Results 13 items found

Available equipment

Showing 13 of 13 matching equipment.

Featured
Stock Number: #246737
Rising/Falling Film Evaporator Buflovak/Blaw Knox x-320 steam chest Stainless Steel 316
Evaporation Rate: 14,900 lb/h
Total Heat Transfer Surface Area: 2,850 ft²
Orientation: Vertical
Pressure: 120 psi
Temperature: 300 °F
Vacuum: Yes
Number of Effects: 2
Vapor Body #1: 316 SS 36" OD x 102 " SS, lug Mounted Print weight 1400 lbs.
Vapor Body # 2: 316SS 42" OD x 102" SS, lug mounted Print weight 2000 lbs.
Steam Chest #1: 903 Sq.Ft. 316 SS tubes and tube sheets, CS shell. 36" OD x 319" OAL . 116 straight tubes, 1.5"OD x 239" Vertical lug mount.
Steam Chest # 2: 1924 Sq.Ft. 316 SS tubes and tube sheets, CS shell. 34" OD x 333" OAL 245 1.5" tubes 0.049" wall x 20' long. Vertical lug mount.
Condenser: 900 Sq.Ft. 316 SS tubes, tube sheets and heads, CS shell. 30" OD x 137" OAL, 430 straight tubes 1" OD x 0.049" wall x 8' long Horizontal saddle mounted.
Additional Information: Feed Heating: 316 SS plate & Frame Alfa Laval 27 Sq.Ft. & 51 Sq.Ft..
More Details ⟶
Stock Number: #220739
Stainless Steel 316 Rising/Falling Film Evaporator
Evaporation Rate: 16,000 lb/h
Total Heat Transfer Surface Area: 900 ft²
Pressure: 50 psi
Temperature: 300 °F
Additional Information: • tubular evaporation system manufactured by Buflovak-Blaw-Knox. Includes 5 main pieces and support equipment such as pumps and small plate heat exchanger. Main pieces are as follows:(D) 1st effect steam chest (heat exchanger), 900 Sq Ft. NB #8255/ 9393, SN # 17669/18701, (1997) rated for 50 psi at 300 degrees on the shell, Model 1256642. 36" diameter x 10' OAL mounted vertical. (C) 1st effect vapor separator, RRFC, 42" diameter x 9' OAL with top side man way and "York" style 931 316 SS demisting mesh packing for vapor carry over.(needs to be replaced). (E) 2nd effect heater, 4' diameter x 13' OAL, with (B) 38" diameter x 8' OAL separator with cone bottom. NB # 3136, serial # 11514, Rated for MAWP Vacuum at 179 degrees F. ( HSB # 2544B) Plant # S-11181-2. With 18" man way and sight glass. With 12" interconnecting pipe, and elbow pump. Overhead condenser (A) approx. 2000 Sq. ft., 316 SS , 2/4 pass on tube side(cooling) with 12" water inlet/outlet. Discharge of overheads to distillate. 30" diameter x 10' 3" OAL, saddle mounted, with two 40 Lb. steam jets to supply vacuum.
More Details ⟶
Stock Number: #247011
Stainless Steel 304 Buflovak/Blaw Knox Rising/Falling Film Evaporator
Evaporation Rate: 21,100 lb/h
Total Heat Transfer Surface Area: 4,200 ft²
Orientation: Vertical
Pressure: 14 psi
Temperature: 300 °F
Vacuum: Yes
Number of Effects: 2
Vapor Body #1: 304 SS top 54" diameter x 84" long (vapor) bottom is 24" diameter x 72" long. (liquid) Lug mounted, with welded dish heads.
Vapor Body # 2: 304 SS 64" diameter x 150' straight side with welded dish heads. Lug mounted. Manufactured by IPS Inc. serial # 05-1122, NB # 135.
Steam Chest #1: 2315 Sq.Ft., 304 SS with CS shell, vertical steam chest. 38" diameter x 157" long, with clamped heads mounted by lugs. Estimated 442 straight tubes 2" OD x 10" long.
Steam Chest # 2: 1906 Sq.Ft., 304SS tubes with CS shell vertical steam chest. 32" diameter x 163" long side with clamped heads, mounted by lugs. Estimated 364 straight tubes 2" OD x 10' long.
Condenser: Alfa Laval spiral, See stock # 246876 for details
Additional Information: Second Effect separator replaced by IPS, Inc.-Condenser changed from original design and now is an Alfa Laval spiral, IPP stock # 246876. 270 Sq.Ft., 316 SS clad on CS, 55 psi at 300 degrees F. Feed Heating: No.
More Details ⟶
Stock Number: #108064
Stainless Steel 304 Buflovak/Blaw Knox Dryer-Rotary Vacuum
Capacity Design: 125 ft3
Capacity Working: 82 ft3
Diameter: 48 in
Length: 120 in
Rated for Vacuum: Yes
Heat Transfer Surface Area: 125 ft²
Shaft Cored and National Board Stamped: Yes
Agitation Seal Type: Packing
Jacket Pressure: 50 psi
Jacket Temperature: 300 °F
Additional Information: HSB # 3332A Shell rated full vacuum 4' diameter x 10' long chamber Has 24" diameter cored removable shaft with paddles and bolt-on scraper blades. 3" Johnson rotary joint. Has 12" diameter bottom outlet with hinged swing bolt cover. 2-12" feed ports.
More Details ⟶
Stock Number: #220772
Stainless Steel 316 Buflovak/Blaw Knox Tank
Capacity (Design): 1,900 gallons
Orientation: Vertical
Diameter: 60 in
Straight-side Length: 148 in
Internal Pressure: 25 psi
Internal Temperature: 212 °F
Vacuum: Yes
Cone Length: 53 in
Support: Lugs
Additional Information: Vapor body/separators for evaporation system Vapor head and swirl breaker dimensions: 68" diameter x 148" long with a slight cone drop leg is 12" diameter x 120" long. All welded construction
More Details ⟶
Stock Number: #31727
626 kg/h (1,400 lb/h) Stainless Steel 304 Wiped/Thin Film Evaporator
Evaporation Rate: 1,400 lb/h
Total Heat Transfer Surface Area: 50 ft²
Diameter: 40 in
Height: 68 in
Pressure: 15 psi
Temperature: 400 °F
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Additional Information: 304 ELC SS 40% clad on Carbon steel (for product contact), thin film evaporator system Mfd by Buflovak 165 psi @ 400 deg F jkt. NB stamped 5931. Rotor was under driven by 20 HP, 3/60/220/440 volt mtr w/UL label, 480 rpm rotor speed. (motor for drive not available). Unit has external upper & lower bearings, mech seals on shaft. Unit has 3" feed port and 10" x 24" discharge into centrifugal vapor/liquid separator. 36" deep cone btm. W/system is 565 sq ft, 304LSS shell side, CS head, horiz condenser with 3/4" OD x 18 bwg, 304LSS tubes, 143" long. 6 pass tube side. 18" dia 304ELC SS shell 161" overall length. CS channels. Unit designed for 30 psi & full vac @ 400 deg F shell side; 100 psig @ 400 deg F tube side. Openings: shell 1-10", 1-3"; channels 2-4" one head, (2) 3/4" other head. Mfd by Patterson Kelly. Also w/unit is an 81 sq ft aftercondenser. Mfd by Graham, 304SS shell side, CS tube side. Unit rated 50 psig/full vac @ 150 deg F shell side; 75 psig @ 150 deg F tube side. Asme code constructed. 8" dia shell, 8' long tubes, 9'11" overall length.
More Details ⟶
Stock Number: #31726
626 kg/h (1,400 lb/h) Stainless Steel 304 Wiped/Thin Film Evaporator
Evaporation Rate: 1,400 lb/h
Total Heat Transfer Surface Area: 50 ft²
Diameter: 40 in
Height: 68 in
Pressure: 15 psi
Temperature: 400 °F
Vacuum: Yes
Mechanical Seal on Shaft: Yes
Additional Information: 304 ELC SS 40% clad on Carbon steel (for product contact), thin film evaporator system 165 psi @ 400 deg F jkt NB stamped 5932. Rotor was under driven by 20 HP, 3/60/220/440 volt mtr w/UL label, 480 rpm rotor speed Unit has external upper & lower bearings, mech seals on shaft. Unit has 3" feed port and 10" x 24" discharge into centrifugal vapor/liquid separator. 36" deep cone btm W/system is 565 sq ft, 304LSS shell side, CS head, horiz condenser with 3/4" OD x 18 bwg, 304LSS tubes, 143" long. 6 pass tube side. 18" dia 304ELC SS shell 161" overall length. CS channels. Unit designed for 30 psi & full vac @ 400 deg F shell side; 100 psig @ 400 deg F tube side. Openings: shell 1-10", 1-3"; channels 2-4" one head, (2) 3/4" other head. Mfd by Patterson Kelly. Also w/unit is an 81 sq ft aftercondenser. Mfd by Graham, 304SS shell side, CS tube side. Unit rated 50 psig/full vac @ 150 deg F shell side; 75 psig @ 150 deg F tube side. Asme code constructed. 8" dia shell, 8' long tubes, 9'11" overall length.
More Details ⟶
Stock Number: #102517
304.8 mm (12 in) Stainless Steel 316 Dryer-Drum
Diameter: 12 in
Length: 18 in
Drum Heating-Cooling: Heating
Heating Type: Steam
Drum Configuration: Single
Additional Information: single drum dip feed dryer Drum cored for steam heating Manual knife discharge Has 15" x 19" CS jkt feed pan 3/60/230/460 volt, rated 44 rpm max, 8.8 rpm min
More Details ⟶
Stock Number: #79679
Stainless Steel 304 Buflovak/Blaw Knox Dryer-Rotary Vacuum
Capacity Design: 55 ft3
Capacity Working: 40 ft3
Diameter: 32 in
Length: 120 in
Temperature: 300 °F
Pressure: 55 psi
Rated for Vacuum: Yes
Heat Transfer Surface Area: 84 ft²
Shaft Cored and National Board Stamped: Yes
Orientation: Horizontal
Agitation: Yes
Jacket Material: Carbon Steel
Additional Information: rotary vac dryer 32" dia x 10' long shell. Bolt flat heads 12" dia charge port, 12" center btm discharge Approx 10" dia SS hollowshaft. 69.4 ratio
More Details ⟶
no image found
Stock Number: #246882
Stainless Steel Other Buflovak/Blaw Knox Grainer Dryer-Pan
Capacity Design: 66 ft3
Capacity Working: 44 ft3
Diameter: 68 in
Height: 34 in
Pressure: 14 psi
Temperature: 300 °F
Vacuum Rated: Yes
Jacket?: Yes
Jacket Type: Standard
Jacket Material: Carbon Steel
Jacket Pressure: 25 psi
Jacket Temperature: 300 °F
Additional Information: Grainer # 2 Welded dish bottom and bolted top head.
More Details ⟶
no image found
Stock Number: #246883
Stainless Steel Other Buflovak/Blaw Knox Grainer Dryer-Pan
Capacity Design: 66 ft3
Capacity Working: 44 ft3
Diameter: 68 in
Height: 34 in
Pressure: 14 psi
Temperature: 300 °F
Vacuum Rated: Yes
Jacket?: Yes
Jacket Type: Standard
Jacket Material: Carbon Steel
Jacket Pressure: 25 psi
Jacket Temperature: 300 °F
Additional Information: Grainer # 3 Welded dish bottom and bolted top head.
More Details ⟶
no image found
Stock Number: #246880
Stainless Steel Other Buflovak/Blaw Knox Grainer Dryer-Pan
Capacity Design: 66 ft3
Capacity Working: 44 ft3
Diameter: 68 in
Height: 34 in
Pressure: 14 psi
Temperature: 300 °F
Vacuum Rated: Yes
Jacket?: Yes
Jacket Type: Standard
Jacket Material: Carbon Steel
Jacket Pressure: 25 psi
Jacket Temperature: 300 °F
Additional Information: Welded dish bottom and bolted top head.
More Details ⟶
no image found
Stock Number: #246881
Stainless Steel Other Buflovak/Blaw Knox Grainer Dryer-Pan
Capacity Design: 66 ft3
Capacity Working: 44 ft3
Diameter: 68 in
Height: 34 in
Pressure: 14 psi
Temperature: 300 °F
Vacuum Rated: Yes
Jacket?: Yes
Jacket Type: Standard
Jacket Material: Carbon Steel
Jacket Pressure: 25 psi
Jacket Temperature: 300 °F
Additional Information: Grainer # 1 SO63-6634 Welded dish bottom and bolted top head.
More Details ⟶
