Results 1868 items found

Available equipment

Showing 25 of 1868 matching equipment.

Featured
Stock Number: #200724
Glasslined Dryer-Twin Shell & Double Cone
Capacity Design: 100 ft3
Capacity Operating: 70 ft3
Vessel Pressure: 30 psi
Vessel Temperature: 450 °F
Jacket Pressure: 50 psi
Jacket Temperature: 350 °F
Full Vacuum: Yes
Additional Information: standard 6' diameter bucket with 18" diameter manway and 8" diameter outlet with 9 to 45 rpm on bucket with Hastelloy vacuum arm with stuffing box. With bull and pinion Reconditioned gear box, driven by 3HP XP class 1, div 2 , 3 phase, 60HZ, 230, 460 Volt motor with electric 10 ft-lbs. brake.
More Details ⟶
Featured
Stock Number: #238184
Unused Reactor Glasslined Pfaudler KC Batch Type **Body Only** Can be equipped with Agitation System
Capacity (Design): 5,000 gallons
Internal Pressure: 90 psi
Internal Full Vacuum: Yes
Internal Temperature: 400 °F
Jacket Pressure: 125 psi
Jacket Temperature: 400 °F
Body Only: Yes
Diameter: 108 in
Straight Side Length: 179 in
Support Type: Legs
Additional Information: • Can be equipped with Agitation System • Reglassed KC series reactor body • Manufacturers number 4364421 • With (4) side support lugs or (8) leg couplings for mounting/installation.
More Details ⟶
Featured
Stock Number: #224189
Reactor Batch-Type Agitated Glasslined Pfaudler BE
Capacity (Design): 8,200 L
Internal Pressure: 6 bar
Internal Full Vacuum: Yes
Internal Temperature: 200 °C
Jacket Pressure: 6 bar
Jacket Temperature: 200 °C
Orientation: Vertical
Agitation: Yes
Diameter: 2,000 mm
Straight Side Length: 3,250 mm
Support Type: Lugs
Additional Information: 6,300 liter order number 60669 Pressure ratings: Internal -1/6 Bar @ -25/+200°C total volume 8,190 liters; Jacket rated -1/6 Bar @ -25/+200°C total volume 795 liters. Lined with glass WWG9115 With a top mounted drive with Burgmann mechanical seal type M462L-D20 and Burgmann Thermosyphon TS 2000 pneumatic bottom outlet valve, and solids dosing device,
More Details ⟶
Featured
Stock Number: #203648
Pfaudler Shell and Tube Heat Exchanger Tantalum & Glass Lined
Heat Transfer Surface Area: 85 ft²
Orientation: Horizontal
Shell Pressure: 50 psi
Shell Temperature: 425 °F
Shell Material: Glasslined
Tube Pressure: 300 psi
Tube Temperature: 425 °F
Tube Material: Tantalum
Vacuum: Yes
Shell Diameter: 24 in
Head Material: Glasslined
Tube Type: U-Tube
Additional Information: Rated FV/300 psi @ -20 to 425 degrees tube side; FV/50 psi @ -20 to 425 degrees F shell side.
with glass lined clamped heads Tube Number: 18. Tube Diameter: 0.75 in. Tube Length: 216 in.
More Details ⟶
Featured
Stock Number: #90726
Glasslined Reactor Batch-Type Agitated Pfaudler E Type
Capacity (Design): 1,200 L
Internal Pressure: 6 bar
Internal Full Vacuum: Yes
Internal Temperature: 200 °C
Jacket Pressure: 6 bar
Jacket Temperature: 200 °C
Diameter: 1,200 mm
Straight Side Length: 1,250 mm
Additional Information: Auft # 37387 belt driven by LOHER 3.6 KW, 1715 RPM, 3/7.7-13.3A/60Hz/220-380 volt motor, ex proof (T3). Designed to German TUV standards. Reglassed in Romani by UGE 2001.
More Details ⟶
Featured
Stock Number: #241027
Reactor Glasslined Batch-Type Agitated
Capacity (Design): 3,000 gallons
Internal Pressure: 150 psi
Internal Full Vacuum: Yes
Internal Temperature: 450 °F
Jacket Pressure: 150 psi
Jacket Temperature: 450 °F
Orientation: Vertical
Agitation: Yes
Diameter: 96 in
Straight Side Length: 73 in
Support Type: Legs
Additional Information: Shell rated 150/FV @ 450 degrees F. Conventional jacket 150/FV @ 450 degrees F with welded 2:1 elliptical heads Alloy mixer with dual tier agitation, lower is a CBT, upper is a PBT
More Details ⟶
Featured
Stock Number: #216539
Glasslined Pfaudler RW Glass Drives Agitator
Diameter: 6 in
Additional Information: 7/8 RW Baseplate with 6" diameter glass lined bore
More Details ⟶
Featured
Stock Number: #240794
Pfaudler Agitator Drive
Additional Information: Reconditioned, 4 RW gearbox,
More Details ⟶
Featured
Stock Number: #225352
Hastelloy - C276 Pfaudler Tray Column
Diameter (1): 3 in
Length (overall): 36 in
Pressure: 300 psi
Vacuum: Yes
Temperature: 450 °F
Number Of Trays: 10
Tray Type: Sieve Tray
Additional Information: distillation column with reflux splitter and separator tank Top head is a 3" to 1.5" concentric reducer Includes a reflux splitter and separator tank
More Details ⟶
Featured
Stock Number: #86856
Glasslined Crystalizer/Evaporator Evaporator
Orientation: Vertical
Diameter: 36 in
Height: 28 in
Additional Information: • 130 gal (500 liter), Open top, dish bottom. No bottom outlet.
More Details ⟶
Featured
Stock Number: #238333
Glasslined Pfaudler RA Batch Type Body Only Reactor
Capacity (Design): 1,000 gallons
Internal Pressure: 100 psi
Internal Full Vacuum: Yes
Internal Temperature: 450 °F
Jacket Pressure: 90 psi
Jacket Temperature: 350 °F
Jacket Material of Construction: Carbon Steel
Body Only: Yes
Orientation: Vertical
Diameter: 60 in
Straight Side Length: 74 in
Support Type: Legs
Additional Information: • This is a bare reactor
More Details ⟶
Stock Number: #248458
Batch-Type Agitated Reactor
Capacity (Design): 3,000 gallons
Internal Pressure: 100 psi
Internal Full Vacuum: Yes
Internal Temperature: 450 °F
Jacket Pressure: 90 psi
Jacket Temperature: 450 °F
Jacket Material of Construction: Glasslined
Orientation: Vertical
Agitation: Yes
Diameter: 102 in
Straight Side Length: 85 in
Support Type: Lugs
Additional Information: • Dual Rated Vessel • Dual rated vessel 70/FV psi @ -40 F to 450 F Jacket 47/47 w/FV psi @ -40 F to 450 F
More Details ⟶
Stock Number: #246408
Glasslined Agitator Glass Lined Parts
Vessel Size: 4,000 gallons
Hub size: 4.5
Reglassed: Yes
Rotation: Clockwise
PBT Span: 43 in
Additional Information: • 1 Set PBT Blades, prices is for set, and so is the weight.
More Details ⟶
Stock Number: #233232
Glasslined Pfaudler KC Batch-Type Agitated Reactor
Capacity (Design): 1,500 gallons
Internal Pressure: 100 psi
Internal Full Vacuum: Yes
Internal Temperature: 450 °F
Jacket Pressure: 90 psi
Jacket Temperature: 450 °F
Agitation: Yes
Diameter: 78 in
Straight Side Length: 65 in
Additional Information: reactor assembly
More Details ⟶
Stock Number: #238227
Unused Glasslined Miscellaneous Glass Lined Parts Dip Tube 6.5" diameter
Diameter: 6.5 in
Length: 120 in
Additional Information: • Dip Tube , 6 1/2" diameter x 120" overall length,113 1/2" wet length for a 8" nozzle
More Details ⟶
Stock Number: #238274
Unused Glasslined Pfaudler Miscellaneous Glass Lined Parts Dip Tube 4" Diameter
Diameter: 4 in
Length: 25 in
Additional Information: • Dip Tube approximately 4" diameter x 6" x 32" over all length, 25" wet length. Flange mount.
More Details ⟶
Stock Number: #235530
Cryo-Lock Blades Glass Lined Parts
Vessel Size: 4,000 gallons
Hub size: 4.5
Rotation: Clockwise
PBT Span: 43 in
Additional Information: • Quantity of two is a set.
More Details ⟶
Stock Number: #238303
Glasslined Pfaudler RA Batch-Type Agitated Reactor
Capacity (Design): 1,000 gallons
Internal Pressure: 100 psi
Internal Full Vacuum: Yes
Internal Temperature: 450 °F
Jacket Pressure: 90 psi
Jacket Temperature: 350 °F
Jacket Material of Construction: Carbon Steel
Orientation: Vertical
Agitation: Yes
Diameter: 60 in
Straight Side Length: 74 in
Support Type: Legs
Additional Information: 100/90# DTW Drive
More Details ⟶
Stock Number: #238228
Unused Glasslined Miscellaneous Glass Lined Parts Dip Tube 3" Diameter
Diameter: 3 in
Length: 68.5 in
Additional Information: • Dip Tube, 3" diameter x 68 1/2" overall length, 64 1/2" wet length for a 8" nozzle.
More Details ⟶
Stock Number: #238229
Unused Glasslined Miscellaneous Glass Lined Parts Dip Tube 3" Diameter
Diameter: 3 in
Length: 68.5 in
Additional Information: • Dip Tube, 3" diameter x 68 1/2" overall length,64 1/2" wet length for a 4" nozzle
More Details ⟶
Stock Number: #240182
Glasslined Pfaudler RS Batch Type Body Only Reactor
Capacity (Design): 6,000 gallons
Internal Pressure: 125 psi
Internal Full Vacuum: Yes
Internal Temperature: 450 °F
Jacket Pressure: 90 psi
Jacket Temperature: 350 °F
Jacket Material of Construction: Carbon Steel
Body Only: Yes
Orientation: Vertical
Diameter: 108 in
Straight Side Length: 130 in
Support Type: Legs
Additional Information: • Shell is 1", Heads are 1" Jacket is 5/8” all Carbon steel. Reglassed in 2015 *
More Details ⟶
Stock Number: #44870
Glasslined P Series Tank Cover Glass Lined Parts
Diameter: 30 in
Vessel Size: 100 gallons
Reglassed: Yes
Additional Information: • Reactor cover Bolt holes - (3) 1/2" bolt holes. Bolt circle - 9" • Fits 100 gal P Series reactor.
More Details ⟶
Stock Number: #99891
Glasslined Pfaudler Dryer-Twin Shell & Double Cone
Capacity Design: 2.6 ft3
Capacity Operating: 1.6 ft3
Vessel Pressure: 30 psi
Vessel Temperature: 450 °F
Jacket Pressure: 80 psi
Jacket Temperature: 350 °F
Full Vacuum: Yes
Additional Information: (Reglassed @ UGE facility ). Glass #5015 W/Hastelloy C vac arm inside w/packing Openings: top 1-10" w/cover; btm 1-10" w/cover varidrive reducer, max output 154 rpm, min output 15.4 rpm Control panel with start/stop switches
More Details ⟶
Stock Number: #238213
Unused Teflon Pfaudler Miscellaneous Glass Lined Parts 2" Diameter Dip Tube
Diameter: 2 in
Length: 141 in
Additional Information: • Teflon coated dip tube, 2" diameter x 141 over all length ,wet length 135".for 6" nozzle
More Details ⟶
Stock Number: #213719
Unused Glasslined Miscellaneous Glass Lined Parts 3.5" Dip Tube
Diameter: 3.5 in
Length: 89 in
Vessel Size: 1,000 gallons
Additional Information: • Dip pipe approximately 3 1/2" OD, 2 1/2" ID x 89" over all length, 85" wet length with 6" diameter flange.
More Details ⟶
