Holoflite dryer
Estimated heat transfer area is 78 Sq.Ft.
Agitator 16" diameter and 18' long.
Material of construction 316SS on the screw and ferrilium vessel
outboard bearings
Type: Dryer-Holoflite & Screw
Manufacturer: Hi Line Industries
Model: 2155M25
Condition: Used
Material: Stainless Steel 316
Length: 4,115 mm (162 in)
Number of Screws: 1
12" dia x 13'6" long ferrilium/316SS conveyor dryer
Rated 5 TPH
Shaft 22 rpm
Ferrilium housing
316SS hollow screw conveyor
outboard bearings
3/60/230/460 volt,
Internal Pressure: 1.03 bar (14.9 psi). Internal Temperature: 149 °C (300 °F).
Type: Dryer-Holoflite & Screw
Manufacturer: Thies Kg Coesfeld Gmbh
Model: 2 V 410-24,
Condition: Used
Material: Stainless Steel 316
Width: 700 mm (27.6 in)
Length: 3,760 mm (148 in)
type Variocleaner
Rated internal pressure 0.005 bar @-10/50 Degrees C
carbon steel, heated screws rated 3 bar @ 50 Degrees C, 75 liter each;
jacket has two sections 120 liters each
bolt flat end
2404mm screw length.
Openings: top: 1-650mm, 1-250mm, 4-100mm side glassis, jacket: 3-40mm, bottom: 2-50mm
Number of Screws: 2. Internal Pressure: 0.005 bar (0.0725 psi). Internal Temperature: 50 °C (122 °F). Jacket Pressure: 6 bar (87 psi). Jacket Temperature: 50 °C (122 °F). Orientation: Horizontal.
