thin film continous contact dryer.
Jkt rated 13 bar @ 220 deg C,
int rated 0.5 bar and full vac @ 220 deg C.
Shell 850mm (34") dia x 4800mm (15.8') long
Type: Dryer-Thin Film
Manufacturer: Luwa SMS
Model: 850/4700/10
Condition: Used
Material: Stainless Steel 316L
Heat Transfer Surface Area: 11 m² (118 ft²)
Internal Pressure Rating: 0.5 bar (7.25 psi)
thin film continuous contact dryer.
Jkt rated 13 bar @ 220 deg C,
Shell 850mm (34") dia x 4800mm (15.8') long,
Internal Temperature Rating: 220 °C (428 °F). Jacket Pressure: 13 bar (189 psi). Jacket Temperature: 220 °C (428 °F). Orientation: Horizontal. Vacuum Rated: Yes. Shell Diameter: 850 mm (33.5 in). Shell Length: 4,800 mm (189 in).
Type: Dryer-Thin Film
Manufacturer: Luwa SMS
Model: 1000/6000/10
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 16 m² (172 ft²)
Internal Pressure Rating: 0.5 bar (7.25 psi)
thin film continuous contact dryer
Jkt rated 10 bar @ 200 deg C
Shell 1000mm (40") dia x 6008mm long
Rotor speed 80/160 rpm
Internal Temperature Rating: 200 °C (392 °F). Jacket Pressure: 10 bar (145 psi). Jacket Temperature: 200 °C (392 °F). Orientation: Horizontal. Vacuum Rated: Yes. Shell Diameter: 1,000 mm (39.4 in). Number of Shell Sections: 3. Shell Length: 6,008 mm (237 in).
Type: Dryer-Thin Film
Manufacturer: Luwa SMS
Model: DK600/4500/10
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 7.5 m² (80.7 ft²)
Internal Pressure Rating: 0.5 bar (7.25 psi)
thin film continuous contact dryer (cooler)
Jkt rated 8 bar @ 50 deg C
Shell 600mm dia (24") x 4.492m (177") long
Internal Temperature Rating: 120 °C (248 °F). Jacket Pressure: 8 bar (116 psi). Jacket Temperature: 50 °C (122 °F). Orientation: Horizontal. Shell Diameter: 600 mm (23.6 in). Shell Length: 4,492 mm (177 in).
Type: Dryer-Thin Film
Manufacturer: Luwa SMS
Model: DK600/4500/10
Condition: Used
Material: Stainless Steel 316
Heat Transfer Surface Area: 7.5 m² (80.7 ft²)
Internal Pressure Rating: 0.5 bar (7.25 psi)
Jacket rated 8 bar @ 50 degrees C,
Shell 600mm diameter x 4492mm long.
Internal Temperature Rating: 120 °C (248 °F). Jacket Pressure: 8 bar (116 psi). Jacket Temperature: 50 °C (122 °F). Orientation: Horizontal. Shell Diameter: 600 mm (23.6 in). Shell Length: 4,492 mm (177 in).
