Used and Unused Process Plants & Equipment

Stock Number: #701561

Unused Siemens EG-400-2 Steam Turbine

Power: 8,450 kW

Speed (RPM): 6076-7975

Inlet Pressure: 590 psi

Inlet Temperature: 385 °C

Inlet Steam Flow: 291,200 lb/h

Outlet Pressure: 93 psi

Extraction?: Yes

Extraction Points: 1

Extraction Details: Single cylinder extraction at 205psi.

Backpressure?: Yes

Stages: 1

Rotation Direction: Clockwise

Additional Information: • Spare parts & spare rotor available separately. • With SIHI gland steam condenser. Single cylinder extraction backpressure of Axial flow type, extraction steam 205 psi (14.2 bar),Steam consumption 130 ton/hr.

More Details ⟶

Stock Number: #220587

Aluminum Pump-Vacuum

Air Flow: 650 m3/h

Discharge Pressure: 0.15 psi

Seal Type: Liquid Ring

Temperature: 60 °C

Cooling or Seal Water: Yes

Additional Information: water seal vacuum pump aluminum bronze rated by 100 mbar @ 60 degrees C

Motor:

pump is driven by electrical motor 400-690V with a 110 liter receiver, manufactured by Siemens, serial number 94/1023C, pressure rated 2 bar @ 100 degrees C, with a shell and tube condenser, manufactured by Funke, serial number 361702, pressure shell side 16 bar (volume 2,3 liter, pressure tube side 10 bar (volume 1,62 liter) pump is skid mounted with a 110 liter receiver manufactured by Siemens serial number 94/1023C pressure rated 2 bar @ 100 degrees C with a shell and tube condenser manufactured by Funke serial number 361702 pressure shell side 16 bar (volume 2,3 liter, pressure tube side 10 bar (volume 1,62 liter) skid dimension: 1465mm x 1100mm x 945mm weight 520 kg CE certified type ELMO-F2BV5161-0KD92-8P-Z, EExeII

More Details ⟶

Stock Number: #220591

120 m3/h (70.6 CFM) Stainless Steel 316 Pump-Vacuum

Air Flow: 120 m3/h

Seal Type: Liquid Ring

Temperature: 140 °F

Additional Information: 40 mbar stainless steel (1.4581) water seal vacuum pump skid mounted 1.500 x 1.100x 885 mm with condenser and 140 l receiver

More Details ⟶

Stock Number: #96447

2,250 m3/h (1,300 CFM) Pump-Vacuum

Air Flow: 2,250 m3/h

Discharge Pressure: 0.2 bar

Orientation: Horizontal

Additional Information: 220 mbar water seal vac pump. Number of stages: 2 Includes valve and silencer

More Details ⟶

Stock Number: #94657

Unused Siemens HG32/20/10 Steam Turbine

Power: 8,350 HP

Speed (RPM): 8654-10400

Inlet Pressure: 1,850 psi

Inlet Temperature: 965 °F

Inlet Steam Flow: 110,350 lb/h

Outlet Pressure: 205 psi

Outlet Temperature: 480 °F

Outlet Steam Flow: 106,900 lb/h

Backpressure?: Yes

Additional Information: back pressure turbine.steam consumption 13.2 lb/BHP/hr,Total flow 106900 lbs/hr.

More Details ⟶

Stock Number: #94661

Unused Siemens HG32/20/10 Steam Turbine

Power: 8,350 HP

Speed (RPM): 8654-10400

Inlet Pressure: 1,850 psi

Inlet Temperature: 965 °F

Inlet Steam Flow: 110,350 lb/h

Outlet Pressure: 205 psi

Outlet Temperature: 480 °F

Outlet Steam Flow: 106,900 lb/h

Backpressure?: Yes

Additional Information: back pressure turbine. steam consumption 13.2 lb/BHP/hr Total flow 106900 lbs/hr.

More Details ⟶

Stock Number: #94663

Siemens HG40/25/25 Steam Turbine

Power: 13,700 HP

Speed (RPM): 5094-5945

Inlet Pressure: 1,850 psi

Inlet Temperature: 965 °F

Inlet Steam Flow: 185,350 lb/h

Outlet Pressure: 205 psi

Outlet Temperature: 480 °F

Outlet Steam Flow: 148,200 lb/h

Backpressure?: Yes

Additional Information: back pressure turbine, steam consumption 13.55 lb/BHP/hr, inlet temp normal 940 deg F, inlet temp max 965 deg F, Total flow 148200 lbs/hr.

More Details ⟶

Stock Number: #94665

Siemens HG40/25/25 Steam Turbine

Power: 13,700 HP

Speed (RPM): 5660

Inlet Pressure: 1,850 psi

Inlet Temperature: 940 °F

Inlet Steam Flow: 185,350 lb/h

Outlet Pressure: 205 psi

Outlet Temperature: 480 °F

Outlet Steam Flow: 148,200 lb/h

Backpressure?: Yes

Additional Information: back pressure turbine. steam consumption 13.55 lb/BHP/hr, Total flow 148200 lbs/hr.

More Details ⟶

Stock Number: #94660

Unused Siemens K-1100-2 Steam Turbine

Power: 8,100 HP

Speed (RPM): 3857-4560

Inlet Pressure: 210 psi

Inlet Temperature: 480 °F

Inlet Steam Flow: 86,600 lb/h

Outlet Pressure: 1.7 psi

Outlet Temperature: 210 °C

Outlet Steam Flow: 83,000 lb/h

Condensing?: Yes

Stages: 1+21

Rotation Direction: Counter-Clockwise

Additional Information: condensing turbine. inlet pressure normal 190 psig steam consumption 9.9 lb/BHP/hr, Total flow 83000 lbs/hr.

More Details ⟶

Stock Number: #232386

Siemens Starter And Switch Gear Electrical

Electrical Phase:

Additional Information: One lot of sixteen (16) Siemens Air Circuit Breakers, consisting of the following: 12 Pieces Siemens RLE 1600-Type RLE,3 pole 3 phase, 1600 amp 65kA at 635 volts, draw out mounting. 3 Pieces Siemens RL 4000 Type RL, rated 600 vac, draw out mounting. 1 piece Siemens RL 2000 , rated 2000 amps, Trip function LSIG, 65 kA at 480 volts, Draw out mounting.

More Details ⟶

Stock Number: #208815

Stainless Steel 304 Siemens 2BE1-203-8HY4Z Pump-Vacuum

Air Flow: 750 CFM

Discharge Pressure: 1.1 psi

Orientation: Horizontal

Seal Type: Liquid Ring

Temperature: 15 °F

Cooling or Seal Water: Yes

Additional Information: Instruction Manual Available • Medium: Gas • Permissible absolute intake pressure: 33mbar abs • Permissible absolute compression: 900-1100 mbar abs • Permissible temperature range of intake medium: 0 degrees C to 80 degrees C • Operating liquid: Type (generally water) • Shaft sealing liquid: Water • Temperature: 15 degrees C or operating temp .10 degrees C< boiling point • Volume: Flow depends on style of stuffing box

More Details ⟶

Stock Number: #222308

Unused 149.1 kW (200 HP) Carbon Steel Motor Electrical

Motor Power: 200 HP

Motor RPM: 3,573

Additional Information: horizontal electric motor kW 148.2 AMPS 216 Class insul - F

More Details ⟶

Stock Number: #212957

Unused Siemens EG-400-2 Steam Turbine Rotor

Additional Information: Spare rotor for steam turbine stock # 701561 Manufactured from a forged blank of Alloy, containing impulse blades, reaction blades, and moving blades.

More Details ⟶
