Graphite Robert Jenkins GEK-BQ-7 Block Heat Exchanger - IPP# 705658

Type: Heat Exchanger

Subtype: Block

Manufacturer: Robert Jenkins

Model: DM400/10/2A

Condition: Refurbished/Rebuilt

Material: Graphite

Heat Transfer Surface Area: 8 m² (86.1 ft²)

Orientation: Vertical

cylindrical (1) block (2) vert mounting brackets.

Shell Pressure: 6 bar (87 psi). Shell Temperature: 165 °C (329 °F). Shell Diameter: 457.2 mm (18 in). Length: 1,219 mm (48 in). Nozzle Schedule: Openings: 2-8", 2-4". Process Pressure: 6 bar (87 psi). Process Temperature: 165 °C (329 °F).

Type: Heat Exchanger

Subtype: Block

Manufacturer: Robert Jenkins

Model: GEK-BJ

Condition: Unused

Material: Carbon Steel

Orientation: Horizontal

Shell Pressure: 5.2 bar (75 psi)

Carbon block heat exchanger Block dimensions 620mm long x 340mm wide x 340mm high. Heat exchanger was refurbished by Ralph Coidan, ref # 31114D, test pressure service side 7.8 bar, process 7.8 bar

Shell Temperature: 180 °C (356 °F). Vacuum: Yes. Length: 620 mm (24.4 in). Nozzle Schedule: openings 4-50mm, 1-125mm. Process Pressure: 5.2 bar (75 psi). Process Temperature: 180 °C (356 °F).

Type: Heat Exchanger

Subtype: Block

Manufacturer: Rob Jenkins Systems

Model: GEB06/2

Condition: Used

Material: Graphite

Heat Transfer Surface Area: 0.8 m² (8.6 ft²)

Shell Pressure: 5.2 bar (75 psi)

(1) block, single pass.

Shell Temperature: 165 °C (329 °F). Length: 508 mm (20 in). Nozzle Schedule: Openings: 2-25mm. Process Pressure: 1.72 bar (24.9 psi). Process Temperature: 165 °C (329 °F).

Type: Heat Exchanger

Subtype: Block

Manufacturer: Vicarb

Model: HP2/20

Condition: Used

Material: Graphite

Heat Transfer Surface Area: 8 m² (86.1 ft²)

Orientation: Vertical

cylindrical design pressure process side 2.1 bar @ 15 to 120 deg C service 5.3 bar @ 155 deg C 7-pass on process side, 6-pass service side (2- pass per block, 3-blocks)

Shell Pressure: 4.6 bar (66.7 psi). Shell Temperature: 155 °C (311 °F). Shell Material: Carbon Steel. Shell Diameter: 470 mm (18.5 in). Length: 2,496 mm (98.3 in). Nozzle Schedule: openings: process 2-50mm, 2-25mm, service 2-100mm. Process Pressure: 2.1 bar (30.5 psi). Process Temperature: 120 °C (248 °F).
