Type: Dryer-Fluid Bed
Manufacturer: Glatt
Model: WSG15
Condition: Used
Material: Stainless Steel 316
Capacity: 45 L (11.9 gallons)
Air Flow Rate: 750 m3/h (441.4 CFM)
15-30 Kg, 45 liter bowl capacity, 52000 K/hr steam heaters, compressed air @ 6 bar, Air warming range -10 degrees C to +70 degrees C, Electrics motor
Pressure: 3 bar (43.5 psi). Temperature: 70 °C (158 °F). Product Density: 0.04 m3 (1.41 ft3).
Type: Dryer-Fluid Bed
Manufacturer: Glatt
Model: WST120
Condition: Refurbished/Rebuilt
Material: Stainless Steel 304
Capacity: 420 L (111 gallons)
Air Flow Rate: 5,981 m3/h (3,520 CFM)
250 Kg Fluid Bed Dryer batch type Steam heater rated 140000 Kcal/hr steam Motor: 3 phase 220/380 volt With (2) product bins 1200mm upper diameter, 800mm lower diameter, sanitary polished Drying chamber 3.5m high (11'6") x 1.2m diameter (48") With a control panel indicating air temperature, timers, intervals, vibration indicator of dust collector
Pressure: 6 bar (87 psi). Bowl Diameter: 1,200 mm (47.2 in). Bowl Height: 3,500 mm (137.8 in). Product Density: 0.42 m3 (14.8 ft3). Operational Mode: Batch. Dust Collection: Yes.
Type: Dryer-Fluid Bed
Manufacturer: Glatt
Model: WSG
Condition: Used
Material: Stainless Steel 304
Capacity: 45 L (11.9 gallons)
Air Flow Rate: 750 m3/h (441.4 CFM)
15 Kg bed dryer system Heating capacity 68000 BTU/hour Steam pressure 3 bar air (compressed) 6 bar with removable trolley Drying chamber in (3) sections: (1) 21 1/2" diameter x 12" straight side; (1) 21 1/2" diameter x 27 1/2" straight side; (1) 21 1/2" diameter x 27 1/2" straight side x 15 1/2" diameter (cone shaped). Hydraulic bin closure, (2) trolley for bin removal Unit with air filter, manufactured by HSE, Type 5.5KW-SCF, serial #2620 Motor: 3 phase (3) control panels, (1) built-on unit Top mounted fan driven by 4.5 KW, 3/50/440 volt, 2915 rpm non-flameproof motor.
Pressure: 3 bar (43.5 psi). Temperature: 70 °C (158 °F). Bowl Diameter: 393.7 mm (15.5 in). Bowl Height: 279.4 mm (11 in). Orientation: Vertical. Product Density: 0.04 m3 (1.41 ft3). Operational Mode: Batch.
Type: Dryer-Fluid Bed
Manufacturer: Glatt
Model: WST120
Condition: Used
Material: Stainless Steel 304
Capacity: 420 L (111 gallons)
Air Flow Rate: 5,000 m3/h (2,943 CFM)
120 Kg Rated approx. 871,000 Kcal/hour steam Heaters @ 6 bar, 330 Kgs/hour vapor consumption @ 3 bar and -10 degrees C/+80 degrees C 3 bar Motor: 3 phase 12090mm cylindrical type drying chamber with explosion door (2) 304 stainless steel product bins Bin dimensions: 500 liter, top 1200mm diameter x bottom 1000mm diameter Pneumatic bin locking mechanism, control panel Unit with all ancillaries
Pressure: 3 bar (43.5 psi). Temperature: 80 °C (176 °F). Bowl Diameter: 1,200 mm (47.2 in). Bowl Height: 1,000 mm (39.4 in). Orientation: Vertical. Operational Mode: Batch.
