Stainless Steel 316L Alfa Laval CP30-H-60PLs Welded Plate Compabloc Heat Exchanger - IPP# 242494

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CP30-H-60PLs

Condition: Used

Material: Hastelloy - C22

Heat Transfer Surface Area: 6.5 m² (70 ft²)

Process Pressure: 6 bar (87 psi)

• Compabloc welded plate heat exchanger
• design pressure side A: -1/6 barg @ -29/185 degrees C (26.2 liter),
• side B: -1/8 barg @ -29/185 degrees C (24.6 liter)

Process Temperature: 185 °C (365 °F).

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CPL30-H-80

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 9 m² (96.9 ft²)

Process Pressure: 10 bar (145 psi)

• Compabloc welded plate heat exchanger,
• design pressure process side: 10 barg + full vacuum @ -25/165 degrees C (34.4 liter),
• service side: 10 barg + full vacuum @ -29/185 degrees C (33.5 liter),
• 1-pass process side, 6-pass service side,
• (80) 316L (1.4404) stainless steel welded plates,
• openings process side 1-100mm, 1-50mm, service side: 2-50mm,
• design code: ADM (PED CAT 3)

Process Temperature: 165 °C (329 °F).

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CPL20-H-60

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 3.8 m² (40.7 ft²)

Process Pressure: 10 bar (145 psi)

• Compabloc welded plate heat exchanger,
• design pressure process side: 10 barg + full vacuum @ -25/165 degrees C (17.3 liter),
• service side: 10 barg + full vacuum @ -29/185 degrees C (16.9 liter),
• 2-pass process side, 6-pass service side,
• (60) 316L (1.4404) stainless steel welded plates,
• openings process side 3-50mm, service side: 2-50mm,
• design code: ADM (PED CAT 3)

Process Temperature: 165 °C (329 °F).

Type: Heat Exchanger

Subtype: Welded Plate

Manufacturer: Alfa Laval

Model: CP30-C-160PLs

Condition: Used

Material: Stainless Steel 316L

Heat Transfer Surface Area: 17.3 m² (186.2 ft²)

Process Pressure: 6 bar (87 psi)

• Compabloc welded plate heat exchanger,
• design pressure: process side: 6 barg + full vacuum @ 0/185 degrees C (82 liter)
• design pressure: service side: 8 barg + full vacuum @ 0/185 degrees C (67 liter)
• 1+1-pass process side,
• 4-pass service side
• (160) 316L stainless steel welded plates
• openings process side: 1-250mm, 1-100mm, 1-50mm, service side: 2-100mm
• mounted on lugs
• design code: AD-Merkblatt Ed.2000

Process Temperature: 185 °C (365 °F).
