Glasslined Pfaudler BE Batch-Type Agitated Reactor - IPP# 242683

  • Glasslined Pfaudler BE Batch-Type Agitated Reactor - IPP# 242683 Glasslined Pfaudler BE Batch-Type Agitated Reactor - IPP# 242683
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor - IPP# 242683 Glasslined Pfaudler BE Batch-Type Agitated Reactor - IPP# 242683
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor - IPP# 242683
  • Glasslined Pfaudler BE Batch-Type Agitated Reactor - IPP# 242683
Overview
Reactor
Batch-Type Agitated
Pfaudler
BE 16000
Used
Glasslined
16,000 L (4,250 gallons)
Glass Lined
Pressure Vessel
6 bar (87 psi)
Yes
200 °C (392 °F)
Jacket/Internal Coil
10 bar (145 psi)
200 °C (392 °F)
Standard
Carbon Steel
Dimensions
Vertical
2,750 mm (108 in)
2,300 mm (89.6 in)
Agitation System
Yes
Pitch Blade
Mechanical with Gas
1-sets of Cryolock pitched paddles and CBT Cryolock on bottom
45 kW (60.3 HP)
45 kW (60.3 HP)
Beavertail
beavertail baffle
Heads
Dish
Glasslined
Dish
Glasslined
Other Specifications
Yes
Lugs
Inlets & Outlets
openings top: 1-600mm manway with 2-100mm sightglasses, 2-400mm, 2-300mm, 4-200mm, 1-25mm (jacket), side jacket: 2-80mm, 4-50mm, bottom: 1-150mm, 2-80mm (jacket)
Additional Information
  • design pressure internal -1/6 bar @ -29/200 degrees C,
  • jacket -1/10 bar @ -29/200 degrees C,
  • CE0038,
  • glass type 9129,
  • driven by 45-52kW, 3/50-60/690-400/660-380/415-440 volt, 1477/1473/1479/1773 rpm EExd IIB II 2G T4 ATEX motor via a reduction gearbox,
  • 90 rpm shaft speed,
  • white glass body, blue glass shaft and baffle
  • design code: ASME VIII DIV 1, 2004 ANNEXE Z and essential safety requirements of PED/97/23/EC,
