Stainless Steel 304 Evans & Sons Tank - IPP# 232169

Type: Tank

Manufacturer: Evans & Sons

Condition: Used

Material: Stainless Steel 304

Capacity (Design): 17,050 L (4,500 gallons)

Orientation: Vertical

Diameter: 2,750 mm (108 in). Straight-side Length: 2,750 mm (108 in). Internal Pressure: 1.01 bar (14.7 psi). Does it have Agitation ?: Yes. Baffle Type: Sidewall Mounted Straight Baffle. Support: Legs.

Type: Tank

Manufacturer: Evans & Sons

Condition: Used

Material: Stainless Steel 304

Capacity (Design): 4,550 L (1,200 gallons)

Orientation: Vertical

Diameter: 1,500 mm (60 in). Straight-side Length: 2,750 mm (108 in). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 176.7 °C (350 °F). Vacuum: Yes. Support: Legs.

Type: Tank

Manufacturer: Evans & Sons

Condition: Used

Material: Stainless Steel 304

Capacity (Design): 5,700 L (1,500 gallons)

Orientation: Vertical

• Variable head thickness: top head 0.3" thick, bottom head 0.291" thick.

Diameter: 1,500 mm (60 in). Straight-side Length: 2,750 mm (108 in). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 176.7 °C (350 °F). Vacuum: Yes. Support: Legs.

Type: Tank

Manufacturer: Evans & Sons

Condition: Used

Material: Stainless Steel 304

Capacity (Design): 5,700 L (1,500 gallons)

Orientation: Vertical

• Variable head thickness: top head 0.3", bottom head 0.291"

Diameter: 1,500 mm (60 in). Straight-side Length: 2,750 mm (108 in). Internal Pressure: 6.9 bar (100 psi). Internal Temperature: 176.7 °C (350 °F). Vacuum: Yes. Support: Legs.
