Rotary Vacuum Paddle Dryer with heated shaft. Vessel rated for Full vacuum internal 316SS internals, SS 1/2 pipe coil jacket. one head bolted dished, one head welded dished. Unit has approx. 12" diameter heated shaft with paddle agitator blades. Shaft is direct coupled to a gear reducer motor3/60/230/460 volt Openings inlcude: (1) 18" Top, (1) 12" x 16" end port with hinged cover, Bottom center discharge.
Type: Dryer-Rotary Vacuum
Manufacturer: Buss AG Basel Schwein
Condition: Used
Material: Stainless Steel 316
Capacity Design: 2.5 m3 (90 ft3)
Capacity Working: 1.7 m3 (60 ft3)
Rotary Vacuum Paddle Dryer with heated shaft. Vessel rated for Full vacuum internal 316SS internals SS 1/2 pipe coil jacket one head bolted dished, one head welded dished. Unit has approx. 12" diameter heated shaft with paddle agitator blades. Shaft is direct coupled to a gear reducer 3/60/230/460 volt Openings include: (1) 18" Top, (1) 12" x 16" end port with hinged cover, Bottom center discharge.
Diameter: 1,219 mm (48 in). Length: 3,658 mm (144 in). Height: 1,422 mm (56 in). Orientation: Horizontal. Agitation Seal Type: Packing. Jacket Material: Stainless Steel Other. Jacket Pressure: 4.1 bar (60 psi). Jacket Type: Half Pipe/Limpet.
Type: Dryer-Rotary Vacuum
Manufacturer: Blaw Knox
Condition: Used
Material: Stainless Steel 316
Capacity Design: 7.9 m3 (280 ft3)
Capacity Working: 5.4 m3 (190 ft3)
Shell rated full vac @ 300 deg F Has 24" dia removable cored rotor w/SS paddles and teflon scrapers Openings: top 2-24"; btm 1-24" No drive grearbox or rotary joint
Diameter: 1,219 mm (48 in). Length: 9,144 mm (360 in). Temperature: 148.9 °C (300 °F). Jacket Material: Carbon Steel. Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 148.9 °C (300 °F).
Type: Dryer-Rotary Vacuum
Manufacturer: Krauss Maffei
Model: DTB630C-List-Discotherm
Condition: Used
Material: Stainless Steel 316
Capacity Design: 0.72 m3 (25.4 ft3)
Capacity Working: 0.63 m3 (22.2 ft3)
vac dryer (cooler). 316SS shell Total capacity 0.72 cbm Shell 600mm (24") dia x 3.8m (12'6") long Has 18" dia removable cored rotor. Has 9" long scraper blades on shaft. Has (17) fixed delumpers on str side of vessel. Openings: top 2-24" w/bolt cover; btm 3-2", 2-8".
Diameter: 600 mm (23.6 in). Length: 3,800 mm (149.6 in). Height: 2,500 mm (98.4 in). Temperature: 50 °C (122 °F). Pressure: 6 bar (87 psi). Heat Transfer Surface Area: 14.3 m² (153.9 ft²). Orientation: Horizontal. Operational Mode: Continuous. Agitation: Yes. Jacket Material: Stainless Steel 304. Jacket Pressure: 7 bar (101.5 psi). Jacket Temperature: 50 °C (122 °F).
Type: Dryer-Rotary Vacuum
Manufacturer: Stokes
Model: 900-59-125
Condition: Used
Material: Stainless Steel 316
Capacity Design: 7 m3 (247.2 ft3)
Diameter: 1,219 mm (48 in)
jacketed rotary vacuum dryer 3/50/380 volt Cleveland 63-55:1 ratio 3.8 HP, 1750 rpm gearbox shaft cored for steam heating, no national board, rated 50 psi @ 300 degrees F (1-straight side and 1-each end) Rotary union joint, outboard bearings. Unit with dust collector. Openings: top (2) 3' x 18 1/2" hinged access covers with counter balanced mechanism, 2-12"; end 1-8"; bottom 1-10" with manual open/close mechanism; jacket 4-6", 4-2", 4-1", 4-3/4"; shaft 1-2", 1-1 1/2".
Length: 6,096 mm (240 in). Temperature: 148.9 °C (300 °F). Shaft Cored and National Board Stamped: Yes. Orientation: Horizontal. Operational Mode: Batch. Agitation: Yes. Dust Collection: Yes. Jacket Material: Carbon Steel. Jacket Pressure: 3.4 bar (50 psi). Jacket Temperature: 148.9 °C (300 °F).
