Name: Stainless Steel 317 Edel Batch-Type Agitated Reactor
Brand: Edel
SKU: 236015

Overview

Type:

Reactor

Subtype:

Batch-Type Agitated

Manufacturer:

Edel

Condition:

Used

Material:

Stainless Steel 317

Capacity (Design):

7,100 L (1,900 gallons)

Pressure Vessel

Internal Pressure:

3.2 bar (46.4 psi)

Internal Full Vacuum:

Yes

Internal Temperature:

200 °C (392 °F)

Jacket/Internal Coil

Jacket Pressure:

10 bar (145 psi)

Jacket Temperature:

200 °C (392 °F)

Jacket Material of Construction:

Stainless Steel 304

Agitation System

Agitation:

Yes

Agitation Seal Type:

Mechanical

Agitator Details:

Stelzer type SNR 35-10-E right angled CE0035, EX II 2G T3 II BX agitator drive, driven by 30kw 3/50/400 volt, 1480 rpm ATEX CE0045 Ex motor via a reduction gearbox, (3) sets of 2-blade intermig impellors on shaft, mechanical seal

Motor Power:

30 kW (40.2 HP)

Baffle Details:

(4) internal baffle plates on sidewall

Dimensions

Diameter:

1,800 mm (70.9 in)

Straight Side Length:

2,050 mm (81.5 in)

Heads

Top Head Type:

Dish

Bottom Head Type:

Cone

Other Specifications

Manway:

Yes

Inlets & Outlets

Nozzle Schedule:

openings top: 1-500mm manway with cover, 2-300mm, 7-150mm, straight side: 5-50mm (jacket), bottom cone: 1-150mm (discharge), 1-50mm (jacket), 1-30mm wide x 500mm long sight glass
