Type: Dryer-Fluid Bed
Manufacturer: Niro
Condition: Used
Material: Stainless Steel 304
Bowl Diameter: 1,340 mm (52.8 in)
Bowl Height: 9,600 mm (378 in)
vibrating fluid bed dryer
vibratory mechanism
304 stainless steel perforated fluid bed
openings: feed: 1-800mm, powder discharge: 1-635mm, top: 1-700mm manway, 2-600mm, 1-250mm, straight side: 3-500mm manways, bottom: 2-625mm, 1-500mm manway
dryer with springs but no frame
Orientation: Horizontal. Operational Mode: Continuous.
Type: Dryer-Fluid Bed
Manufacturer: Niro
Condition: Used
Material: Stainless Steel 304
Bowl Diameter: 1,100 mm (43.3 in)
Bowl Height: 6,000 mm (236 in)
continuous vibrating fluid bed dryer
perforated fluid bed
openings: feed: 1-600mm, powder discharge: 1-300mm, top: 1-750mm manway, 1-450mm, straight side: 3-450mm manways, bottom: 2-625mm each with a 625mm diameter x 980mm straight side s/steel tank
dryer mounted on carbon steel frame with springs
Orientation: Horizontal. Operational Mode: Continuous.
Type: Dryer-Fluid Bed
Manufacturer: Aeromatic-Fielder AG
Model: T5-2110
Condition: Used
Material: Stainless Steel 304
Capacity: 340 L (89.8 gallons)
Air Flow Rate: 3,600 m3/h (2,119 CFM)
fluid bed dryer system
50-250 Kg
With cylindrical chamber
the rupture channel 950mm dia x 2345mm high
Filter housing rated 2 bar and has volume of 1638 liter. Filter area 13 sq meter. W/(2) 304SS product bins, rated 2 bar, w/volume of 340 liter, base area of bin 0.45 sq meter, 1100mm/750mm dia x 500mm deep, w/60mm x 270mm sight glass.
Fine dust filter 19.3 sq meter. Steam air heater rated 467,2000 Kg/hr with air inlet of -10 deg C and outlet of +80 deg C. Steam pressure 4 bar. Fan rated 1.2 cbm/sec, static pressure 5000 N/sq meter, rated 8.5 KW @ 2900 rpm.
With hydraulic operated bin loader
Pressure: 2 bar (29 psi). Temperature: 80 °C (176 °F). Bowl Diameter: 1,000 mm (39.4 in). Bowl Height: 2,496 mm (98.3 in). Operational Mode: Batch.
Type: Dryer-Fluid Bed
Manufacturer: Glatt
Model: WST120
Condition: Refurbished/Rebuilt
Material: Stainless Steel 304
Capacity: 420 L (111 gallons)
Air Flow Rate: 5,981 m3/h (3,520 CFM)
250 Kg
Fluid Bed Dryer
batch type
Steam heater rated 140000 Kcal/hr steam
Motor: 3 phase
220/380 volt
With (2) product bins 1200mm upper diameter, 800mm lower diameter, sanitary polished
Drying chamber 3.5m high (11'6") x 1.2m diameter (48")
With a control panel indicating air temperature, timers, intervals, vibration indicator of dust collector
Pressure: 6 bar (87 psi). Bowl Diameter: 1,200 mm (47.2 in). Bowl Height: 3,500 mm (138 in). Product Density: 0.42 m3 (14.8 ft3). Operational Mode: Batch. Dust Collection: Yes.
