Equipment Search

New and Used Equipment

Search our inventory of over 15,000 new and used industrial equipment. Filter by manufacturer, material of construction, industry uses, and technical specs.

Request a Quote

Sort

Searching equipment…

Active Filters

Equipment

Manufacturer: Paul Mueller

Clear all filters

Results 11 items found

Available equipment

Showing 11 of 11 matching equipment.

Featured

Stock Number: #214768

Still Paul Mueller P7140 Stainless Steel 316

Diameter: 48 in

Length: 8.9 ft

Pressure: 150 psi

Temperature: 336 °F

Controls: Yes

Support Type: Skid

Orientation: Vertical

Additional Information: 1,200 lbs./hr PyroPure Clean steam generator Produces pyrogen free pure steam that meets USP requirements With external shell and tube evaporator, double tube sheet 316LSS contact surfaces, polished to 20 ra max. blowdown cooler which serves as a pre-heater for water entering the evaporator steam seperator and feedwater pump Evaporater NB # 32477 serial #4767410-1 Shell rated for 150/FV psi at 366 degrees F tubes rated for 150/FV psi at 366 degrees F Cooler NB #32664 Serial # 4864670-1 shell rated for FV/150 psi at 336 degrees F tubes rated for FV/150 psi at 336 degrees F Feed water pump, 316SS manufactured by Fristam Pump direct driven by a 3 hp 3500 rpm AC motor All parts mounted on a skid with the following controls AB PLC control with Panel View Plus operator interface I/O cabinet and Motor staring cabinet complete with breaker Feedwater inlet is 1" TC sanitary Steam inlet is 1.5" flange(150 psi max) Pure steam outlet is 2" TC sanitary Condensate outlet is 1" FNPT drain is 1" TC, and instrument air is 1/4" FNPT Dimensions are 48" wide x 46.5" deep x 107" high. Shipping weight is 2,150 lbs.

More Details ⟶

Stock Number: #246911

Stainless Steel 304 Paul Mueller Tank

Capacity (Design): 9,500 gallons

Orientation: Horizontal

Diameter: 88 in

Straight-side Length: 351 in

Internal Pressure: 14 psi

Support: Saddle

Additional Information: • Vessel has an internal ladder of 304L SS. • Saddles have a 304 SS wear plate.

More Details ⟶

Stock Number: #216016

Stainless Steel 304 Packed Column

Diameter (1): 60 in

Length (overall): 696 in

Pressure: 180 psi

Vacuum: Yes

Temperature: 400 °F

Additional Information: Welded dish heads packed bed column ( with two repair tags, 2005, by CDI) Top packing bed is 5' from top under distribution tray, 9' bed of Koch-Glitsch Fleximax 200 in 316 SS Bottom bed 26'6" bed of Koch-Glitsch Fleximax 200 in 316 SS Column operates at 60 psi with a delta pressure of 40"wc across column.

More Details ⟶

Stock Number: #216324

Paul Mueller Plate and Frame Heat Exchanger

Heat Transfer Surface Area: 100 ft²

Hot-side Pressure: 150 psi

Hot-side Temperature: 150 °F

Number of Plates: 72

Additional Information: Chilled water service Size unknown, insulated

More Details ⟶

Stock Number: #216019

Stainless Steel 304 Tank

Capacity (Design): 7,600 gallons

Orientation: Vertical

Diameter: 108 in

Straight-side Length: 192 in

Internal Pressure: 50 psi

Internal Temperature: 525 °F

Does it have Agitation ?: Yes

Vacuum: Yes

Support: Lugs

Additional Information: • Type: Pressure tank (Flash Still) • Packing Manufacturer: Koch-Glitsch • Top Head: Accepts flash condenser • Internal Packing: Koch Flexichevron in 316L SS • Shipping Weight: 19,800lbs. • Inspection Manway: 24"

More Details ⟶
