Glasslined DeDietrich CTJ Batch Type Body Only Reactor - IPP# 245563

Type: Reactor

Subtype: Batch Type Body Only

Manufacturer: DeDietrich

Model: CTJ

Condition: Re-glassed

Material: Glasslined

Capacity (Design): 757 L (200 gallons)

Internal Pressure: 5.2 bar (75 psi)

• Base reactor

Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 7.2 bar (105 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Diameter: 991 mm (39 in). Straight Side Length: 813 mm (32 in). Support Type: Legs.

Type: Reactor

Subtype: Batch Type Body Only

Manufacturer: DeDietrich

Model: SA

Condition: Re-glassed

Material: Glasslined

Capacity (Design): 1,900 L (500 gallons)

Internal Pressure: 6.9 bar (100 psi)

• This is a base reactor body.

Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Diameter: 1,200 mm (48 in). Straight Side Length: 1,450 mm (57 in). Support Type: Legs.

Type: Reactor

Subtype: Batch Type Body Only

Manufacturer: DeDietrich

Model: SA

Condition: Re-glassed

Material: Glasslined

Capacity (Design): 3,800 L (1,000 gallons)

Internal Pressure: 6.9 bar (100 psi)

Internal Full Vacuum: Yes. Internal Temperature: 260 °C (500 °F). Jacket Pressure: 6.2 bar (90 psi). Jacket Temperature: 260 °C (500 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Diameter: 1,700 mm (66 in). Straight Side Length: 1,800 mm (71 in). Support Type: Legs.

Type: Reactor

Subtype: Batch Type Body Only

Manufacturer: DeDietrich

Model: CTJ

Condition: Used

Material: Glasslined

Capacity (Design): 75.7 L (20 gallons)

Internal Pressure: 0.55 bar (8 psi)

• laboratory type reactor body Fab # 16202Auter 416387 195

Internal Full Vacuum: Yes. Internal Temperature: 200 °C (392 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 200 °C (392 °F). Jacket Material of Construction: Carbon Steel. Body Only: Yes. Orientation: Vertical. Diameter: 406.4 mm (16 in). Straight Side Length: 406.4 mm (16 in).
