Featured
Stock Number: #70263
Dryer-Thin Film Luwa SMS D-850/4700/10 Stainless Steel 316
Heat Transfer Surface Area: 118.4 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 428 °F
Jacket Pressure: 188.5 psi
Jacket Temperature: 428 °F
Orientation: Horizontal
Vacuum Rated: Yes
Shell Diameter: 33.5 in
Shell Length: 189 in
Additional Information:

pressure internal rated 0.5 bar and full vauumc @ 220 degrees C. Jacket 13 bar @ 220 degrees C, Shell 850mm diameter x 4800mm long,

More Details…
Featured
Stock Number: #70267
Dryer Thin Film Luwa SMS DK600/4500/10 Stainless Steel 316
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

thin film continuous contact dryer (cooler) Jkt rated 8 bar @ 50 deg C Shell 600mm dia (24") x 4.492m (177") long

More Details…
Stock Number: #70272
7.5 m² (80.7 ft²) Stainless Steel 316L Dryer-Thin Film
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

thin film continuous contact dryer (cooler). Jacket rated 8 bar @ 50 degrees C, Shell 600mm diameter x 4492mm long.

More Details…
Stock Number: #70271
7.5 m² (80.7 ft²) Stainless Steel 316 Dryer-Thin Film
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

Jacket rated 8 bar @ 50 degrees C, Shell 600mm diameter x 4492mm long.

More Details…
Stock Number: #236136
Stainless Steel Austenitic Buss-SMS-Canzler GmbH D-015 Dryer-Thin Film
Heat Transfer Surface Area: 37.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 572 °F
Jacket Pressure: 217.6 psi
Jacket Temperature: 572 °F
Orientation: Horizontal
Shell Diameter: 22.4 in
Shell Length: 141.7 in
Additional Information:

jacketed thin film dryer, fabrik #0500/187, shell jackets 15 bar @ 300 degrees C (2 x 38 liter) 569mm diameter x 3.6m, rotor driven by 27kw, 3 phase, 50Hz, 400 volt, 1000 rpm Eexe 11 T2, IP55 motor, rotor speed 310 rpm,

More Details…
Stock Number: #70269
7.5 m² (80.7 ft²) Stainless Steel 316 Dryer-Thin Film
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

thin film continuous contact dryer (cooler). Jkt rated 8 bar @ 50 deg C, Shell 600mm dia (24") x 4.492m (177") long.

More Details…
Stock Number: #70266
7.5 m² (80.7 ft²) Stainless Steel 316L Dryer-Thin Film
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

thin film continuous contact dryer (cooler). Jkt rated 8 bar @ 50 deg C, Shell 600mm dia (24") x 4.492m (177") long.

More Details…
Stock Number: #70270
7.5 m² (80.7 ft²) Stainless Steel 316 Dryer-Thin Film
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

thin film continuous contact dryer (cooler). Jkt rated 8 bar @ 50 deg C, Shell 600mm dia (24") x 4.492m (177") long. Rotor driven by 25 KW, 3/50/380 volt motor, 260 rpm output speed.

More Details…
Stock Number: #70268
7.5 m² (80.7 ft²) Stainless Steel 316L Dryer-Thin Film
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

thin film continuous contact dryer (cooler) Jkt rated 8 bar @ 50 deg C Shell 600mm dia (24") x 4.492m (177") long

More Details…
Stock Number: #70264
Stainless Steel 316L Dryer-Thin Film
Heat Transfer Surface Area: 118.4 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 428 °F
Jacket Pressure: 188.5 psi
Jacket Temperature: 428 °F
Orientation: Horizontal
Vacuum Rated: Yes
Shell Diameter: 33.5 in
Shell Length: 189 in
Additional Information:

thin film continuous contact dryer. pressure internal 0.5 bar and full vacuum @ 220 degrees C. Jacket rated 13 bar @ 220 degrees C, Shell 850mm diameter x 4800mm long, Rotor was driven by 30 KW, 3/50/380 volt, 260 rpm output speed.

More Details…
Stock Number: #70265
7.5 m² (80.7 ft²) Stainless Steel 316 Dryer-Thin Film
Heat Transfer Surface Area: 80.7 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 248 °F
Jacket Pressure: 116 psi
Jacket Temperature: 122 °F
Orientation: Horizontal
Shell Diameter: 23.6 in
Shell Length: 176.9 in
Additional Information:

thin film continuous contact dryer (cooler) Jkt rated 8 bar @ 50 deg C Shell 600mm dia (24") x 4.492m (177") long

More Details…
Stock Number: #70250
16 m² (172.2 ft²) Stainless Steel 316 Dryer-Thin Film
Heat Transfer Surface Area: 172.2 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 392 °F
Jacket Pressure: 145 psi
Jacket Temperature: 392 °F
Orientation: Horizontal
Vacuum Rated: Yes
Shell Diameter: 39.4 in
Number of Shell Sections: 3
Shell Length: 236.5 in
Additional Information:

thin film continuous contact dryer Jkt rated 10 bar @ 200 deg C Shell 1000mm (40") dia x 6008mm long Rotor speed 80/160 rpm

More Details…
Stock Number: #70254
16 m² (172.2 ft²) Stainless Steel 316L Dryer-Thin Film
Heat Transfer Surface Area: 172.2 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 392 °F
Jacket Pressure: 145 psi
Jacket Temperature: 392 °F
Orientation: Horizontal
Vacuum Rated: Yes
Shell Diameter: 39.4 in
Number of Shell Sections: 3
Shell Length: 236.5 in
Additional Information:

thin film continuous contact dryer, dryer has 3 segments: each segments: internal pressure rated -1/0,5 bar @ 200 degrees C, total volume 1570 liter, jacket pressure rated 10 bar @ 200 degrees C, total volume 150 liter. Shell 1000mm (40") diameter x 6008mm long, Rotor speed 80/160 rpm. system included a feeder driven by a 0,8kW motor, manufactured by VEB Elektromotorenwerke, 3~/50Hz/660V/100rpm, ExeT3.

More Details…
Stock Number: #70262
Stainless Steel 316 Dryer-Thin Film
Heat Transfer Surface Area: 118.4 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 428 °F
Jacket Pressure: 188.5 psi
Jacket Temperature: 428 °F
Orientation: Horizontal
Vacuum Rated: Yes
Shell Diameter: 33.5 in
Shell Length: 189 in
Additional Information:

thin film continous contact dryer. Jkt rated 13 bar @ 220 deg C, int rated 0.5 bar and full vac @ 220 deg C. Shell 850mm (34") dia x 4800mm (15.8') long

More Details…
Stock Number: #70258
Stainless Steel 316L Luwa SMS 850/4700/10 Dryer-Thin Film
Heat Transfer Surface Area: 118.4 ft²
Internal Pressure Rating: 7.3 psi
Internal Temperature Rating: 428 °F
Jacket Pressure: 188.5 psi
Jacket Temperature: 428 °F
Orientation: Horizontal
Vacuum Rated: Yes
Shell Diameter: 33.5 in
Shell Length: 189 in
Additional Information:

thin film continuous contact dryer. Jkt rated 13 bar @ 220 deg C, Shell 850mm (34") dia x 4800mm (15.8') long,

More Details…
Page of 1
1 - 15 of 15 items
