Stock Number: #208223
Stainless Steel 316 Thies Kg Coesfeld Gmbh 2 V 410-24, Dryer-Holoflite & Screw
Width: 700 mm
Length: 3,750 mm
Number of Screws: 2
Internal Pressure: 0.07 psi
Internal Temperature: 122 °F
Jacket Pressure: 6 bar
Jacket Temperature: 50 °C
Orientation: Horizontal
Additional Information: type Variocleaner Rated internal pressure 0.005 bar @-10/50 Degrees C carbon steel, heated screws rated 3 bar @ 50 Degrees C, 75 liter each; jacket has two sections 120 liters each bolt flat end 2404mm screw length. Openings: top: 1-650mm, 1-250mm, 4-100mm side glassis, jacket: 3-40mm, bottom: 2-50mm
More Details ⟶
Stock Number: #219940
Stainless Steel 321 Thies Kg Coesfeld Gmbh Shell and Tube Heat Exchanger
Heat Transfer Surface Area: 247 m²
Orientation: Vertical
Shell Pressure: 6.2 bar
Shell Temperature: 250 °C
Shell Material: Stainless Steel 321
Tube Pressure: 6.2 bar
Tube Temperature: 250 °C
Tube Material: Stainless Steel 321
Vacuum: Yes
Shell Diameter: 1,400 mm
Head Material: Stainless Steel 321
Length: 2,500 mm
Additional Information: multi pass, expansion bellow, (1) domed head Tube Number: 1,260. Tube Diameter: 25 mm. Tube Length: 2,500 mm. Nozzle Schedule: - Openings: Tubeside - 1 x domed head with 1-800mm, 1 x head with 1-400mm; Shell - 1-600mm, 1-250mm, 1-200mm.
More Details ⟶
Stock Number: #219925
31 m² (333.7 ft²) Stainless Steel Austenitic Shell and Tube Heat Exchanger
Heat Transfer Surface Area: 31 m²
Orientation: Vertical
Shell Pressure: 6 bar
Shell Temperature: 300 °C
Shell Material: Stainless Steel Austenitic
Tube Pressure: 6 bar
Tube Temperature: 300 °C
Tube Material: Stainless Steel Austenitic
Vacuum: Yes
Shell Diameter: 500 mm
Head Material: Stainless Steel Austenitic
Length: 2,500 mm
Additional Information: Expansion bellows: Yes, on shell single pass (2) 1.4571 s/steel bonnet heads Tube Number: 162. Tube Diameter: 25 mm. Tube Length: 2,500 mm. Nozzle Schedule: - Tube openings: 1 x head with 1-200mm, 1-100mm; 1 x head with 1-200mm, 1-100mm - Shell openings: 3-50mm.
More Details ⟶
Stock Number: #219938
120 m² (1,300 ft²) Stainless Steel 321 Shell and Tube Heat Exchanger
Heat Transfer Surface Area: 120 m²
Orientation: Vertical
Shell Pressure: 20 bar
Shell Temperature: 250 °C
Shell Material: Stainless Steel 321
Tube Pressure: 6 bar
Tube Temperature: 250 °C
Tube Material: Stainless Steel 321
Vacuum: Yes
Shell Diameter: 1,000 mm
Head Material: Stainless Steel 321
Length: 2,500 mm
Additional Information: • Expansion bellow: Yes domed head single pass expansion bellow (1) 1.4571 stainless steel dished head, (1) doemd head Tube Number: 616. Tube Diameter: 25 mm. Tube Length: 2,500 mm. Nozzle Schedule: - Tubeside openings: 1 x domed head with 1-600mm, 1 x head with 1-300mm - Shell openings: 1-250mm, 1-150mm.
More Details ⟶
