w/single ribbon type agit
no int rating
32" dia x 8' long shell
Bolt flat heads w/1-2" opening
16" dia charge port
12" dia center btm discharge
No drive or motor
Type: Dryer-Rotary Vacuum
Manufacturer: Devine
Condition: Used
Material: Stainless Steel 316
Capacity Design: 2.83 m3 (100 ft3)
Capacity Working: 1.98 m3 (70 ft3)
Rotary vacuum dryer
Vessel rated for Full vacuum
12.5" diameter cored shaft with 24 fixed plows.
Outboard bearings with packing glands.
Diameter: 1,219 mm (48 in). Length: 3,048 mm (120 in). Rated for Vacuum: Yes. Heat Transfer Surface Area: 11.7 m² (126 ft²). Shaft Cored and National Board Stamped: Yes. Orientation: Horizontal. Agitation Seal Type: Packing. Jacket Pressure: 2.41 bar (35 psi). Jacket Temperature: 104 °C (220 °F).
Type: Dryer-Rotary Vacuum
Manufacturer: Devine
Condition: Used
Material: Stainless Steel 304
Capacity Design: 3.77 m3 (133 ft3)
Capacity Working: 2.83 m3 (100 ft3)
54" dia x 10' long shell
16" dia charge port w/cover, 16" dia hydraulic operated center btm outlet.
Bolt flat ends. Approx 8" dia SS hollowshaft w/SS paddles.
Diameter: 1,372 mm (54 in). Length: 3,048 mm (120 in). Rated for Vacuum: Yes. Heat Transfer Surface Area: 13.1 m² (141 ft²). Orientation: Horizontal. Agitation: Yes. Jacket Material: Carbon Steel. Jacket Pressure: 3.45 bar (50 psi). Jacket Temperature: 204 °C (400 °F).
Type: Dryer-Rotary Vacuum
Manufacturer: Devine
Condition: Used
Material: Stainless Steel 304
Capacity Design: 3.77 m3 (133 ft3)
Capacity Working: 2.83 m3 (100 ft3)
Rotary vacuum dryer
54" dia x 10' long shell.
16" dia charge port w/cover
10" center btm outlet.
Bolt flat heads w/2-4" end discharge.
16" x 22" end opening w/bolt cover.
Approx 8" x 8" sq hollowshaft w/SS paddles, gear driven.
No motor.
Diameter: 1,372 mm (54 in). Length: 3,048 mm (120 in). Rated for Vacuum: Yes. Heat Transfer Surface Area: 13.1 m² (141 ft²). Orientation: Horizontal. Agitation: Yes. Jacket Material: Carbon Steel.
Type: Dryer-Rotary Vacuum
Manufacturer: Blaw Knox
Condition: Used
Material: Stainless Steel 316
Capacity Design: 7.93 m3 (280 ft3)
Capacity Working: 5.38 m3 (190 ft3)
Shell rated full vac @ 300 deg F
Has 24" dia removable cored rotor w/SS paddles and teflon scrapers
Openings: top 2-24"; btm 1-24"
No drive grearbox or rotary joint
Diameter: 1,219 mm (48 in). Length: 9,144 mm (360 in). Temperature: 149 °C (300 °F). Rated for Vacuum: Yes. Heat Transfer Surface Area: 35 m² (377 ft²). Jacket Material: Carbon Steel. Jacket Pressure: 3.45 bar (50 psi). Jacket Temperature: 149 °C (300 °F).
