Stainless Steel 316 Dryer-Fluid Bed 500 L (132.1 gallons) For Sale - IPP# 703094

Type: Dryer-Fluid Bed

Manufacturer: Calmic (William Boulton)

Model: 12874

Condition: Used

Material: Stainless Steel 316

Bowl Diameter: 609.6 mm (24 in)

Bowl Height: 330.2 mm (13 in)

25 Kg fluid bed dryer with steam heated jacket/battery flameproof motor with (1) 24" diameter x 13" deep bin Complete with socks, temperature gauge and bag vinch (manual)

Type: Dryer-Fluid Bed

Manufacturer: Arthur White

Model: AWS

Condition: Used

Material: Stainless Steel 316

Capacity: 100 L (26.4 gallons)

Pressure: 5.5 bar (80 psi)

50 Kg With 2 stainless steel bins on wheels with Davidson "M" Series fan non-flameproof motor Unit complete with bag shaker, damper pulsator, temperature gauge and socks Dryer housing is carbon steel With on/off switch Unit rated @ 100-200 lb/hr.

Temperature: 130 °C (266 °F). Bowl Diameter: 609.6 mm (24 in). Bowl Height: 355.6 mm (14 in). Orientation: Vertical. Operational Mode: Batch.

Type: Dryer-Fluid Bed

Manufacturer: Glatt

Model: WSG15

Condition: Used

Material: Stainless Steel 316

Capacity: 45 L (11.9 gallons)

Air Flow Rate: 750 m3/h (441.4 CFM)

15-30 Kg, 45 liter bowl capacity, 52000 K/hr steam heaters, compressed air @ 6 bar, Air warming range -10 degrees C to +70 degrees C, Electrics motor

Pressure: 3 bar (43.5 psi). Temperature: 70 °C (158 °F). Product Density: 0.04 m3 (1.41 ft3).

Type: Dryer-Fluid Bed

Manufacturer: GEA

Model: Pharmadule MP2/3-K2-F1/2

Condition: Unused

Material: Stainless Steel 316

Capacity: 160 L (42.3 gallons)

Air Flow Rate: 670 m3/h (394.3 CFM)

Documentation shows Mills but we did not get some of them. With spare product containers. (read below) 60 kg Explosion shock resistant fluid bed dryer. Designed for cGMP production, it is a contained system, and can be used for other process’ such as food agglomeration and drying Model - MP2/3-K2-F1/2 Rated for Maximum absolute pre pressure of 11 bar and Maximum explosion over pressure of 12 bar Total volume 610 liters typical working volume is 18-160 liters based on the allowable product density of 1500 kg/m This fluid bed dryer was designed for Pharmaceutical service and features sanitary design and clean in place With wet and dry loading ports, internal lighting, and sample ports Designed for liquid/binder addition, it includes the Peristaltic transfer pump. This dryer is part of a contained system, product never reaches outside the unit. It is also integrated to work with products upstream and downstream. Designed for easy and quick cleaning and changeovers, the clean in place and all the operations are completely automated, and can be controlled at a local operator station Air handling is achieved with a custom manufactured unit by ZAir, Type SKG-4,2 507-68273-1 Manufactured of 304 SS construction, it’s rated for 130-670 m3/Hr. at 20-80 degrees C This unit handles all the air heating, cooling, and humification duties The Main fan is driven by a 12.7 kW AC motor, and it also has a HEPA filter This unit is complete with all filters, and accessories High shear granulator available (IPP Stock # 233967. This unit also has spare product containers. Product containers are FBP 07304A.FBP101, # 001, built 2019, with Product container trolly. FBP 07304A.FBP101, # 002, built 2019, with Product container trolly. FBP 07304A.FBP101, # 003, built 2019, with Product container trolly Unit comes with one product container, all other additional equipment is available at an additional cost

Pressure: 12 bar (174 psi). Temperature: 100 °C (212 °F). Clean in Place: Yes. Bowl Diameter: 650 mm (25.6 in). Bowl Height: 1,000 mm (39.4 in). Orientation: Vertical. Product Density: 1,500 m3 (52,972 ft3). Operational Mode: Batch. HEPA Filtration: Yes. Dust Collection: Yes. Explosion-Shock Resistant: Yes.
