Name: 1.25 m² (13.5 ft²) Graphite Shell and Tube Heat Exchanger
Brand: VICARB
SKU: 211625

Graphite VICARB HP2/20 Shell and Tube Heat Exchanger

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: VICARB

Model: HP2/20

Condition: Used

Material: Graphite

Heat Transfer Surface Area: 21 m² (226 ft²)

Orientation: Vertical

design pressure process side 7 bar @ 50/61 degrees C, service 3.6 bar @ 23/34 degrees C, exchanger made up of 8- blocks of HP2/20 elements

Shell Pressure: 2.5 bar (36.3 psi). Shell Temperature: 34 °C (93.2 °F). Shell Material: Carbon Steel. Tube Pressure: 6 bar (87 psi). Tube Temperature: 61 °C (141.8 °F). Tube Material: Graphite. Shell-side Passes: 2. Tube-side Passes: 3. Nozzle Schedule: openings: process 2-100mm, 2-25mm, service 2-100mm,.

7 m² (75.3 ft²) Graphite Shell and Tube Heat Exchanger

Type: Heat Exchanger

Subtype: Shell and Tube

Manufacturer: VICARB

Condition: Used

Material: Graphite

Heat Transfer Surface Area: 7 m² (75.3 ft²)

Orientation: Horizontal

condenser Tube dimensions: 20 mm x 32mm OD x 1740 mm long

Shell Pressure: 3.5 bar (50.8 psi). Shell Temperature: 160 °C (320 °F). Shell Material: Carbon Steel. Tube Pressure: 3.5 bar (50.8 psi). Tube Temperature: 160 °C (320 °F). Tube Material: Graphite. Shell Diameter: 370 mm (14.6 in). Length: 3,000 mm (117.7 in). Tube Number: 43. Tube Diameter: 32 mm (1.26 in). Tube Length: 1,750 mm (68.5 in). Tube Thickness: 12 mm (0.47 in). Nozzle Schedule: - Openings: (2) 150 mm, (1) 50mm tube side; (2) 100 mm, (1) 25mm Shell side.
