenk
Model: ZHF-SR10KL
Condition: Used
Material: Stainless Steel Austenitic
Filtration Area: 4.7 m² (50.6 ft²)
Diameter: 805 mm (31.7 in)
jacket 1,9 bar at 150°C (10) 316Ti stainless steel filter leaves Mechanical seal on shaft, carbon steel half pipe coil on bottom head Filter volume 670 liter
Pressure: 6 bar (87 psi). Temperature: 150 °C (302 °F). Jacket: Yes. Jacket Type: Half Pipe/Limpet. Jacket MOC: Carbon Steel. Jacket Pressure: 9 bar (130.5 psi). Jacket Temperature: 150 °C (302 °F).
