Carbon Steel Steam Boiler - IPP# 245587

Type: Boiler

Subtype: Steam

Manufacturer: Cleaver Brooks

Model: CFH-700-70HP-150#ST

Condition: Used

Material: Carbon Steel

Boiler Type: Firetube

Temperature: 100 °C (212 °F)

Power: 52.2 kW (70 HP). Capacity (Design): 1,100 kg/h (2,400 lb/h). Capacity Working: 1,300 kg/h (2,850 lb/h). Fuel Type: Natural Gas. Pressure: 10.3 bar (150 psi). Controls: Yes. Deaerator System: Yes.

Type: Boiler

Subtype: Steam

Manufacturer: Cleaver Brooks

Model: CB200-730-150

Condition: Used

Material: Carbon Steel

Boiler Type: Water Tube

Capacity (Design): 11,350 kg/h (25,000 lb/h)

Fuel Type: Natural Gas. Pressure: 10.3 bar (150 psi). Burner Manufacturer: Cleaver Brooks.

Type: Boiler

Subtype: Steam

Manufacturer: Cleaver Brooks

Model: D-34-R.H

Condition: Used

Boiler Type: Water Tube

Capacity (Design): 6,800 kg/h (15,000 lb/h)

Unit number: W-3525 Boiler heating surface sq. ft. 1517, Water wall sq. ft. 302 Max 20.574, Main Power 460 volts. Shipping dimensions 11’ wide x 25’ long x 12’ 6” min. to 13’ 4 “ max. overall height.

Fuel Type: Natural Gas. Pressure: 44.8 bar (650 psi).

Type: Boiler

Subtype: Steam

Manufacturer: Ansaldo Volund

Condition: Used

Material: Carbon Steel

Boiler Type: Water Tube

Temperature: 105 °C (221 °F)

normal working pressure 83 bara, flue gas for dimensioning 16,667 Nm3/hr, flue gas temperature after economizer 139.5 deg C, content of CO2 in flue gas 8.92 volume %, H20 15.84 volume %, O2 2.07 volume %, net calorific value 42.8 MJ/kg (gas oil), 39 MJ/kg (natural gas), Saacke type TSAAYD-135-E3-6275 steam atomizing burner, designed for natural gas or gas oil, heat input 22,000kg/hr, gas oil output 190-1329 kg/hr, natural gas 163-1631 Nm3/hr, energy input 13.1 MW, fuel input natural gas 1206 kg/hr, gas oil 1097 kg/hr, air flow 14,000 Nm3/hr, flue gas flow natural gas 14,150 Nm3/hr, gas oil 14,866 Nm3/hr, heating surface area furnace 60sqm, screen 2.6sqm, evaporator 33sqm, walls of convection part 25sqm, economizer 1 683sqm, economizer 2 78sqm, total 881sqm the boiler is an all welded water tube boiler with natural water circulation, built as a vertical and self-contained construction in which the downcomers form the supporting columns, vertical expansion of the boiler is free upwards, boiler has a radiation part, a convection part and a detached economizer, the radiation part is to reduce the flue gas temperature before the convection part, the radiation part is built as an all-welded membrane wall section on the sides, top and partition wall, the economizer is in the back of the convection part and is made with horizontal tube coils, these are a nest of pipes consisting of 14-tube lines of each 28 tubes, the evaporator is made with diagonal tube coils, which are a nest of 6-tube lines of each 28 tubes, the detached economizer is built as a four sided casing tower in which are placed horizontal convection heating surfaces, boiler includes: (1) 1640ltr c/steel boiler drum, steam space load 275 m3/m3xh, 1200mm diameter x 3m long, 40mm thick, weld dished ends, (1) Detached in-line fin tube Economizer, manufactured by Emvertec, 683sqm, design pressure 13.5 bar, (1) 316 s/steel Deaerator vessel, manufactured by Cool Technology ltd, design pressure 2 bara @ 105 deg C, operating pressure 0.21 bara (3) Feed water pumps, manufactured by KSB, type HGM-2/15, Other associated equipment include fans, valves, pumps, instruments, control panels, etc

Power: 13,100 kW (17,550 HP). Capacity (Design): 19,950 kg/h (44,000 lb/h). Fuel Type: Natural Gas. Pressure: 91 bar (1,300 psi). Controls: Yes. Burner Manufacturer: Saacke. Low NOx: Yes. Deaerator System: Yes.
