single screw Ko-Kneader system, processing length 16 L/D, carbon steel heated screw, 15mm screw oscillating stroke, screw root diameter 65mm, Theo. pitch in kneading zone (2-spirals) 60mm, pitch in infeed zone (1-spiral) 55mm, free volume (5 barrel section) 5.35 dm3, screw driven by a 2-speed motor, 90kw, 3/50/380/400/415/660/690 volt, 1481/1483/1485 rpm or 105kw, 3/60/440 volt, 1780 rpm, cast chrome steel barrel, barrel with special high nickel content carbon steel liner and kneading pins, barrels steam/water heated, (4) Regloplas type P160 water/steam heater temperature controllers for barrel heating, 6.5 liter volume, rated 6 bar @ 160 deg C, (1) 1m wide x 4m cooling length carbon steel chilled conveyor, manufactured by Bergerbachmann, belt driven by approx 1.1kw motor, 200mm diameter squeezing roll, 400mm diameter cooling roll, conveyor with Netzsch Condux carbon steel Granulator, type CS-300-800-11, serial # 6889, rotor speed 600 rpm, (2) Mixaco SM-600-D stainless steel high intensity mixers, 600ltr capacity, driven by 45kw, 3/50/400/690 volt 740 rpm motor, air pressure 6 bar, total volume 750 liter, 1180mm diameter x 690mm deep, 350mm feed, 300mm discharge with valve, each mixer with it own bag charging station
Type: Extruder
Manufacturer: SMS Buss
Model: K200S Ko-Kneader
Condition: Used
with chrome screw and chrome lined barrel. Jacketed barrel for cooling, hinged longitudinally for cleaning and maintenance.
Type: Extruder
Model: TCS-70-16D Kneader
Condition: Used
Material: Carbon Steel
Diameter: 70 mm (2.8 in)
Number of Heating Zones: 5
single screw Ko-Kneader system, proceesing length 16 L/D, carbon steel heated screw, screw oscillation stroke 10.5mm, screw root diameter 45mm, Theoretical pitch in kneading zone (2-spirals) 42mm, pitch in infeed zone (1-spiral) 38mm, free zone (5-barrel section) 2.04 dm3, screw driven by a 2-speed motor, 45kw, 3/50/380/400/415/660/690 volt, 1480/1475 rpm or 55kw, 3/60/440 volt, 1775 rpm, cast chrome steel barrel, barrel with special high nickel content carbon steel liner and kneading pins, barrels steam/water heated, (4) Regloplas type P160/9/SG5/IK/R145 water/steam heater temperature controllers, 6.5 ltr volume, rated 6 bar @ 160 deg C, (1) 600mm wide x 3m long chilled rubber belt conveyor with Netzsch Condux Granulator, (2) Tricool chillers, 2) 21.6 cubic foot (0.6 cubic meter) carbon steel ribbon mixer, 550mm wide x 1680mm long x 700mm deep, interupted ribbon, driven by 7.5 hp, 3/60/415 volt, 1405 rpm motor, end bottom discharge with pneumatic operated slide valve, 2-650mm x 650mm inspection ports with hinged covers,
Screw Length: 1,300 mm (51.2 in). Feeder: Yes. Number of Cooling Zones: 1.
Type: Extruder
Condition: Used
Material: Carbon Steel
Diameter: 63 mm (2.5 in)
Feeder: Yes
63mm, single screw extrusion line, approx 60 kg/hr of 800mm wide plastic sheet), line consists of: (1) Bone Brother 63mm x 2m long c/steel single screw extruder, motor with cooling fan, barrel with (5) fans driven by 0.33 kw, 3/50/415 volt, 2800 rpm motors, 126mm x 38mm feed opening with s/steel feed hopper, (1) 3-roll calender, rolls 300mm diameter x 800mm long, rolls with mirror finish, each roll is oil heated with its own oil heater, each roll gap adjuster has a hydraulic ram driven by 4 kw, 3/50/380-420 volt, 1435 rpm motor vai a Eurodrive gearbox, the calender is mounted on a moveable skid , skid has a hydraulic raise/lower mechanism, (1) end of line Gillard & Co sheet cutter, mounted on wheels, totally enclosed in a cabinet, system with control panels.
Type: Extruder
Condition: Used
Material: Carbon Steel
Diameter: 20 mm (0.79 in)
Number of Heating Zones: 4
Bone Brothers lab size single screw extruder. Unit has (4) electrically heated zones. Unit is complete with 7" diameter x 5" high stainless steel feed hopper cooling bath and control panel.
Screw Length: 420 mm (16.5 in). Feeder: Yes. Heating type: Electric.
