Stainless Steel 316 Dryer-Shelf 9.8 m² (105 ft²) For Sale - IPP# 704176

Type: Dryer-Shelf

Manufacturer: Calmic (William Boulton)

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 4 m² (43.1 ft²)

Vacuum Rated: Yes

vacuum shelf dryer system, oil heated, (2) 470mm wide x 930mm long x 40mm deep stainless steel trays, built on control panel with heater, circulation pump, vacuum pump and thermal reset trip, unit with (1) oil circulation pump driven by 1 hp, 3/50/360/440 volt, 1420 rpm motor, (1) carbon steel single stage vacuum pump, manufactured by General engineering ltd, driven by 3 kw, 3/50/220-240/380-415 volt, 1420 rpm motor

Number of Shelves: 4. Shelf Length: 930 mm (36.6 in). Shelf Width: 470 mm (18.5 in). Chamber Height: 40 mm (1.57 in). Chamber Width: 470 mm (18.5 in). Chamber Length: 930 mm (36.6 in). Number of Pans: 2. Pan Capacity: 0.03 m3 (1.23 ft3).

Type: Dryer-Shelf

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 4.5 m² (48 ft²)

Vacuum Rated: Yes

vacuum shelf dryer. shelves cored for steam heating. Distance between shelves 3". Hinged front door with swing bolt closure. Also 1-4" sight glass. Unit with full insulation. Openings: vacuum 1-2 1/2"; steam 2-1 1/4", 4-3/4".

Number of Shelves: 4. Shelf Length: 1,041 mm (41 in). Shelf Width: 1,067 mm (42 in). Chamber Height: 1,702 mm (67 in). Chamber Width: 1,524 mm (60 in). Chamber Length: 1,524 mm (60 in). Orientation: Vertical. Temperature: 100 °C (212 °F). Number of Pans: 0.

Type: Dryer-Shelf

Manufacturer: Hering

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 10 m² (107.6 ft²)

Vacuum Rated: Yes

Vacuum Shelf Dryer, electrically heated. Shelves with 19 pans, 990mmx490mmx50mm, chamber volumn is 1,400 liters, Vacuum Shelf Dryer by 220V 3/ PE 50Hz, (1) control cabinet.

Number of Shelves: 10. Shelf Length: 1,000 mm (39.4 in). Shelf Width: 1,000 mm (39.4 in). Shelf Pressure: -0.97 bar (-14 psi). Shelf Temperature: 200 °C (392 °F). Temperature: 200 °C (392 °F). Number of Pans: 19. Pan Capacity: 0.46 m3 (16.2 ft3).

Type: Dryer-Shelf

Manufacturer: Devine

Condition: Used

Material: Stainless Steel 316

Heat Transfer Surface Area: 10.2 m² (110 ft²)

Vacuum Rated: Yes

Number of Shelves: 10. Shelf Pressure: 2.1 bar (30 psi). Shelf Temperature: 204.4 °C (400 °F). Chamber Height: 1,219 mm (48 in). Chamber Width: 1,016 mm (40 in). Chamber Length: 1,016 mm (40 in). Orientation: Horizontal. Temperature: 204.4 °C (400 °F). Number of Pans: 30. Pan Capacity: 0.42 m3 (15 ft3).
