Side discharge 500mm dia Raker driven by 6 PS, 3/50/500 volt 1480 rpm motor W/Von Roll Type PLR65 gear reducer. Hydraulic lift driven by 0.3 KW 3/50/500 volt motor. W/(2) polypropylene hinged covers1-100mm center btm outlet.
Type: Filter
Subtype: Nutsche
Manufacturer: JENS OLSEN
Condition: Used
Material: Stainless Steel 316
Filtration Area: 2.8 m² (29.6 ft²)
Diameter: 1,900 mm (74.8 in)
5570 liter jacketed tumbling pressure Nutsche filter internal pressure -1/2 bar @ 50/134 degrees C, jacket -1/2 bar @ 50/134 degrees C (339 liter) with hydraulic open/close assist hydraulic driven raker agitator driven by a hydraulic powerpack the whole filter rotates for discharge via a hydraulic motor driven by the same powerpack
Orientation: Vertical. Pressure: 2 bar (29 psi). Temperature: 134 °C (273.2 °F). Vacuum: Yes. Jacket: Yes. Jacket Pressure: 2 bar (29 psi). Jacket Temperature: 134 °C (273.2 °F).
Type: Filter
Subtype: Nutsche
Manufacturer: JENS OLSEN
Condition: Used
Material: Stainless Steel 316
Filtration Area: 1.75 m² (18.8 ft²)
Diameter: 1,500 mm (59.1 in)
2376 liter stainless steel agitated, jacketed tumbling pressure Nutsche filter internal pressure -1/2 bar @ 50/134 degrees C, jacket -1/2 bar @ 50/134 degrees C (150 liter) nged bolt dished bottom with hydraulic open/close assist hydraulic driven raker agitator driven by a hydraulic powerpack, the whole filter rotates for discharge via a hydraulic motor, driven by the same powerpack,
Pressure: 2 bar (29 psi). Temperature: 134 °C (273.2 °F). Jacket: Yes. Jacket Pressure: 2 bar (29 psi). Jacket Temperature: 134 °C (273.2 °F).
Type: Filter
Subtype: Nutsche
Manufacturer: Nutsche
Condition: Used
Material: Stainless Steel 316
Diameter: 900 mm (35.4 in)
Top load/unload design Top half (slurry holder), 300mm deep, open top with (2) removable lids. Bottom half (vacuum/filtrate receiver), 300mm deep Single mesh filter plate between top/bottom sections
Type: Filter
Subtype: Nutsche
Manufacturer: Seitz
Model: EF-100.300-CW
Condition: Used
Material: Stainless Steel 316
Filtration Area: 0.85 m² (9.1 ft²)
Diameter: 1,000 mm (39.4 in)
pressure filter Internal (330 ltr) Jacket (35 ltr) Raise/lower mechanism, max lifting 200 mm
Pressure: 6 bar (87 psi). Temperature: 165 °C (329 °F). Jacket: Yes. Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 165 °C (329 °F).
