swing bolt top
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Sparkler
Model: HRC-100
Condition: Used
Material: Stainless Steel 304
Filtration Area: 10.9 m² (117 ft²)
Diameter: 1,219 mm (48 in)
(12) 48" long horiz filter plates
rotate to vert position for discharge
Designed for dry cake discharge via screw conveyor (conveyor and conveyor drive missing)
Approx 560 gal volume
18 cu ft cake capacity (1/2" clearance)
Designed for pneumatic discharge and hydraulically rotating plates
(Vibrators and hydraulic rotating pump missing)
Orientation: Horizontal. Pressure: 5.17 bar (75 psi). Overall Length: 1,651 mm (65 in). Jacket: Yes. Jacket Pressure: 5.52 bar (80 psi). Jacket Type: Half Pipe/Limpet.
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Sparkler
Model: 14-S-7
Condition: Used
Material: Stainless Steel 304
Filtration Area: 0.579 m² (6.23 ft²)
Diameter: 406 mm (16 in)
Cake capacity: 0.229 cubic feet
Has scavenger plate
Orientation: Vertical. Overall Length: 229 mm (9 in).
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Sparkler
Model: HRC200
Condition: Used
Material: Stainless Steel 316
Filtration Area: 19.2 m² (207 ft²)
Diameter: 1,219 mm (48 in)
ASME #19142
250" thick heads
187" shell
Tank has 1100 gal capacity
(1) dish head is hinged
and has swing bolts
Horiz tank, horiz plate design
(12) plates, 34.5 cu ft cake capacity
Dry cake discharge w/hydraulic cylinder to rotate plates to vert for cake discharge
Unit has (12) 1" openings with manifold for filtrate discharge
Pressure: 4.14 bar (60 psi). Temperature: 204 °C (400 °F).
Type: Filter
Subtype: Pressure Leaf
Manufacturer: Sparkler
Model: 18-S-7
Condition: Used
Material: Stainless Steel 316
Filtration Area: 1.05 m² (11.3 ft²)
Pressure: 4.14 bar (60 psi)
0.141 " tank thickness
with scavenger plate
0.414 CuFt cake capacity
7 plates (number of plates included)
Temperature: 177 °C (350 °F).
