Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Mueller
Condition: Used
Material: Stainless Steel 304
Capacity (Design): 9,650 L (2,550 gallons)
Internal Pressure: 1.72 bar (25 psi)
Tank is suitable for agitator mounting through top center port.
Internal Full Vacuum: Yes. Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 148.9 °C (300 °F). Jacket Material of Construction: Stainless Steel 304. Body Only: Yes. Orientation: Vertical. Diameter: 1,600 mm (63 in). Straight Side Length: 5,200 mm (204 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Mueller
Model: F
Condition: Used
Material: Stainless Steel 316
Capacity (Design): 1,500 L (400 gallons)
Internal Pressure: 5.2 bar (75 psi)
Finish: #2B on interior surfaces
Insulated & cladded- Pharma
Internal Full Vacuum: Yes. Internal Temperature: 93.3 °C (200 °F). Sanitary Construction: Yes. Jacket Pressure: 6.9 bar (100 psi). Jacket Temperature: 93.3 °C (200 °F). Body Only: Yes. Orientation: Vertical. Diameter: 1,050 mm (42 in). Straight Side Length: 1,500 mm (59 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Manufacturer: Superior Welding
Condition: Used
Material: Stainless Steel 304
Clad: Yes
Capacity (Design): 3,800 L (1,000 gallons)
Internal Pressure: 10.3 bar (150 psi)
no motor
Internal Temperature: 148.9 °C (300 °F). Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 148.9 °C (300 °F). Orientation: Vertical. Agitation: Yes. Diameter: 1,850 mm (72 in). Straight Side Length: 1,350 mm (54 in). Support Type: Lugs.
Type: Reactor
Subtype: Batch-Type Agitated
Condition: Used
Material: Stainless Steel 304
Capacity (Design): 1,350 L (360.1 gallons)
Jacket Material of Construction: Carbon Steel
Jacket: Carbon steel on straight side and bottom dish of vessel Lip: Carbon steel
Agitation: Yes. Diameter: 1,150 mm (45 in). Straight Side Length: 1,150 mm (45 in).
