Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Condition: Unused
Material: Carbon Steel
Heat Transfer Surface Area: 28.8 m² (310 ft²)
Orientation: Horizontal
Type BEM.
Replacement shell, spare, no heads with the unit.
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 177 °C (350 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 177 °C (350 °F). Tube Material: Carbon Steel. Tubesheet Material: Carbon Steel. Vacuum: Yes. Shell Diameter: 406 mm (16 in). Length: 3,575 mm (141 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 135. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 3,575 mm (141 in). Tube Thickness: 0.08 mm (0.00315 in). Nozzle Schedule: 3" outlet, 10" inlet, (2) 3/4", 3/4" vent, 3/4" drain..
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Model: 20-42 BEM
Condition: Used
Material: Hastelloy - C276
Heat Transfer Surface Area: 19.6 m² (211 ft²)
Orientation: Vertical
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204 °C (400 °F). Tube Material: Hastelloy - C276. Tubesheet Material: Hastelloy - C276. Vacuum: Yes. Shell Diameter: 508 mm (20 in). Head Material: Hastelloy - C276. Length: 1,022 mm (40.3 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 324. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,016 mm (40 in). Tube Thickness: 1.24 mm (0.049 in). Nozzle Schedule: Two 6", two 3", Two 1", one 0.75".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Model: BEM 20-42
Condition: Used
Material: Hastelloy - Other
Heat Transfer Surface Area: 20.1 m² (216 ft²)
Orientation: Vertical
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204 °C (400 °F). Shell Material: Carbon Steel. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204 °C (400 °F). Tube Material: Hastelloy SB-626. Tubesheet Material: Hastelloy SB-575. Vacuum: Yes. Shell Diameter: 5,131 mm (202 in). Head Material: Hastelloy - Other. Length: 1,016 mm (40 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 324. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,016 mm (40 in). Tube Thickness: 12.4 mm (0.49 in). Nozzle Schedule: Two 6", two 3" two 1"one 3/4".
Type: Heat Exchanger
Subtype: Shell and Tube
Manufacturer: Atlas Industrial
Condition: Used
Material: Stainless Steel Austenitic
Heat Transfer Surface Area: 3.81 m² (41 ft²)
Orientation: Horizontal
8367-Austenitic stainless tubes
8367-Austenitic stainless tube sheets
8367-Austenitic stainless heads
TEMA type BEM
size 10-54
Shell Pressure: 10.3 bar (150 psi). Shell Temperature: 204 °C (400 °F). Shell Material: Stainless Steel 304L. Tube Pressure: 10.3 bar (150 psi). Tube Temperature: 204 °C (400 °F). Tube Material: Stainless Steel Austenitic. Tubesheet Material: Stainless Steel Austenitic. Vacuum: Yes. Shell Diameter: 273 mm (10.8 in). Head Material: Stainless Steel Austenitic. Length: 1,321 mm (52 in). Shell-side Passes: 1. Tube-side Passes: 1. Tube Type: Straight Tube. Tube Number: 48. Tube Diameter: 19.1 mm (0.75 in). Tube Length: 1,321 mm (52 in). Tube Thickness: 1.24 mm (0.049 in). Nozzle Schedule: (2x) 3" nozzles, (2x) 2" nozzles, (4x) 1" nozzles..
